Dear customer!
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfi l your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
Instructions for use
REFRIGERATOR
R22838W
R22838S
R2283W
R2283S
R2283B
2
REFRIGERATOR
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at
temperatures above 0°C.
EU EPREL database
Information about your product can be found at www.
asko.com/energylabel, where you will also fi nd a link to
the European Product Database for Energy Labelling,
EPREL. Or else visit https:// eprel.ec.europa.eu directly.
Follow the instructions to search by model name (see
the information on the serial number plate).
3
IMPORTANT NOTES AND PRECAUTIONS 4
Before using the appliance for the fi rst time 4
Important safety instructions 5
Important information on the use of appliance 7
ADVICE FOR SAVING POWER WITH
REFRIGERATION APPLIANCES 9
APPLIANCE DESCRIPTION 10
INSTALLATION AND CONNECTION 11
Selecting the room 11
Installing the appliance 11
Connecting the appliance 12
CHANGING THE DIRECTION OF DOOR
OPENING 13
OPERATING OF THE APPLIANCE 14
Switching the appliance on/off 14
Adjusting the temperature 14
Refrigerator boost 14
APPLIANCE INTERIOR EQUIPMENT 15
Shelf 15
Wire bottle rack* 15
Fruit and vegetable bin with humidity control 15
Interior side of the refrigerator door 15
Adjustable door bins 15
Storage bin (MultiBox) 16
Fan* 16
Ionizer (IonAir)* 16
Adaptive Intelligent Technology 16
RECOMMENDED DISTRIBUTION OF
FOOD IN THE APPLIANCE 17
Recommended distribution of food in the appliance 17
STORING FOOD IN THE REFRIGERATOR 18
Important warnings regarding food storage 18
Avoid contamination of food 18
Food storage times 18
STORING FOOD IN THE FRESHZONE
DRAWER 19
DEFROSTING THE APPLIANCE 20
Automatic refrigerator defrosting 20
CLEANING THE APPLIANCE 21
TROUBLESHOOTING 22
INFORMATION ABOUT APPLIANCE
NOISE 23
TABLE OF CONTENS
4
Spacers are fi tted on the corners of
the doors. Remove them and insert
the supplied plugs into their slots
(only in some models).
Before using the appliance for the fi rst time
Before connecting the appliance to the power mains, please read carefully the
instructions for use which describe the appliance and its correct and safe use.
The instructions apply to several appliance types/models; thus, settings or
equipment may be described herein which is not available in your appliance.
We recommend saving this instruction manual for future reference and attach it
to the appliance if it is sold in the future.
Check for any damage or irregularities on your appliance. If you fi nd your
appliance is damaged, notify the retailer from which you have purchased the
appliance.
Before connecting the appliance to the power mains, let the appliance rest in
a vertical position for a minimum of 2 hours. This will reduce the possibility of
operation faults due to the eff ect of transport on the cooling system.
IMPORTANT NOTES AND PRECAUTIONS
5
Important safety instructions
WARNING! Risk of fi re/fl ammable materials.
The appliance must be connected to the power mains and grounded in
compliance with the eff ective standards and regulations.
WARNING! Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power mains (unplug the
power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualifi ed persons in order to avoid a
hazard.
WARNING! When positioning the appliance, ensure the supply cord is not
trapped or damaged.
If LED lighting does not work, call a service technician. Do not attempt a repair
of the LED lighting yourself, as there is danger of contact with high voltage!
WARNING! Do not use any electric devices inside the appliance, except for
those allowed by the manufacturer of this refrigeration appliance.
WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor stability of the appliance,
make sure it is installed as instructed.
6
Danger of frostbite
Never put frozen food in your mouth and avoid touching frozen food as this
may cause frostnip or frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Cleaning and user maintenance shall not be made by children without
supervision.
Remove the packaging intended to protect the appliance or particular parts
during transport and keep it outside the reach of children.
It presents danger of injury or suff ocation.
For European markets only
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an environmentally friendly yet
fl ammable gas R600a. Make sure that no parts of the cooling system are
damaged. A gas leak is not hazardous to the environment, but it could cause
eye injury or fi re.
7
In case of a gas leak, ventilate the room thoroughly, disconnect the appliance
from the power mains, and call a service technician.
Important information on the use of appliance
WARNING! This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offi ces and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
WARNING! Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
The appliance may not be used outdoors and it may not be exposed to rain.
Do not store explosive substances such as aerosol cans with a fl ammable
propellant in this appliance.
If the appliance will be out of use for an extended period of time, switch it
off using the relevant button, and unplug it from the power mains. Empty the
appliance, defrost it, clean it, and leave the door ajar.
In case of an error or power supply failure, do not open the freezer
compartment unless the freezer has not operated for over 16 hours. After this
period, use the frozen food or provide suffi cient cooling (e.g. a replacement
appliance).
Technical information on the appliance
Rating plate can be found in the appliance interior. It indicates data on voltage,
gross and net volume, type and amount of refrigerant, and information on the
climate classes.
If the language on the rating plate is not the language of your choice or the
language of your country, replace it with the one supplied.
8
Environment protection
Packaging is made of environmentally friendly materials that can be recycled,
disposed of, or destroyed without any hazard to the environment.
Removing an obsolete appliance
To protect the environment, take the obsolete appliance to an authorized home
appliance collection centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
WARNING! Do not damage the refrigerant circuit. This will also prevent
pollution.
The symbol on the product or its packaging indicates that the product should not be treated as normal
household waste. The product should be taken to an authorized collection centre for waste electric and
electronic equipment processing. Correct disposal of the product will help prevent any negative eff ects
on the environment and health of people which could occur in case of incorrect product removal. For detailed
information on removal and processing of the product, please contact the relevant municipal body in charge
of waste management, your waste disposal service, or the store where you bought the product.
9
• Install the appliance as specifi ed in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).
• If the gasket is damaged or does not provide a perfect seal for other reasons, have it replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the appliance, cool it to room temperature.
• Defrost frozen food in the refrigerator compartment.
• Remove the drawers from the freezer compartment as described in the instruction manual, in order to make use of the
entire interior.
• Defrost your conventional freezer when an approximately 3-5 milimeter layer of of frost or ice has built up on the
refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that the food is placed so that the air can freely
circulate in the appliance interior (observe the recommended placement of food as described in the instructions).
• In appliances with a fan, do not block the fan slots.
• If you do not need the fan or the ionizer, switch them off to reduce power consumption.
ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES
10
1
3
4
2
9
5
6
12 12
7
8
10
11
1 Control unit
2 Led lighting of refrigerator interior
3 Fan with air ionizer (+ on/off switch)
4 Bottle rack
5 Pull-out glass shelf (height adjustable)
6 FreshZone drawer
7 CrispZone fruit and vegetables drawer
with humidity control
8 Fruit and vegetables drawer
9 SimpleSlide height-adjustable door bin
10 Multibox storage bin
11 Bottle bin
12 Foot
• Appliance interior equipment may change according to the appliance model.
• The drawers are protected against pulling out. To remove a drawer from the appliance, open it, then lift the front part
and pull it out.
APPLIANCE DESCRIPTION
11
Selecting the room
• Install the appliance in a dry and well ventilated
room. The appliance will operate correctly if the
environment temperature is in the interval specifi ed
in the table. The appliance class is indicated on the
rating plate / label with the basic information on the
appliance.
• This appliance is not intended to be used as a build-in
appliance.
Description Class
Ambient
temperature
range °C
Relative
humidity
Extended
temperate SN +10 to +32
≤ 75%Temperate N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
WARNING!
Make sure the room where the appliance is
installed is large enough. There should be at
least 1 m3 of space per 8 grams of refrigerant.
Amount of refrigerant is stated on the rating plate
in the appliance interior.
Installing the appliance
Appliance installation should be carried out by at least
two persons to avoid any physical injury or damage to
the appliance.
• The appliance must stand level and stable on a
solid base. At the front, the appliance is fi tted with
two adjustable legs that can be used to level the
appliance. At the rear side, casters allow for easier
installation of the appliance (only with some models).
• There should be a clearance of at least 5 cm between
the appliance and any cupboard installed above it, in
order to allow adequate cooling of the condenser unit.
• The appliance is supplied with two spacers which
should be installed on the lower part of the housing
to prevent from pushing the appliance too close to
the wall. Appliance may also be installed without
the spacers; however, this may increase power
consumption.
• Do not expose the appliance to direct sunlight and do
not place it near any source of heat. If this cannot be
avoided, install an insulation panel.
• The appliance may stand alone or it may be placed
ext to a cupboard or a wall. Consider the clearance
required to fully open the door in order to allow
pulling out the drawers and shelves (see installation
diagram).
INSTALLATION AND CONNECTION
12
Note: When placing the appliances side by side, the
anti-dew (anti-condensation) set has to be purchased
and installed!
Code for ordering the set:
– appliances with a height of 1850 mm: 576604.
Connecting the appliance
• Connect the appliance to the power mains using a
connection cable. The wall outlet should be fi tted with
a ground contact (safety socket). Nominal voltage and
frequency are indicated on the rating plate/label with
basic information on the appliance.
• The appliance must be connected to the power
mains and grounded in compliance with the eff ective
standards and regulations. The appliance will
withstand short-term deviations from the nominal
voltage, but not more than +/- 6%.
13
Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, fl at screwdriver
The procedure to change the direction of door opening should be carried out by at least two persons.
1. Remove the upper hinge cover (A) and the covering cap (G).
2. Undo the upper hinge (B) and remove the door (C) from the lower hinge (D).
3. Tilt the appliance backwards (make sure you do not press against the condenser unit on the rear wall of the
appliance as this may damage the cooling system), unscrew the lower hinge (D) and the foot (E), and move them to
the opposite side. Make sure the washer is installed like it was before disassembly.
4. Move the door hinges (F) to the opposite side, remove the door stopper S1 and attach the door stopper S2 supplied
in a bag with the instruction manual. Replace the door (C) back on the lower hinge (D).
5. Use the screws to attach the upper hinge (B) on the opposite side.
6. Replace the upper hinge cover (A) and the covering cap (G) on the opposite side.
7. Replace the handle (L): undo the side screws (M) and the (N) screw in the handle holder. Take care not to damage
the door. Pull the handle in the direction of the arrow Disassemble the handle (L): undo the screw (O), turn the
handle holder (P) by 180° and reattach it using the screw. On the opposite side of the door, remove the cover
plugs (R) and replace the handle (L) in the direction of the arrow 2. Reattach the handle using the screws (M) and (N).
Place the covering plugs/caps (R) on the opposite side of the door.
7
7
7
77
L
L
M
NP
R
1
1
1
112
2
2
22
3
3
3
33
D
E
E
6
6
6
66
A
G
B
C
F
F
G
A
D
4
4
4
44
C
D
C
G
B
5
5
5
55
S1
S2
CHANGING THE DIRECTION OF DOOR OPENING
16
Storage bin (MultiBox)
• MultiBox bin off ers a convenient way for storing food
with a strong or pungent smell, e.g. ripened or blue-
vein cheese, sausages, onions, butter etc.
• The silicone lid provides an air-tight seal that prevents
the food from drying out and the odour to spread
throughout the refrigerator compartment.
• The silicon lid can also be used as an egg or ice tray.
• If the fl exible lid is used as an egg tray, place it directly
on the bottom of the door bin and use the open
lower part of the Multibox bin to store food in smaller
packages – pâté, jams, smaller tubes etc.
Fan*
• The fan placed under the refrigerator compartment
ceiling or hidden in the freezer unit will make sure the
temperature is distributed more evenly and reduce
condensation (dew) on the storage surfaces.
Ionizer (IonAir)*
• Air ionizer placed in the refrigerator compartment
removes most bacteria, viruses, gases, and
unpleasant odours to make sure the air in the
refrigerator is always fresh. The food will remain fresh
and tasty longer.
• Air ionizer can be switched on and off using the
switch located on the fan housing or on the side of the
cooling tower (depending on the model).
Switching the ionizer on/off
ON = I 0OFF =
When the ionizer is switched on, a red dot will be visible
on the switch.
Adaptive Intelligent Technology
Innovative sensor technology allows adjusting appliance
operation to the user's habits or behaviour. Adaptive
intelligent system monitors, analyzes, and records on
weekly basis the use of appliance and adapts appliance
operation to the perceived patterns. If the appliance is
able to anticipate increased frequency of door opening,
the appliance will automatically lower the temperature
before such time to reduce heating of the food as the
door is opened more often.
17
Recommended distribution of food in the
appliance
Sections of the refrigerator:
- canned food, bread, wine, pastry etc.upper part:
- dairy products, ready-made meals, middle part:
desserts, soft drinks, beer, cooked food, etc.
- Fresh bin: - meat, meat produce, delicatessen;
- Fruit and vegetable bin: fresh fruit, vegetables,
salads, root vegetables, potatoes, onions, garlic,
tomatoes, tropical fruit, sauerkraut, turnips etc.
Sections in the refrigerator compartment door:
- eggs, butter, cheese etc.upper/middle door bins:
- lower door bins: beverages, cans, bottles etc.
RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE
18
Important warnings regarding food storage
WARNING!
Correct use of the appliance, appropriate
packaging, maintaining the right temperature,
and observing the food hygiene standards has a
decisive impact on the quality of food storage.
Observe the expiry dates for the food, specifi ed
on the packaging.
Food stored in the refrigerator should be kept in
closed containers or appropriate packaging to
prevent them from emitting or receiving odours.
Do not store infl ammable, volatile, and explosive
substances in the refrigerator.
Bottles with high alcohol content should be
tightly sealed and stored in an upright position.
Some organic solutions, essential oils in lemon
and orange peel, butter acid, etc. may damage
the plastic surfaces in case of a prolonged
contact, causing damage and premature ageing
of these materials.
Unpleasant odour warns of lacking cleanliness of
the appliance or perished contents (see Cleaning
the Appliance).
If you are leaving home for a longer period of
time, remove perishables from the refrigerator.
Avoid contamination of food
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signifi cant increase of the temperature in the
compartments of the appliance.
• Regularly clean surfaces that can come in contact
with food and accessible drainage systems.
• Store raw meat and fi sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
• If the refrigerating appliance is left empty for long
periods, switch off , defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
Food storage times
Recommended storage time in the refrigerator
Type of food Time
eggs, marinades, smoked meat up to 10 days
cheese up to 10 days
root vegetables up to 8 days
butter up to 7 days
deserts, fruit, ready-to-eat
food, chunks of raw meat up to 2 days
fi sh, raw minced meat, seafood up to 1 day
STORING FOOD IN THE REFRIGERATOR
22
Problem: Cause or remedy:
Appliance is connected to the
power mains but it does not work:
• Make sure there is voltage in the power outlet and that the appliance is switched
on.
Cooling system operates
continuously for a long period of
time:
• Too high environment temperature.
• Door opened too frequently or too long.
• Door not closed correctly (possible impurities on the seal, misaligned door,
damaged seal etc.).
• Too much fresh food inserted at once.
• Sensor in the refrigerator (A) blocked by fresh food. Make sure the air can
circulate around the sensor (only with some models).
• Insuffi cient compressor and condenser cooling. Check the air circulation behind
the appliance and clean the condenser unit.
Excessive build-up of ice on the
back wall of refrigerator interior
can be a result of the following:
• Door opened too frequently or too long.
• Warm food placed in the refrigerator.
• Food in contact with the back interior wall of the refrigerator.
• Poor door sealing.
If the seal is dirty or damaged, clean it or replace it.
Condensate (dew) on the shelf
above the drawers:
• This is a transient phenomenon which cannot be entirely avoided in periods of high
environment temperature and humidity. It subsides when temperature and
humidity are normalized. We recommend cleaning the drawers more frequently
and wiping the droplets occasionally.
• Place the food in to bags or other airtight packaging.
Water leaking from the
refrigerator:
• Clogged water discharge opening or water dripping past the water gutter.
• Clean the clogged opening, for example using a plastic straw.
• If a thick layer of ice builds up, defrost the appliance manually (see Defrosting the
Appliance).
Door is diffi cult to open: • If you are trying to open the appliance door after just having closed it, this could be
diffi cult to do.
As you open the door, some cool air escapes from the appliance and it is replaced
by warm air from the environment. When this air is cooled, negative pressure is
generated which results in problems as you try to open the door. After a few
minutes, the condition is normalized and the door can be easily opened again.
LED lighting does not work: • If LED lighting does not work, call a service technician.
• Do not attempt a repair of the LED lighting yourself, as there is danger of contact
with high voltage!
If none of the instructions above fi xes your problem, call the nearest authorized service center and state the type,
model, and serial number found on the rating plate/label which is located in the appliance interior.
TROUBLESHOOTING
Produkt Specifikationer
| Mærke: | Asko |
| Kategori: | Køleskab |
| Model: | R2283W |
Har du brug for hjælp?
Hvis du har brug for hjælp til Asko R2283W stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleskab Asko Manualer
30 Juli 2025
8 Januar 2025
14 September 2024
31 August 2024
30 August 2024
30 August 2024
29 August 2024
29 August 2024
29 August 2024
29 August 2024
Køleskab Manualer
- Kunft
- Schneider
- Matrix
- Junker
- Cool Head
- Optimum
- SilverCrest
- Neff
- CaterCool
- Eta
- Frilec
- Severin
- RCA
- Electroline
- Structural Concepts
Nyeste Køleskab Manualer
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
6 August 2025
