Side 1/8

User Instructions

American DJ

4295 Charter Street

Los Angeles, CA 90058

www.americandj.com

DJ Scan 250™ Introduction

Introduction: Congratulations and thank you for purchasing the DJ

Scan 250™ by American DJ

®, one of the finest pieces of its kind on the

market today! The DJ Scan 250™ is a great inexpensive, light weight,

intelligent fixture. Due to it’s physical specifications, it’s a great piece

for mobile DJ’s, roller rinks, small clubs, bars, and bowling centers.

When used in multiples of two or more, these units create an effect

that rivals that of units that can cost up to three times the price. The DJ

Scan 250™ was designed to run in a Master/Slave mode but can be

used with any universal DMX-512 controller.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set-up and installation help and to answer any

question should you encounter problems during your set up or initial

operation. You may also visit us on the web at www.americandj.com

for any comments or suggestions. Toll free customer service hours are

Monday through Friday 9:00 a.m. to 5:30 p.m. Paciﬁc Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or ﬁre, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war

ranty. In the unlikely event your unit may require service please contact

American DJ customer support.®

Please recycle the shipping carton when ever possible

Improvements and changes in speciﬁcations and design to this

manual and unit may be made at any time without prior notice.

HALOGEN LAMP WARNING!

This fixture is fitted with a halogen lamp which is highly susceptible to

damage if improperly handled. Never touch the lamp with your bare

fingers as the oil from your hands will shorten the lamp life. Never

install, mount, or place this fixture in areas prone to heavy vibration.

Also, never move the fixture until the lamp has had ample time to

cool. Remember, lamps are not covered under warranty conditions.

Rev. 3/04

DJ Scan 250™ Quick Start

The DJ Scan 250™ features a bright 250 watt halogen bulb with a

separate gobo and color wheel. The color wheel features seven bril

liant colors plus white and the gobo wheel features 10 gobos plus

a large spot. This fixture incorporates the use of high quality step

per motors for a more accurate mirror movement. Mirror movement

allows for a full 90 degree tilt (vertical) and a 45 degree pan (hori

zontal). An internal built in microphone allows the fixtures to run in

Stand Alone mode so there is no need for an external controller. The

DJ Scan 250™ may also be set-up to run in a Master-Slave mode

when used in multiples, up to four units. When used in the Master-

Slave mode, the unit will chase to several internal programs. The

DJ Scan 250™ can also be controlled via a standard DMX control

ler such as the American DJ

® Show Designer,™ or the American

® DMX Operator,™ giving the user independent control over the

gobo and color wheel as well as the mirrors pan and tilt movements.

Note: The built in programs in the DJ Scan 250™ are so good you

may never need a DMX controller.

• ZB-ELC7 24V/250W

• DMX-512 Compatible.

• Stepper motors for smooth movements.

• 7 colors plus white.

• 10 Gobos plus spot.

• Gobo Shake

• Master/Slave Operation

• Sound Active.

• Optional MINI/C controller, for blackout control.

• Optional Wireless MINI/C controller, for blackout control.

DJ Scan 250™ Features

Master/Slave Quick Start Stand Alone Mode

Connect up to four units together via XLR cables. The master unit will

run the slaves to the masters built in programs and internal micro

phone. Plug in all units. When the DJ Scan 250™ is first turned on, it

will run through an internal self test where it resets all motors to their

zero position. After the self test the units will react to sound, and fol

low several built in programs.

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Please route your power cord out of the way of

foot trafﬁc.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and ﬁre in case of an internal short.

• Disconnect

from main power before making any type of connection.

• Do not remove the top cover under any conditions. There are no

user serviceable parts inside.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged in any

way.

• Never operate this unit when it’s cover is removed.

• To reduce the risk of electrical shock or ﬁre, do not expose this unit

rain or moisture

• This unit is intended for indoor use only, use of this product out

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power Cord Protection - Power cords should be routed so they are

not likely to be walked on or pinched by items placed upon or

against them, paying particular attention to cords at plugs, conve-

nience receptacles, and the point where they exit from the unit.

• Cleaning - Follow the directions on page 10.

• Heat -The unit should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including

amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The fixture does not appear to operate normally or exhibits a

marked change in performance.

DJ Scan 250™ Safety Precautions
