Asus Pro WS W480-ACE Manual

Asus Bundkort Pro WS W480-ACE

Læs gratis den danske manual til Asus Pro WS W480-ACE (348 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Asus Pro WS W480-ACE, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/348

ASUS Control Center

Express

User Manual

Version: 01.05

E22036

Revised Edition V5

September 2023

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but

not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.

In no event shall ASUS, its directors, officers, employees, or agents be liable for any indirect, special,

incidental, or consequential damages (including damages for loss of profits, loss of business, loss of use

or data, interruption of business and the like), even if ASUS has been advised of the possibility of such

damages arising from any defect or error in this manual or product.

Specifications and information contained in this manual are furnished for informational use only, and are

subject to change at any time without notice, and should not be construed as a commitment by ASUS.

ASUS assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual,

including the products and software described in it.

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Produkt Specifikationer

Mærke:	Asus
Kategori:	Bundkort
Model:	Pro WS W480-ACE
Bredde:	305 mm
Dybde:	234 mm
Wi-Fi:	Ingen
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Maksimal opløsning:	4096 x 2304 pixel
Kabler inkluderet:	SATA
Lyd-output kanaler:	8.0 kanaler
Harmoniseret systemkode (HS):	84733020
Maksimal intern hukommelse:	128 GB
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ja
Understøttede Windows-operativsystemer:	Windows 10 x64
Processorproducent:	Intel
HDMI-version:	1.4b
DisplayPort-version:	1.4
Antal DisplayPorts:	2
Ethernet-grænsefladetype:	2.5 Gigabit Ethernet
Komponent til:	PC
Understøttet datalagringsdrev typer:	HDD & SSD
Processor sokkel:	LGA 1200 (Socket H5)
Understøttelse af parallel behandlingsteknologi:	3-Way CrossFireX
Kompatibel processor serie:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium, Intel Xeon
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel W480
Lydchip:	SupremeFX S1220A
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	2133,2400,2600,2800,2933,3000,3200,3300,3333,3400,3466,3600,3733,3866,4000,4133,4266,4400,4500,4600,4800 MHz
Ikke-bufferet hukommelse:	Ja
Antal M.2 (M) slots:	2
Antal SATA III-stik:	6
LAN Kontroller:	Intel I225-LM, Realtek RTL8117
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	1
CPU-ventilatorstik:	Ja
ATX strømstrik (24 stikben):	Ja
Anal EATX-strømstik:	1
Antal kabinetventilatorstik:	3
Lydstik på frontpanel:	Ja
Motherboard form faktor:	ATX
Understøttede lagerdrev brugerflader:	M.2, SATA III
BIOS-type:	UEFI AMI
BIOS-hukommelsesstørrelse:	128 Mbit
Nulstil CMOS-jumper:	Ja
RAID-niveauer:	0, 1,5, 10
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte:	4
PCI Ekspres x1 (Gen 3.x) slots:	2
PCI Ekspres x16 (Gen 3.x) slots:	3
Antal Thunderbolt-porte:	2
EPS strømstik (8-pin):	Ja
USB 3.2 Gen 2 (3.1 Gen 2) -stik:	1
Thunderbolt-headere:	1
