Side 1/88

PRIME /

ProArt /

TUF GAMING

Intel 600

Series

BIOS Manual

Motherboard

PRIME / ProArt / TUF GAMING Intel 600 Series BIOS Manual

E19474

First Edition

December 2021

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by

any means, except documentation kept by the purchaser for backup purposes, without the express

written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM

ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN

THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Produkt Specifikationer

Mærke:	Asus
Kategori:	Bundkort
Model:	PRIME Z690-P D4
Bredde:	305 mm
Dybde:	234 mm
Højde:	68 mm
Vægt:	1020 g
Wi-Fi:	Ingen
Bluetooth:	Ingen
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Kabler inkluderet:	SATA
Lyd-output kanaler:	7.1 kanaler
Harmoniseret systemkode (HS):	84733020
Maksimal intern hukommelse:	128 GB
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ja
Understøttede Windows-operativsystemer:	Windows 10, Windows 11
Processorproducent:	Intel
Drivere inkluderet:	Ja
HDMI-version:	2.1
DisplayPort-version:	1.4
Antal DisplayPorts:	1
Ethernet-grænsefladetype:	2.5 Gigabit Ethernet
Komponent til:	PC
Understøttet datalagringsdrev typer:	HDD & SSD
Perifere (Molex) strømstik (4-pin):	1
Antal PS/2-porte:	1
Processor sokkel:	LGA 1700
Understøtter RAID:	Ja
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
Kompatibel processor serie:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium G
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel Z690
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	2133,2400,2666,2800,2933,3000,3200,3333,3400,3466,3600,3733,3866,4000,4133,4266,4400,4600,4800,5000,5133,5333 MHz
Ikke-bufferet hukommelse:	Ja
Antal M.2 (M) slots:	3
Antal SATA III-stik:	4
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	2
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Antal kabinetventilatorstik:	3
Lydstik på frontpanel:	Ja
Motherboard form faktor:	ATX
Understøttede lagerdrev brugerflader:	M.2, SATA
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	192 Mbit
RAID-niveauer:	0, 1,5, 10
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte:	1
Strømstik til ventilator:	Ja
PCI Ekspres x1 (Gen 3.x) slots:	1
PCI Ekspres x16 (Gen 3.x) slots:	2
EPS strømstik (8-pin):	Ja
PCI Express x16 (Gen 4.x) slots:	1
USB 3.2 Gen 2 (3.1 Gen 2) -stik:	1
12V strømstik:	Ja
Header med RGB-LED-ben:	Ja
Thunderbolt-headere:	1
Antal USB 3.2 Gen 2x2 type-C-porte:	1
