Side 1/10

Rev. 3/14

User Instructions

American DJ - www.americandj.com - Comscan LED Instruction Manual Page 2®

Comscan LED General Information

Unpacking: Thank you for purchasing the Comscan LED by Ameri-

can DJ . Every Comscan LED has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please do not return this unit to your dealer without con-

tacting customer support rst.

Introduction: The Comscan LED is a five channel DMX intelligent,

LED scanner. The Comscan LED can operate as a stand alone fixture

or in a Master/Slave configuration. Comscan LED has three oper The -

ating modes; sound active mode, show mode and DMX control. This

fixture is suitable for theaters, studios, retail stores, and other similar

locations. For best results use fog or special effects smoke to enhance

the beams projections.

Customer Support: American DJ provides a toll free customer ®

support line, to provide help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

For Your Own Personal Safety, Please Read and Understand This

Manual Completely Before You Attempt To Install Or Operate

This Unit!

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break o the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 15 for cleaning details.

• Heat -This fixture should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including

amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. Objects have fallen, or liquid has been spilled into the appliance.

B. The appliance has been exposed to rain or water.

C. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Comscan LED Safety Precautions

American DJ - www.americandj.com - Comscan LED Instruction Manual Page 4American DJ - www.americandj.com - Comscan LED Instruction Manual Page 3 ®®

• DMX-512 Protocol Compatible (Five DMX Channels)

• X/Y Mirror Control

• 3 Operating Modes - Sound Active, Show Mode, and DMX Control

• Internal Microphone

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

Comscan LED Features

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

American DJ

® will not accept any liability for any resulting damages

caused by the non-observance of this manual or any unauthorized

modication to this unit.

Comscan LED Handling Precautions

Comscan LED Warranty Registration

The Comscan LED carries a 2 year (730 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact American DJ® cus-

tomer support for a R.A. number.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Comscan LED General Instructions
