Side 1/8

American DJ ®

4295 Charter Street

Los Angeles CA. 90058

www.americandj.com

1/07

User Instructions

Unpacking: Thank you for purchasing the Double Roller by Amer-

ican DJ . Every Double Roller has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your ﬁxture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please do not return this unit to your dealer without ﬁrst

contacting customer support.

Introduction: This unit is an unigue double barrel, eight channel DMX

intelligent light. Four channels for each side. This unit can also run as

a stand alone, sound-active unit, or in a Master/Slave configuration.

When used as a stand alone unit or when used in multiples linked in

a master/slave configuration, the optional BC 30 Controller may be

used with in this operation for blackout, program modes, and program

effects. For best results use fog or special effects smoke to enhance

the beams projections.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

5:00 p.m. Paciﬁc Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or ﬁre, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

Double Roller General Information

• DMX-512 Protocol Compatible (Uses Eight DMX Channels)

• Bright Lamps

LL-ELC x 2, 124v/250w

• 2 Gobo Wheels - Each with 10 Gobo Patterns

Plus One Spot/8

Colors Plus White, and 1 Quad Color and 1 Split Color

• Gobo Shake and Gobo Switch

• Master/Slave Operation

• Internal Microphone

• High Velocity Fan (No Duty Cycle)

• Optional BC 30 remote control for Blackout and Programs

(Not

Included)

Double Roller Features

The Double Roller carries a one year limited warranty. Please fill out

the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. num

ber must be clearly written on the outside of the return package. A

brief description of the problem as well as the R.A. number must also

be written down on a piece of paper included in the shipping carton.

If the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our toll free customer support number. All

packages returned to the service department not displaying a R.A.

number on the outside of the package will be returned to the shipper.

Double Roller Product Registration

• To reduce the risk of electrical shock or ﬁre, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break off the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and ﬁre in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 12 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Double Roller Safety Precautions

To optimize the performance of this product, please read these operating

instructions carefully to familiarize yourself with the basic operations of

this unit. These instructions contain important safety information regard-

ing the use and maintenance of this unit. Please keep this manual with

the unit, for future reference.

Double Roller General Instructions
