Side 1/12

User Instructions

Fusion FX Bar 5 Introduction

Rev. 3/14

Unpacking: Thank you for purchasing the Fusion FX Bar 5 by Ameri-

can DJ . Every Fusion FX Bar 5 has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: The Fusion FX Bar 5 is part of American DJ’s continu-

ing pursuit for creating high quality affordable intelligent fixtures. The

Fusion FX Bar 5 is a DMX intelligent LED wash & laser fixture. The unit

has 3 operating modes; Sound Active (with adjustable sound sensitiv-

ity), Show Mode, or DMX Control. This unit can be used as a stand

alone xture, or in a Master/Slave conguration.

Customer Support: American DJ provides a toll free customer sup®-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

PLEASE recycle the shipping carton when ever possible.

Fusion FX Bar 5 Safety Precautions

• White LED Wash/Strobe Effect, 1 TRI Color LED Moonflower, & 1

Green Laser

• Strobing

• Built in Microphone

• DMX-512 protocol - Seven DMX Modes

• 16 Show Modes, 1 Radom Show Mode

• 3 Operating Modes - Sound Active, Show Mode, or DMX Control

• Sound Sensitivity Adjustable

• UC3 Remote Control Compatiable (Not Included)

• Power Cord Daisy Chaining. See page 16.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 19 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Fusion FX Bar 5 Warranty Registration

Fusion FX Bar 5 Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

Fusion FX Bar 5 General Instructions

The Fusion FX Bar 5 carries a 2 year (730 days) limited warranty for

LEDs and a 90 Day limited warranty for the laser. Please fill out the

enclosed warranty card to validate your purchase and warranty. You

may also register your product online at www. americandj.com. All

returned service items whether under warranty or not, must be freight

pre-paid and accompany a return authorization (R.A.) number. If the

unit is under warranty you must provide a copy of your proof of pur-

chase invoice. Please contact American DJ® customer support for a

R.A. number.
