Audibax Roma 240 Go Manual

Audibax Højttaler Roma 240 Go

Læs gratis den danske manual til Audibax Roma 240 Go (4 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Audibax Roma 240 Go, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

Roma 240 Go

Please read the manual before using the product

USER´S

MANUAL

Roma 240 Go

Speciﬁcations

Model No.

Roma 240 Go

Type

PA System All-in-One Battery Powered

Transducer LF

1 * 6.5" subwoofer, 1.5" voice coil

Transducer HF

3 * 2.75", neodymium magnet, 1" voice coil

Frequency Response (-6dB)

60 Hz - 18 kHz

Max. SPL (1m, free space)

114 dB

Impedance

4Ohms

Ampli cation ﬁ

Class D

Power Output (RMS)

120W

Number of Mixer Channels

Number of Mic Preamps

2-Band Channel EQ

Effects

Reverb

Inputs

2 * XLR / 6 .3mm Combo , / 1 * RCA Line in

Outpust

1*XLR line out

Bluetooth

Yes, and support Tws function

Enclosure Material

Polypropylene Plastic

Mounting Options

35mm pole mount, Tilt-back, Floor Monitor

Power Supply

110~240V 50/60HZ

Battery

Rechargeable Lithium--ion battery 6pcs 2600mAh 18650

Roma 240 Go

USER´S

MANUAL

1 2

Please read and keep all safety and use instructions. Important Safety Instructions

Refer to the user manual for more information about your Roma 240 Go

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produces heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding-type plug

has two blades and a third grounding prong. The wider blade or third prong is

provided for your safety. If the provided plug does not fit in your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles, and the point where it exits from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

13. Unplug this apparatus during lightning storms or when unused for long periods of

time.

14. Refer all servicing to qualified personnel. Servicing is required when the apparatus

has been damaged in any way such as power-supply cord or plug is damaged,

liquid has been spilled or objects have falleninto the apparatus, the apparatus has

been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNINGS/CAUTIONS:

12. Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

This symbol on the product means there is uninsulated, dangerous voltage

within the product enclosure that may present a risk of electrical shock.

This symbol on the product means there are important operating and

maintenance instructions in this guide.

Contains small parts which may be a choking hazard. Not suitable for

children under age 3.

This product contains magnetic material. Consult your physician on whether

this might affect your implantable medical device.

1.Signal/Clip Indicator: Displays the input signal status in color.

Green: Signal present Red: Signal clipping

Note: Reduce the corresponding volume control to prevent signal clipping.

2. Volume Control: Adjust the volume of your microphone, instrument or audio source.

3.Treble Control: Adjust the high-frequency balance of your microphone or instrument.

4. Bass Control: Adjust the low-frequency balance of your microphone or instrument.

5.Effect Control: Adjust the amount of effect applied to your microphone or instrument.

6.Tone Match Switch: Move the switch to the or position to enable the Tone Match

preset.

7. Channel Input: Analog input for connecting microphone (XLR) and instrument (TS

unbalanced) cables.

8. RCA Left/Right.: Connect another interface such as a cell phone, guitar, computer, and

the same device, etc.

9. Line Output: Use a ¼c TRS cable to connect the line-level output to the Channel 1 or 2

input of a second Roma 240 Go to create a mono, two-loudspeaker setup.

Note: Line Out is post mix.

10. TWS: With BT mode active, press TWS on both speakers to enter TWS mode. LED will flash

until connection is made.

Once connected press TWS again to disconnect.

11. AC Input: 100-240V AC power input.

12. Bluetooth: Press BT to activate bluetooth mode, LED will flash, when bluetooth mode is

active, pressing BT will disconnect.

13. ON/OFF/CHARGE ONLY: Press to switch power ON/OFF. Though the battery will always

charge while the unit is connected to AC power, "Charge Only" enables you to charge your

battery more quickly.

System Setup

Connections and Controls
