Side 1/10

User Instructions

Introduction: Thank you for purchasing the American DJ Emerald ®

Scan.

™

The Emerald Scan™ is a DMX intelligent, laser effect that cre-

ates 12 different patterns. This unit can be used as a stand alone,

sound-active unit or in a Master/Slave conguration. The unit can also

be controlled via DMX controller. For a dramatic laser show use several

Emerald Scans™ together. This piece is best used with a fog or haze

machine to enhance the beam output.

Unpacking: Every Emerald Scan™ has been thoroughly tested and

has been shipped in perfect operating condition. Carefully check the

shipping carton for damage that may have occurred during shipping.

If the carton appears to be damaged, carefully inspect the unit for

any damage and be sure all accessories necessary to operate the unit

have arrived intact. In the event damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Please do not return the unit to your dealer without

rst contacting customer support.

Customer Support: American DJ provides a toll free customer ®

support line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ .® Service Hours are Monday through Friday 9:00 a.m. to 5:00

p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact American DJ customer support.

PLEASE recycle the shipping carton whenever possible.

Emerald Scan™ General Introduction

Rev. 10/09

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

Emerald Scan™ General Instructions Emerald Scan™ Safety Precautions

Safety Issues: This unit may “pop” the breaker if the maximum allotted

load of 2 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 14 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a

marked change in performance.

• 4.9mW Green Laser Diode

• X/Y Mirror Control

• 2 Selectable Built-In Light Shows

• 4 Channel DMX Control

• Built-In Hanging Yoke

• Sound Active with Internal Microphone

• Fan Cooled

• 12 Patterns

• Mini/C Compatible for Blackout Control (Not Included)

Emerald Scan™ Features

Emerald Scan™ Warranty Registration

The Emerald Scan™ carries a 90 day limited warranty. Please fill out

the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-

paid and accompany a return authorization (R.A.) number. If the unit

is under warranty you must provide a copy of your proof of purchase

invoice. Please contact American DJ customer support for a R.A. ®

number.

DANGER

VISIBLE LASER RADIATION

-AVOID DIRECT EYE EXPOSURE

LASER DIODE

WAVELENGTH : 635~650 nm

Max Output : <4.9mW

Class IIIa Laser Product
