Asrock B150M Pro4 Manual

Asrock Bundkort B150M Pro4

Læs gratis den danske manual til Asrock B150M Pro4 (74 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 32 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 16.5 anmeldelser. Har du et spørgsmål om Asrock B150M Pro4, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/74

Version 1.0

Published June 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Produkt Specifikationer

Mærke:	Asrock
Kategori:	Bundkort
Model:	B150M Pro4
Bredde:	244 mm
Dybde:	244 mm
Antal HDMI-porte:	1
HDCP:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	4
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Lyd-output kanaler:	7.1 kanaler
Certificering:	- FCC, CE, WHQL\n- ErP/EuP ready (ErP/EuP ready power supply is required)
Strømkilde type:	ATX
Bæredygtighedscertifikater:	RoHS
Maksimal intern hukommelse:	64 GB
Mikrofonindgang:	Ja
Intel® Turbo Boost Teknologi:	2.0
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
USB-stik type:	USB Type-A
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Antal PS/2-porte:	1
Processor sokkel:	LGA 1151 (stik H4)
Intel® Mindre Forretnings-fordele (Intel® SBA):	Ja
Understøttelse af parallel behandlingsteknologi:	2-Way CrossFireX, Quad-GPU CrossFireX
Kompatibel processor serie:	Intel Celeron, Intel Pentium
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® B150
Lydchip:	Realtek ALC892
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Ikke-fejlkorrigerende kode:	Ja
Understøttede hukommelsesclock-hastigheder:	2133 MHz
Ikke-bufferet hukommelse:	Ja
Antal SATA III-stik:	6
LAN Kontroller:	Intel® I219-V
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	1
USB 3.2 Gen 1 (3.1 Gen 1) stik:	1
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Indbrudsttik til kabinet:	Ja
Antal kabinetventilatorstik:	2
Lydstik på frontpanel:	Ja
Antal DVI-D-porte:	1
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	SATA III
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	16 Mbit
ACPI-version:	5.0
Wake-on-LAN klar:	Ja
Intel® Small Business Advantage (SBA) version:	4.0
PCI Ekspres x1 (Gen 3.x) slots:	2
PCI Ekspres x16 (Gen 3.x) slots:	2
TPM-stik:	Ja
Intel® ekstrem hukommelse profil (XMP):	Ja
Diskret grafik support:	Ja
Intel® Core i3/i5/i7/i9 serie:	i3-6xxx, i5-6xxx, i7-6xxx
