Side 1/1

SURFACE MOUNT LOUDSPEAKER

SWITCH POWER IMPEDANCE AMPLIFIER

1 60 Watts 100 Volt166Ω

2 30 Watts 100 Volt333Ω

3 15 Watts 100 Volt666Ω

4 6 Watts 100 Volt1.6KΩ

5 OFF OFF OFF

616Ω / 160 Watt 16Ω HiFi amp

SDQ8T

WWW.APART-AUDIO.COM INFO@APART-AUDIO.COM

• type : 2-way hiFi Pro, sealed box

• woofer : 8” CP type

• tweeter : 1.2” silk dome neodynium

• protection : system auto-reset 1-guard

• impedance : 16Ω

• 100Volt trafo select : 60-30-15-6-OFF-16Ω

• RMS power low-imp.

AES rated : 140 Watts

music - program : 160 Watts

dynamic peak : (lo-cut) 380 Watts

SPL 1 watt / 1 m : 93dB

SPL max peak : 119dB

• Freq range : 45 - 20000 Hz

• dispersion : 120° H x 100° V

• IP rating : 24

• enclosure material : enforced PolyPlastic

• bracket included : U-type

• dimensions (h x w x d) : 375 x 280 x 240

• weight : 5,45 Kg

Technical Specifications

The SDQ8T 2-way optimised bass-reflex

cabinet loudspeaker offers you a high

performance sound, that normally isn’t associated with

a relatively small cabinet. The loudspeaker can be

used as a 16Ω or 100V loudspeaker. In 16Ω use, you

can connect up to 4 loudspeakers in parallel on each

channel of a standard 4Ω amplifier. For 100V use, the

loudspeaker is equipped with a high quality 60 Watt

transformer with several power taps. Further, the SDQ8T

is equipped with an auto-reset protection system. It

makes the SDQ8T loudspeaker very suitable for the

distribution of ambient background music or microphone

calls. The loudspeaker comes standard with a U-type

bracket. The SDQ8T loudspeakers can be used outdoor.

However, be aware of the fact that the loudspeaker

terminals are not protected, the fact that this is a bass

reflex housing and that the grill is made of plasticized

painted metal. This means direct exposure to rain must

be avoided.

Power Tappings

60 60 30 15 15 15

6 6

++ + + + + +207 Watt =

240 Watt Amplier

Amplier power must be higher than total power of all speakers.

Het versterkervermogen moet hoger zijn dan de som van de vermogens van de luidsprekers.

La puissance de l’amplicateur doit etre plus élevée que la puissance totale des haut parleurs.

100 Volt Technology

16 ohm Technology

16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω

4Ω 4Ω

Produkt Specifikationer

Mærke:	APart
Kategori:	Højttaler
Model:	SDQ8T-BL
Type:	I væggen/på væggen/i loftet højttalere
Vægt:	5450 g
Produktfarve:	Sort
Udgangseffekt (RMS):	140 W
Dimensioner (BxDxH):	280 x 240 x 485 mm
Materiale:	Plast
Frekvensområde:	45 - 20000 Hz
Impedens:	16 ohm (Ω)
Lyd-output kanaler:	2.0 kanaler
Diskanthøjttaler:	Ja
Peak Music-Udgangseffekt (PMPO):	180, 380 W
Diskant diameter:	30.5 mm
Woofer diameter:	203.2 mm
