Introduction:

Congratulations and thank you for purchasing the American DJ UC3 Wireless. The UC3 Wireless is a great upgrade to

our regular UC3 controller. The UC3 Wireless was designed for DJs, Bands, Bars/Clubs, and Mobile Entertainers that

want to control multiple American DJ light fixtures that are UC3 compatible, yet still enjoy the easy-of-use the single

channel UC3 controller offers. This wireless pack had 4 outputs with the capability to control 4 master fixtures and an

infinite number of slave fixtures. The UC3 Wireless is compact and light-weight, and can be mounted on truss, light-

ing stands, wall, or ceilings. The UC3 Wireless has a transmitting distance of 325ft. or 100 meters. With the wireless

remote you are able to control Stand By (Black Out), Function, and Mode for each output. Please refer to your units

user manual for its UC3 functions and controls. The remote also comes with Lock Out function that allows you to lock

the buttons to avoid any accidental function changes.

Customer Support: American DJ® provides a toll free customer support line, to provide set up help and to answer any

question should you encounter problems during your set up or initial operation. You may also visit us on the web at www.

americandj.com for any comments or suggestions. For service related issue please contact American DJ®. Service Hours

are Monday through Friday 9:00 a.m. to 4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, doing so will void

your manufactures warranty. In the unlikely event your unit may require service please contact American DJ customer

support.

The UC3 Wireless carries a 1 Year (365 days) limited warranty. Please fill out the enclosed warranty card to validate your

purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return

authorization (R.A.) number. If the unit is under warranty you must provide a copy of your proof of purchase invoice. Please

contact American DJ® customer support for a R.A. number. For additional warranty info please visit our website.

***THIS SYSTEM HAS BEEN SYNCHRONIZED AT THE FACTORY AND IS READY FOR USE RIGHT OUT OF THE BOX***

If your system becomes unsychronized you can follow the steps below to resync.

SET UP AND SYNCH: When using the UC3 Wireless please refer to your units user manual for its UC3 functions and con-

trols. Please see other side for the UC3 Wireless controls and functions.

1. Using a 1/4” to 1/4” stereo cable, connect one end of the cable to the 1/4” jack on the back of your desired UC3 com-

patible fixture and the other end of the cable to one of the four 1/4” jacks located on the UC3 Receiver. Turn on the UC3

Receiver.

2. Once you have your unit(s) connected to the UC3 Receiver press the SET UP (3) button located on top of the Receiver, RF

SIGNAL LED (4) will begin to flash.

3. When the RF SIGNAL LED (4) is lit, press any button on the UC3 Wireless Controller. Once you press any button, the RF

SIGNAL LED (4) will turn off. The set up process is complete and you can begin controlling your connected unit(s).

RESET: Follow these instructions to reset the signal.

1. Press the SET UP (3) button located on top of the Receiver, DATA until the RECEIVING LED (4) is lit.

2. Now press the SET UP (3) button once to reset.

Specifications:

Voltage..........................................................................120V/60Hz or 220V/50Hz (Not User Selectable)

Wireless Transmitting Distance...............................................................................................325ft. /100M

Frequency...............................................................................................................................................433.9Mhz

Fuse.................................................................................................................................................................1A

Receiver Dimensions.........................................................................................10.25 (L) x 4” (W) x 2” (H)

Receiver Weight......................................................................................................................3lbs / 1.3Kg
