What’s in the Box
PF-115LF or PF-410HLF Speaker Cabinet, Quick Start Guide.
Introduction
Portable. Powerful. Sexy. Ampeg designed and built the original Portaex® Series products
over 50 years ago. Today, we unveil two new Portaex extension cabinets to meet all of your
low-end needs. Embrace the rumble!
Featuring Eminence® Portaex drivers, four removable casters, integrated side handles,
black, diamond pattern tolex, and low-frequency shelf ports, these Portaex cabinets are
ideal companions for any high-powered Ampeg bass head (available separately).
Like all Ampeg products, your Portaex cabinet is designed by musicians and built using only
the best of components. Each cabinet is tested to conrm that it meets our specications,
and we believe that this cabinet is the absolute best that it can be. In order to get the most
out of the cabinet, please fully read this Owner’s Manual Important Safety , as well as the
Instructions included with your cabinet, before playing.
And for choosing Ampeg!thank you
Features
• Ideal companion for any high-powered Ampeg bass head (available separately)
• Loaded with Eminence speaker(s) for high quality sound
• Equipped with a high frequency horn and a 3-position switch (PF-410HLF)
• Two paralleled, 1/4" TS Input and Output jacks
• Nominal impedance: 8
Ω
• Power handling: 400W RMS (PF-115LF) and 800W RMS (PF-410HLF)
• Four removable casters
• Integrated side handles and black, diamond pattern tolex
• 15 mm poplar plywood construction
• Rear shelf ported for low-frequency extension
TABLE OF CONTENTS
What’s in the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rear Panel Connector Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warranty and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
