ASMB-789 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x Startup manual

• 2 x Serial ATA HDD data cables

• 2 x Serial ATA HDD power cables

• 1 x I/O port bracket

• 1 x Warranty card

• 1 x Screw for M.2 device

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

Standard Functions

ASMB-789 LGA 1851 Intel® Core™ Ultra 9/7/5

Processor ATX Server Board with 4 x DDR5, 6 x PCIe,

8 x USB 3.2, 4 x SATA3, Quad/Dual LANs, and IPMI

Startup Manual

• CPU: LGA 1851 Intel® Core™ Ultra 9/7/5 Processors

• BIOS: AMI 256 Mb SPI BIOS

• Chipset: Intel W880

• System memory: Dual Channel DDR5 ECC/Non-ECC

5600/4800/4000MHzunbu󰀨eredDIMM,Max.192GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 192 GB RAM

when 192 GB RAM is installed.

• SATA3 interface: 4 x SATA3 6Gb/s ports to support Intel

Rapid Storage Technology with software RAID 0, 1, 10, &

5 (for Windows only)

• Serial ports: Six serial ports onboard, only support RS-

232 (1 x inserted in rear I/O)

• Watchdog timer: 255 level timer intervals (sec/min)

• USB 3.2: Supports up to 8 x USB 3.2 ports, 4 x Gen2

ports in rear I/O, 2 x Gen1 ports from on-board pin

header, and 1 x Gen1 port from on-board Type-A con-

nector and add 1 x Gen 2 x 2 link from on-board Type-E

connector.

• USB 2.0: Supports up to 5 x USB 2.0 ports (1 x Type-A)

Display Interface

• Chipset: CPU integrated Intel HD graphics controller

• Display memory: 1 GB maximum shared memory with

2 GB and above system memory installed (BIOS default

is 256 MB)

• Resolution:

- Supports VGA up to 1920x1200 resolution @60 Hz

refresh rate

- Supports DP with DSC to 8K60 Hz 36bpp

- Supports HDMI 2.1 TMDS up to 2K/4K resolution @60

Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000/2500 Mbps

• Controller: GbE LAN1: Intel® I219; GbE LAN2: Intel®

I210-AT ; GbE LAN 3~4: Intel® I226;

(LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU only)

Mechanical and Environmental

• Dimensions (L x W): 244 x 304 mm (9.6 x 12 in)

• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 VSB

• Power consumption: Max. load: +3.3 V @ 2.05 A, +5 V

@1.69 A, +12 V @ 0.36 A, +12 V (8P) @ 13 A, +5 VSB

@ 0.10 A

• Operating temperature: 0 ~ 60°C; 32 ~ 140°F (depends

on CPU speed and cooler solution)

• Weight: 0.5 kg;1.1 lb (weight of board)

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-789 at:

https://advt.ch/asmb789

extra warranty for FREE at:

http://www.register.advantech.com

This manual is for the ASMB-789 series Rev. A1.

Part No. 2042078900

Printed in China

1st Edition

October 2025

Packing List Specications
