User Instructions

©American DJ® - www.americandj.com - Ruby Royal Instruction Manual Page 2

Unpacking: Thank you for purchasing the Ruby Royal by American DJ®.

Every Ruby Royal has been thoroughly tested and has been shipped

in perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your xture for any damage and be

sure all equipment necessary to operate the unit has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Please

do not return this unit to your dealer without contacting customer sup-

port rst. PLEASE recycle the shipping carton whenever possible.

Introduction: The Ruby Royal projects unique red, blue, and magenta

laser patterns. The Ruby Royal has three operating modes; sound

active mode, show mode, or it can be controlled via DMX. The Ruby

Royal can operate as a stand alone fixture, or in a Master/Slave con-

figuration. This unit is suitable for theaters, studios, retail stores, and

other similar locations. For best results use fog or special effects smoke

to enhance the beams projections.

Customer Support: American DJ® provides a toll free customer sup-

port line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ®. Service Hours are Monday through Friday 8:00 a.m. to 4:30

p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ customer support.

Ruby Royal General Introduction

2/12

©American DJ® - www.americandj.com - Ruby Royal Instruction Manual Page 4©American DJ® - www.americandj.com - Ruby Royal Instruction Manual Page 3

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

Ruby Royal General Instructions Ruby Royal Safety Precautions

Safety Issues: This unit may “pop” the fuse if the maximum allotted

load of 2 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break o the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 19 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a

marked change in performance.

• 150mW Red Laser & 150mW Violet Blue Laser

• 6 Channel DMX Control

• 3 Operating Modes - Sound Active, Show Mode, & DMX Control

• 20 Laser Patterns

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Run as Stand Alone unit or in a Master-Slave Conguration

• Power Cord Daisy Chain up to 18 units max. See page 16

Ruby Royal Features

Ruby Royal Warranty Registration

The Ruby Royal carries a 90 day limited warranty. Please fill out the

enclosed warranty card to validate your purchase. All returned ser-

vice items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. If the unit is

under warranty you must provide a copy of your proof of purchase

invoice. Please contact American DJ® customer support for a R.A.

number.

LASER RADIATION AVOID

DIRECT EYE EXPOSURE

Maximum output <5 mW

Wavelength: 405, 532nm

Class IIIa laser product

This device complies with 21 CFR chapter I,

Subchapter J, or CFR 1040.10 and 1040.11

The unit should be mounted using a mounting clamp (not provided),

axing it to the mounting bracket that is provided with the unit.

Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also always use a safety cable that can hold

12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Ruby Royal Installation
