Installation Guide

AT-AVA-EX70-KIT

4K/UHD HDMI Extender Kit with Remote Power

AT-AVA-EX70-KIT

The Atlona AT-AVA-EX70-KIT is an Avance™ Series HDBaseT extender kit with remote power

for transmitting 4K/UHD 60Hz 4:2:0 video up to 130 feet (40 meters) or 1080p 60Hz video up to

230 feet (70 meters). In addition to video with embedded multi-channel audio signals, remote

power is provided from the transmitter to the receiver on the single CAT6A/7 cable. Integrated

HDBaseT link status testing allows quick verication of cable, termination, and link quality. HDMI

clock stretching and EDID ltering are included to ensure the integrity of video transmission as

well as compatibility with the widest array of sources and display devices. The AT-AVA-EX70-KIT

includes both transmitter and receiver endpoints. Compact enclosures and included brackets

allow the devices to be surface mounted in furniture or behind a display. The AT-AVA-EX70-KIT

delivers a cost-eective solution for extension of video, audio, and receiver power at resolutions

up to 4K/UHD.

IMPORTANT: Visit https://atlona.com/product/AT-AVA-EX70-KIT for the latest rmware

updates and Installation Guide.

1 x AT-AVA-EX70-TX

1 x AT-AVA-EX70-RX

1 x 2-pin captive screw connector

4 x Mounting brackets

8 x Mounting screws

1 x 48V DC power supply

1 x IEC cable

1 x Installation Guide

Package Contents

Installation Guide

AT-AVA-EX70-KIT

HDBaseT IN HDMI OUT

AT-AVA-EX70-RX

PWR

LINKFW

DC 48V HDBaseT OUT HDMI IN

AT-AVA-EX70-TX

PWR

LINKFW

TEST

Panel Descriptions

1 TEST

Quick and easy test for category cables.

Use the button to start the test and the

LED to determine pass or fail.

2 FW

Connect a micro-USB to USB-A type

cable from this port to a computer, to

update the rmware.

3 POWER and LINK LEDs

The power LED will illuminate green when

receiving power. The link LED will glow

yellow when signal is being sent/received

between the transmitter and the receiver.

4 DC 48V

Connect the included power supply to this

port.

5 HDBaseT OUT

Connect an HDBaseT cable from this port

to the port on the receiver.HDBaseT IN

6 HDMI IN

Connect an HDMI cable from a source to

this port. e.g. HDR BluRay Player

7 FW

Not used at this time.

8 POWER and LINK LEDs

The power LED will illuminate green when

receiving power. The link LED will glow

yellow when signal is being sent/received

between the transmitter and the receiver.

9 HDBaseT IN

Connect an HDBaseT cable from this

port to the port on the HDBaseT OUT

transmitter.

10 HDMI OUT

Connect an HDMI cable from this port to

an HDMI display.

5 6 10

83 721
