Side 1/4

User Instructions

American DJ®

4295 Charter Street

Los Angeles, CA. 90058

www.americandj.com

7/05

Cinco Star™ Introduction

Introduction: Thank you for purchasing the Cinco Star™ by Ameri-

can DJ . The Cinco Star™ is ready to be plugged in right out of the ®

box and does not require any type of controller to operate. The Cinco

Star™ comes with two spinning heads that operate on an indepen-

dently rotating base. This unit produces multi-colored beams of light

that creates unique patterns on the floor and walls. To optimize beam

intensity use this fixture with a fog machine or other type of special

effect smoke.

Customer Support: American DJ provides a toll free customer ®

support line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ . Service Hours are Monday through Friday 9:00 a.m. to 5:00 ®

p.m. Pacific Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Unpacking: Every Cinco Star™ has been thoroughly tested and has

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your unit for damage

and be sure all accessories necessary to operate the unit have arrived

intact. In the event damage has been found or parts are missing, please

contact our toll free customer support number for further instructions.

Please do not return this unit to your dealer without first contacting

customer support at the number listed below.

Warning! To prevent or reduce the risk of electrical shock or fire, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact your nearest American DJ dealer.®

PLEASE recycle the shipping carton when ever possible.

Cinco Star

American DJ

�®

Cinco Star™ Precautions

• Keep the outside of this device dry at all times. Do not spill water or

other liquids into or on to your unit. To prevent ﬁre or shock hazard,

do not expose this product to rain or moisture.

• This unit is designed for interior use only. Do not use this unit out

doors. Use of product outdoors will void the warranty.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Never attempt to operate this unit if the power cord becomes

frayed or broken.

• Never attempt to operate this unit, if it becomes damaged in any

way.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

• Five Moving Heads

• Easy Lamp Replacement

• Compact High-Tech Case Design

• Built-In Hanging Base

• Light Weight Case Design

• Multi-Colored Beams

• 5 Multi-Colored Heads

• 5 x LL-100 120v/100w

Cinco Star™ Features

Cinco Star™ Warranty Registration

The Cinco Star™ carries a one year (365 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) num

ber. The R.A. number must be clearly written on the outside of the

return package. A brief description of the problem as well as the R.A.

number must also be written down on a piece of paper included in

the shipping

carton. If the unit is under warranty, you must provide a

copy of your proof of purchase invoice. You may obtain a R.A. num

ber by contacting our customer support team on our toll free custom

er support number. All packages returned to

the service department

not displaying a R.A. number on the outside of the package will be

returned to the shipper.

Cinco Star™ Operation

Power Supply: Before plugging your unit in, be sure the source

voltage in your area matches the required voltage for your American

DJ Cinco Star™ before attempting operation. ®

General Operation: Just plug this light in, and watch it go. This fix-

ture is designed to operate as a stand alone unit. It has been tested

and the lamp has been installed at the factory there is no assembly

necessary. The Cinco Star™ is ready to be plugged in, out of the box.

There is no power switch, after plugging the unit in the base and five

outer heads will immediately begin to spin.

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte

nance of this unit. Please keep this manual with the unit, for future

reference.

Cinco Star™ General Instructions

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the

internal and external lenses

should be carried out periodically to opti-

mize light output. Cleaning frequency depends on the environment

in which the fixture operates (I.e. smoke, fog residue, dust, dew).

In heavy use we recommend cleaning on a monthly basis. Periodic

cleaning will ensure longevity, and crisp beam output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Use a soft brush to clean out the air vents

3. Clean the external optics with glass cleaner and a soft cloth every

20 days.

4. Clean the internal optics with glass cleaner and a soft cloth every

30-60 days.

5. Always be sure to dry all parts completely before plugging the unit

back in.

Cinco Star™ Cleaning
