User Instructions

Unpacking: Thank you for purchasing the Image 8 DMX™ by Ameri-

can DJ . Every Image 8 DMX™ has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If

the carton appears to be damaged, carefully inspect your unit for any

damage and be sure all equipment necessary to operate the system

has arrived intact. In the event damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Please do not return the unit to your dealer without

rst contacting customer support.

Introduction: The Image 8 DMX™ is a unique three channel, DMX

intelligent, eight beam red laser effect that creates several different

patterns over a wide area. This unit can be used as a stand alone,

sound-active unit or in a Master/Slave conguration. The unit can also

be controlled via DMX controller. The unit’s sound sensitivity may be

adjusted by a sensitivity knob on the rear of the unit. For best results

use fog or special effects smoke to enhance the beams projections.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ . Service Hours are Monday through Friday 9:00 a.m. to 5:00 ®

p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ.

PLEASE recycle the shipping carton when ever possible.

Image 8 DMX™ General Introduction

Rev. 10/09

Image 8 DMX™ General Instructions Image 8 DMX™ Safety Precautions

Image 8 DMX™ Features

Image 8 DMX™ Warranty Registration

The ™ carries a Image 8 DMX 90 day limited warranty. Please fill out

the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. num-

ber must be clearly written on the outside of the return package. A

brief description of the problem as well as the R.A. number must also

be written down on a piece of paper included in the shipping carton.

If the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our toll free customer support number. All

packages returned to the service department not displaying a R.A.

number on the outside of the package will be returned to the shipper.

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

• 4.9mW Red Laser Diode

• 8 Seperate Lasers

• Sound Active with Internal Microphone

• DMX-512 Protocol Compatible

• 3 Channels

• Master/Slave Operation

• 14 Patterns

• Volume Sensitivity Knob

Safety Issues: This unit may pop the breaker if the maximum allotted

load of 2 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 6 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen on, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a

marked change in performance.
