Weather Proof Cover - OP5GY24
Weather Proof Cover - 5x5, 24" Double-Gang Hinge Top Pedestal, Gray
Item OP5GY24
PRODUCT DESCRIPTION
Provides convenient access to power in shared spaces with a heavy-duty power pedestal from Intermatic. These easy-to-install,
low-maintenance cULus 1773 approved solutions are built of heavy gauge 304L stainless steel with 14 GA uprights, powder-
coated and designed to withstand the harshest outdoor environments. Each power pedestal includes a self-closing, lockable
cover for added security. Ideal for retrofit and new construction applications, they’re a simple way to support everyday power
needs (e.g., phone charging) and facility operations (e.g., holiday lighting).
FEATURES
OP5XXXX Double-Gang Pedestals require a selection of an MPXXXXX Device Mounting Plate that meets
your application needs. (Order Separately)
Welded construction, built of heavy gauge 304L stainless steel with 14 GA uprights, powder-coated and
designed to withstand the harshest outdoor environments.
Welded construction, built of heavy gauge 304L stainless steel with 14 GA uprights, powder-coated and
designed to withstand the harshest outdoor environments.
Designed for quick and easy installation and low maintenance.
Model accommodates 20 A to 60 A devices.
Secure - in-use, tamper-resistant with self-closing reinforced hinge-top and hasp accepting up to 1/4"
lock.
APPLICATIONS
Power Pedestals
TECHNICAL DATA
General
Model Number OP5GY24
Description 5x5, 24" Double-Gang Hinge Top Pedestal, Gray
UPC Code 078275158054
Brand Intermatic
Country of Origin (Intermatic) CANADA
Warranty Period 2-Year limited
Mechanical Specifications
Hinge Direction Vertical
Base Surface Mount
Device Type Mounting Plate Order separately - See accessories on product page
Mounting Plate Included No
Ground Wire Max 4 GA Copper Solid
Ground Wire Min 14 GA Copper Solid
Number of Gangs Double
Max Load 20 A; 30-60 A (must be water-tight)
Pedestal Type Hinge-Top
Dimensions
Lockable Hasp Maximum Diameter (in) 0.25
Lockable Hasp Maximum Diameter (mm) 6.35
Product Dimensions (H x W x D) in 24 x 2.8 x 6.375 in
Pedestal Height 24"
1/
Technical specifications and other information are subject to change without notice. Images can vary from original.
