Side 1/1

SOUND PROJECTOR

COLOUR MP16 MP16 MP26 MP26

GREEN 5 WATTS 10 WATTS2K Ω 1K Ω

YELLOW 10 WATTS 20 WATTS1K Ω 500 Ω

RED 16 WATTS 26 WATTS625 Ω 385 Ω

BLUE COMMON COMMON

MP16 / MP26

WWW.APART-AUDIO.COM INFO@APART-AUDIO.COM

● Type : Dual Cone / 5.5” (model 16)

● Type : Dual Cone / 6.5” (model 26)

● Rated Power RMS : 16 W (model 16)

● Music Power RMS : 20 W (model 16)

● Rated Power RMS : 26 W (model 26)

● Music Power RMS : 35 W (model 26)

● Sound Pressure Level (SPL) 1w/1m 95 dB (model 16)

● max level : 107 dB (model 16)

● Sound Pressure Level (SPL) 1w/1m 96 dB (model 26)

● max level : 111 dB (model 26)

● Frequency range : 100 Hz - 18 kHz (model 16)

● Frequency range : 90 Hz - 19 kHz (model 26)

● Trafo Power Tappings : 16 - 10 - 5W (model 16)

● Trafo Power Tappings : 26 - 20 - 10W (model 26)

● IP Rating : IP56

● Dimensions diameter x length (mm) : 138 x 200 (model 16)

● Dimensions diameter x length (mm) : 170 x 240 (model 26)

● Mounting holes : 3 x 6 mm, 30 mm spacingØ

● Speaker cable length : approx 40 cm

● Weight : 1.35 Kg (model 16)

● Weight : 1.75 Kg (model 26)

Technical Specifications

The MP is a compact and stylish sound projector, designed for music reproduction as well

as voice paging and even alarm signals. The cabinet is made of high impact ABS which makes

the MP weather- and UV proof and an aluminium bracket is included in the packing.

The MP is ideally suited for outdoor applications such as recreational facilities, schools,

parking facilities, train stations , as well as for indoor applications such as warehouses,

production plants, sports centers, ...

The MP is provided with a special coated dual-cone loudspeaker for a clear music and

speech reproduction plus a high quality 100 volt transformer with several power taps.

Standard colour is light-grey, which makes the speaker easy to integrate with industrial colours.

From 12 pieces upward, the speaker can be supplied optionally in any RAL colour.

Power Tappings

26 20 20 10 10 10

+ + + + +148 Watts =

240 Watts ampliﬁ er

Ampliﬁ er power must be higher than total power of all speakers.

Het versterkervermogen moet hoger zijn dan de som van de vermogens van de luidsprekers.

La puissance de l’ampliﬁ cateur doit etre plus élevée que la puissance totale des haut parleurs.

100 Volt Technology

Mounting the loudspeaker

An aluminium mounting bracket is included in the packing. The bracket allows you to rotate the speaker over a range of

more than 180 degrees. Securely mount the bracket to a wall or other solid surface.

Connect the 100V speaker line cable according to the colour code and don’t forget to electrically insulate the unused

cable ends to avoid short circuits and speaker line overloads.

Produkt Specifikationer

Mærke:	APart
Kategori:	Højttaler
Model:	MP26-G
Vægt:	1750 g
Produktfarve:	Grå
Ledningslængde:	0.4 m
Udgangseffekt (RMS):	26 W
Equalizer:	Ingen
Frekvensområde:	90 - 19000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	1.0 kanaler
Højttaler, placering:	Ceiling-mountable, In-wall/in-ceiling, Wall-mountable
Certificering:	IP56
Strømkilde type:	Vekselstrøm
Diameter:	170 mm
