Side 1/4
Oasis 6T
Please read the manual before using the product
USER´S
MANUAL
3
Oasis 6T
Example of 70V/100V System Configuration
5 Speakers Connected in Parallel Using 16W Taps
NOTE: The total number of speakers multiplied by the tap value cannot exceed the
output power (in watts) of the 70V/100V amplifier. The above example shows 5 total
speakers. Using the 16W taps, you will need an amplifier with at least (5) x (16) =
80W. A good rule of thumb is to select an amplifier with 20% greater power; in
this case, an amplifier that delivers about 100W.
Underpowering Vs. Overpowering
Technial Specifications
2-CHANNEL AMPLIFIER WITH 8Ω OUTPUT
Observe correct polarity for maximum bass performance.
2 Speakers Per Channel Connected in Parallel
70V/100V
8Ω
8Ω
MODEL
Oasis 6T
Woofer Cone
Polypropylene
Woofer Diameter
6.5"
Tweeter Dome
Titanium
Tweeter Diameter
1"
Frequency Response
55Hz - 20kHz
Sensitivity (1w/1m)
91dB
RMS Power
65W
RMS Power
65W
Impedance (ohm)
8
Transformer
70V: 32-16-8-4-2-1W
100V: 32-16-8-4-2W
Enclosure Material
LLDPE
Environment
IP56
Product Diameter (mm)
365
Product Height (mm)
409
LEFT RIGHT
Oasis 6T USER´S
MANUAL
1 2
Packing List
Important
Audibax has made every effort to provide accurate and detailed instruction for this
product’s assembly. Should you have any doubts, consult a qualified professional
fitter, Audibax recognizes no liability for any difficulty or problem derived from the
interpretation of these instructions. These brackets and all their parts and accessories
must only be used for the purpose they have been constructed.
Audibax, its commercial distributors and retailers are not, directly or indirectly,
responsible for any damage to persons and or properties derived from the use of this
product in an unsafe or different way for which it has been designed and construc-
ted. Several parts of this product are small pieces of hardware therefore extreme
care should be taken to keep them from children.
Read These Instructions Carefully Before Using the Product
1. Place the speaker on a level surface.
2. Do not touch or bump the woofer and tweeter. Any damage will lead to sound
distortion.
3. Do not listen to sound at a very high level when you are changing the input source
(for example, to tune FM / CD) installation or removal of cables should make sure
that the power amp / amplifier device radio is turned off.
4. Don’t attempt to clean the speakers with chemical solvents as this may damage
the paint surface. Clean only with a dry cloth.
Direct Burial Wire or Conduit
Depending on the type of installation, direct burial of the speaker wires from the
amplifier to the loudspeakers may be adequate, or the use of 1"-1-1/2" ID conduit
may be required for protecting the wires from possible physical damage if future
excavation or other alterations are anticipated in the area of the installation.
speaker user manual Black Wire
Red Wire
Signal Feed from
Amplifier
To Next Speaker
Loudspeaker
Switch
Input
Anti-theft bracket
installation panel
Connections Can be Protected Using One of the Following Methods
- Solder wires together using waterproof heat shrink tubing to seal.
- Use waterproof wire connectors.
- Make connections with immersion-resistant crimp splices.
- Use grease wire caps.
Connection
Use wire on the back of the speaker in the output tab of the amplifier (or amplifiers of
radio). The speaker wire is on one side red and on the other one black. Connect to
the red side of the amplifier and speakers (+) tab. Connect one end of the black side
(-) in the other tab. Connect each speaker to make sure that is not (+,-) inverted
polarity. If the polarity of the speakers is reversed, the sound will be unnatural and
will play without bass.
Underpowering Vs. Overpowering
1. Most speaker damage is caused by amplifiers with too little power (wattage).
2. An overdriven amplifier clips the waveforms and sends distortion to the speakers.
3.Clipping is usually audible; it may vary from a harsh sound to a fuzzy or unclear
sound.
4 If you hear the clipping at high volume levels, turn down the volume until the
distortion is gone.
5. Damage caused by operating the speakers at distorted volume levels is not
covered by the warranty.
