Speakers with the Ashly touch.

Ashly Audio Inc.

847 Holt Road

Webster, NY USA

US toll-free

+1.585.872.0010

Fax

+1.585.872.0739

Sales@Ashly.com

www.Ashly.com

All other trademarks and registered trademarks are the property of their respective holders.

IS Series Dual-Impedance Column Speakers

ou may be thinking “

Does the

world need more speakers?

”

❚Yes, when Ashly speakers do things

others don’t. Hear us out.

❚And then hear how our AW on-wall

speakers, IS columns, and SP subwoofer

make beautiful music with our Protēa

and AquaControl

™

software.

SP 12.1PW

Subwoofer

Flush Mount

brackets

(included

with

IS 2.8Ps and

IS 3.8Ps)

IS-TWM

Tilt/Swivel

Mount for

IS 2.8Ps

and IS

3.8Ps

IS-JP2B Joining

Bracket shown on

two IS 2.8PWs

SP 12.1PB

Subwoofer

Thirty-two IS speakers

IS Series column speak-

ers have another exclu-

sive feature: in normal

mode, they’re rated at

8 Ω…but change the

Impedance Switch to 32

Ω and suddenly you can

power a whole facility

with quality sound using

one amp. Add Protēa or

AquaControl™ DSP and

you have an unbeatable

combination at a very

modest price.

Two

IS 2.8PWs

with IS-JP2

Joining

Bracket

IS-PM6B

Pole Mount

IS-PM6B

Pole Mount

IS-TR7B

Tripod

Mount

IS-PM1B

Pole Mount

4 x 400 W @ 4 Ω

Ashly nXp 4004, 8004,

or ne4250 4-channel

amplifier with Protēa

Eight IS columns • 32Ω setting @ 50W each Eight IS columns • 32Ω setting @ 50W each

Ashly nXp

or ne 4-channel

amplifier with

Protēa

4 x 250 W

8 Ω

Four IS columns

32Ω setting

@ 65.2W each

Four IS columns

32Ω setting

@ 62.5W each

Four IS columns

32Ω setting

@ 65.25W each

Four IS columns

32Ω setting

@ 65.2W each

*with DOC crossover and DSP presets for selected Ashly amps and processors.

All specifications are subject to change.

AW Series On-Wall Speakers

IS Series Dual-Ω Column Speakers + SP Subwoofer

AW 8.2T

AW 5.2P

IS 3.8PW

IS 2.8PIS 2.8PW IS 3.8P

AW 2.1P

Tilt Swivel

Bracket

included

AW 3.2T

IS and AW speakers will please

you with their performance and

price. But spec one of the Ashly

amps below and you get:

Only optimized linear

frequency response

and universal crossover

implementation is available on

ne24.24m (not shown).

Protēa & AquaControl DSP: Our speakers’ secret sauce.™

Ashly 2-way speaker with DOC* crossover and DSPTypical 2-way loudspeaker

Off-axis Response ± 30˚ AW Series Off-axis Response ± 30˚

Our AW series speakers are

perfect for restaurant patios,

balconies, and many other

under-eave

applications, as

well as indoors.

They deliver robust

bass, crisp treble and

accurate midrange that

makes them easily heard over table conversation, traffic

or wind noise. Impressive on their own, their sound can be

further enhanced with Ashly power amplifiers and proces-

sors that incorporate Protēa or AquaControl™ software (see

elow). Visit our web site to download

ec Sheets, A&E Specs, and dxf files.

100 1k 10k

100

So ressure, Lev el [dB ]und p

20 50 200 500 2k 5k 20k

100 1k 10k

100

So ressure, Lev el [dB]und p

20 50 200 500 2k 5k 20k

20 dB

9 B9 dB

❚Directivity-weighted, optimized

linear frequency response

❚Universal crossover

implementation for use with

subwoofer and full- range

speakers

❚FIR-corrected linear phase

response above about ~300 Hz

AW 2.1P AW 3.2P AW 5.2T

AW 8.2T

15 W @8 Ω 45 W @ 8 Ω 80 W @ 8 Ω 100 W @ 8 Ω

8 Ω 8 Ω

8 Ω or con-

stant voltage

8 Ω or constant

voltage

response

170-19 kHz

(-10 dB)*

100 Hz to

19 kHz (-10 dB)*

80 Hz to

19 kHz (-10 dB)*

65 Hz to

19 kHz (-10 dB)*

Transducer

2.75" full

range

1.1" PEI HF

3.5" LF

0.75" silk

dome HF

5.25" LF

1" silk dome HF

8" LF

IS column speakers are a

cost-effective way to provide

vertical pattern control, and

consistent sound levels front-

to-back of a venue… especially

when combined

with Ashly amps and

processors that

incorporate

Protēa or

AquaControl™

software (see

below).

They fit perfectly

next to flat-

screens in

conference

rooms. Combined

with an SP 8.1P

or SP 12.1P sub,

you can create an

effective "system

on a stick"

for churches,

wedding

receptions and

corporate events.

Two IS speakers can be joined

with an optional bracket. Pole

and tripod mounts are also

available. Visit our web site to

download Spec Sheets, A&E

Specs, dxf and EASE files.

Directivity Optimized Crossover (DOC) passive

crossover available on 2-way AW models only

2.8P

3.8P

8.1P

12.1P

Power

Handling

120 W @8 Ω

240 W @

8 Ω

150 W @ 8 Ω 350 W @ 8 Ω

Impedance

8 Ω / 32 Ω 8 Ω / 32 Ω 8 Ω 8 Ω

Frequency

response

115 Hz to

20 kHz

105 Hz to

19 kHz

43 Hz to

180 Hz

39 Hz to

180 Hz

Transducers

8 x

2.0" full

range

transducers

with

neodymium

magnet

8 x

3.0" full

range

transducers

with

neodymium

magnet

8" LF

transducer

ferrite

magnet

12” LF

transduce

ferrite

magnet

pēma series Protêa-enabled amps

ne4250pe and ne8250pe network-

enabled amplifiers with Protêa

mXa-1502 mix amp with AquaControl

ne series processors with Protēa

nXp series multi-mode with Protêa
