Side 1/8

American DJ

4295 Charter Street

Los Angeles CA. 90058

www.americandj.com

Revised 8/01

User Instructions

Unpacking: Thank you for purchasing the Centurion™ by American

DJ . Every Centurion™ has been thoroughly tested and has been ®

shipped in perfect operating condition. Carefully check the shipping

carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: This unit use a single color/gobo wheel combination

for vibrant colors and extravagant gobo patterns. The Centurion™ is

an intelligent fixture that can operate in DMX mode, as a stand alone

sound active piece, or in a Master/Slave configuration. The Centurion™

comes with several build in programs and is best used in multiples of

four. This piece is best used with a fog or haze machine to enhance

the beam output. When used in DMX mode the fixture requires 3 DMX

channels. When used as a stand alone unit or when used in multiples

linked in a master/slave configuration an optional IRC/2 controller may

be used to control a blackout function.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

Centurion™ General Information

• EFP 12v/100w Lamp

• DMX-512 Compatible

• 14 Colored Gobo Combinations, Plus White Spot

• Fan Cooling.

• Built-In 15 Second Lamp Life Protection Circuitry

• Master/Slave Operation

• Linkable

Centurion™ Main Features

The Centurion™ carries a one year (365 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) number.

If the unit is under warranty, you must provide a copy of your proof of

purchase invoice. Please contact American DJ customer support for ®

a R.A. number.

Centurion™ Product Registration

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required voltage

for your unit.

• Do not attempt to operate this unit if the power cord has been frayed

or broken.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when itʼs cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product outdoors

voids all warranties.

• During long periods of non-use, disconnect the unitʼs main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 13 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (includ-

ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Centurion™ Safety Precautions

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. If you do not wish to

read through the manual, listed below are the master/slave dip switch

setting. Link the units together using microphone cables and follow the

dip switch chart for sound activation mode. Please keep this manual

with the unit, for future reference.

Centurion™ Quick Start Instructions

Centurion™ Master/Slave Settings

This chart details the Master/Slave dip switch setting for Master/Slave

configuration. Use this configuration only when you will be using your

fixtures in a Master/Slave configuration. Be sure the number 2 function

switch is set to the on position for sound-active operation.

ON ON

1 98765432

Head 4

1 98765432

Head 3

1 98765432

Head 2

1 98765432 10

Master - Head 1
