Side 1/10

User Instructions

American DJ®

6122 S. Eastern Ave.

Los Angeles Ca. 90040

www.americandj.com

Mega Pixel Arch Introduction

Rev. 5/09

Unpacking: Thank you for purchasing the Mega Pixel Arch by Ameri-

can DJ . Every Mega Pixel Arch has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: The Mega Pixel Arch is part of American DJ’s continu-

ing pursuit for creating high quality affordable intelligent fixtures. The

Mega Pixel Arch is a DMX intelligent LED display fixture. This fixture is

a great piece for retail stores, displays, mood, architectural, interior and

exterior decoration, and clubs. This unit can be used as a stand alone,

or in a Master/Slave conguration. The unit can also be controlled via

DMX controller.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

PLEASE recycle the shipping carton when ever possible.

Mega Pixel Arch Safety Precautions

• RGB Color Mixing

• Color Strobe Effect

• Color Mix Effect

• LED Chases (Adjustable Speeds)

• Electronic Dimming 0-100%

• Built in Microphone

• DMX-512 protocol

• Seven DMX Modes (See pages 8-9)

• 3 Operating Modes - Sound Active, Show Mode, or DMX Control

• UC3 Remote Control Compatiable (Not Included)

• Power Cord Daisy Chain (See Page 12)

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 14 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Mega Pixel Arch Warranty Registration

The Mega Pixel Arch carries a 3 year (1095 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact American DJ® cus-

tomer support for a R.A. number.

Mega Pixel Arch Features

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.
