Side 1/36

Motherboard

PRIME B560M-A AC

E18676

First Edition

July 2021

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Produkt Specifikationer

Mærke:	Asus
Kategori:	Bundkort
Model:	Prime B560M-A AC
Bredde:	244 mm
Dybde:	234 mm
Wi-Fi:	Ja
Bluetooth:	Ja
Antal HDMI-porte:	2
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	4
Udgange til hovedtelefoner:	3
Ethernet LAN:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Maksimal opløsning:	4096 x 2304 pixel
Kabler inkluderet:	SATA
Bluetooth-version:	5.0
Lyd-output kanaler:	7.1 kanaler
Bedste Wi-Fi standard:	Wi-Fi 5 (802.11ac)
Maksimal intern hukommelse:	128 GB
Mikrofonindgang:	Ja
Understøttede Windows-operativsystemer:	Windows 10 x64
Processorproducent:	Intel
Drivere inkluderet:	Ja
HDMI-version:	1.4/2.0
DisplayPort-version:	1.4
Antal DisplayPorts:	1
USB-stik type:	USB Type-A, USB Type-C
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Understøttet datalagringsdrev typer:	HDD & SSD
Antal understøttede lagerdiske:	8
Antal PS/2-porte:	1
Processor sokkel:	LGA 1200 (Socket H5)
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
Kompatibel processor serie:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel B560
Lydchip:	Realtek ALC897
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	2133,2400,2666,2800,2933,3200,3333,3466,3600,3733,4000,4266,4400,4600,4800,5000 MHz
Ikke-bufferet hukommelse:	Ja
Antal M.2 (M) slots:	2
Antal SATA III-stik:	6
LAN Kontroller:	Intel® I219-V
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	2
S/PDIF-udgangsstik:	Ja
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Antal kabinetventilatorstik:	2
Lydstik på frontpanel:	Ja
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	M.2, PCI Express 3.0, PCI Express 4.0, SATA III
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	128 Mbit
Nulstil CMOS-jumper:	Ja
Wake-on-LAN klar:	Ja
Understøttede procesorsokler:	LGA 1200 (Socket H5)
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte:	1
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte:	1
PCI Ekspres x1 (Gen 3.x) slots:	1
PCI Ekspres x16 (Gen 3.x) slots:	1
TPM-stik:	Ja
EPS strømstik (8-pin):	Ja
PCI Express x16 (Gen 4.x) slots:	1
12V strømstik:	Ja
Header med RGB-LED-ben:	Ja
WiFi-AP antenne stik:	1
