IS 2.8P

8 x 2-inch

column speakers

IS 3.8P

8 x 3-inch

column speakers

SP 12.1P

Twelve-inch subwoofer

SP 8.1P

Eight-inch subwoofer

IS-TR7B

Tripod mount for IS 2.8P or IS 3.8P

IS-PM1B

1 foot pole mount for SP subs

IS-PM6B

Pole mount for IS 2.8P or IS 3.8P + SP 12.1P

IS-TWM

Tilt wall mount for IS 2.8P or IS 3.8P

IS-FWM

Flush wall mount for IS 2.8P or IS 3.8P

IS-JP2

Joining bracket for two IS 2.8Ps or IS 3.8Ps

M10-SP

Fly bolts for SP 1.8P

Operating and

Installation Manual

IS-TWM IS-FWMIS-JP2

IS Series + SP Series Operating Manual

1. Heed all warnings; follow all instructions.

2. Refer all servicing to qualified personnel.

Servicing is required when the apparatus has

been damaged in any way.

Installation and Mounting

3. To prevent inductive effects from causing

hum and/or noise, loudspeaker lines should

not be laid together with other electric

cables, microphone or line level signal

cables connected to amplifier inputs.

4. To ensure proper sound reproduction,

correct loudspeaker polarity is necessary.

Check “+” and “−” polarity at both the

amplifiers and the IS Series speakers.

5. Make sure loudspeaker lines are not shorted

before turning the amplifier on.

6. The entire audio system must comply with

the current local standards and regulations

regarding electrical systems.

7. Ashly recommends this product only

be permanently installed by licensed,

professional installers (or specialized firms)

who can ensure a correct installation and

certified by a local inspector.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that

produce heat.

9. Use only with mounts or brackets specified

by Ashly Audio.

10. Check the suitability of the support surface

to which the product is anchored (wall,

ceiling, structure, etc.) and the attachment

components (wall plugs, screws, brackets

etc.) to confirm that they are in compliance

with requirements set forth by local building,

safety and electrical codes.

11. Make sure all connections have been made

correctly and the loudspeaker input voltage

is suitable for the amplifier output.

12. Protect loudspeaker lines from damage.

Make sure they are positioned in a way that

they cannot be stepped on or crushed by

objects.

13. Make sure that no objects or liquids can get

into this product, as this may cause a short

circuit.

14. Place the SP 8.P/SP 12.1P subwoofer on a

flat, rigid and anti-skid surface.

Pole, Tripod Mount, Joining Plate

15. Please use Ashly IS-TR7B tripod mount for

IS 2.8P and IS 3.8P speakers. If mounting

the speakers on top of the SP 8.1P or

SP12.1P subwoofer, use only the IS PM1B or

IS PM6B speaker poles.

16. When pole or tripod mounting IS column

speakers, make certain units are placed in a

safe and secure area which is free from foot

traffic or other activities which could cause

accidental tripping or stand collapse.

17. Open the mount’s three “legs” as wide as

possible to ensure its stability.

18. Tighten the height-adjustment bolt firmly.

19. Insert the safety pins on both the fixed and

extendable parts of the tripod or pole.

20. Make sure the the Ashly IS-JP2 accessory

joining plate used to connect to IS speakers

is securely attached.

21. When using two IS speakers joined by an IS-

JP2 vertical mounting plate, pay particular

attention to tripod placement. Confirm

that the tripod mounts’ three legs are fully

extended. Remember that the center

of gravity is higher than with a single IS

speaker.

22. For flying the SP8.1P: Use only the M10-

SP eye bolts. You should consult with a

licensed contractor prior to flying the

SP8.1P to ensure compliance with local

safety regulations. Also, do not hang other

speakers from a suspended SP8.1P. That will

exceed the load capacity.

Safety and Operation Precautions.

Operation

23. IS column line arrays can deliver high sound

pressure that can surpass 90 dB. Exposure

to high sound levels can cause permanent

hearing loss. Monitor and control the volume

at all times.

24. If amplifiers or other connected equipped

displays “clipping”, “peak”, or other overload

conditions, adjust to assure these are

operating below that threshold to prevent a

distorted signal, which may cause damage

to the speakers.

25. To avoid clipping, always use a clip limiter

if available. Always observe specified high

pass filtering recommendations; failure to

do so may result in damage to drivers.

26. Contact your authorized service center

or qualified personnel should any of the

following occur:

■ The loudspeaker does not function

normally

■ The cable has been damaged

■ Objects or liquids have gotten into the unit

■ The loudspeaker has been damaged due to

heavy impacts

2 7. Clean only with a dry cloth. Do not use

solvents, alcohol, benzene, or other volatile

substances for cleaning the external parts of

this product.

28. Don’t unplug signal cables when the amp

connected to your IS Series speakers is still

on.

29. Don’t remove the metal grille of the speaker,

which can cause damage to the speaker

cones.

30. Depending on the impedance switch setting

on the back of the IS speakers (8/32 ohms),

make sure to limit the number of connected

speakers to match the amplifier’s minimum

safe operating impedance. Please refer to

the Ashly amplifiers operations manual for

the correct settings and speaker count.
