Side 1/2

FACTORY UPGRADE ACCESSORY

PROVIDES STABILITY TO OEM SOUND SYSTEMS

IDEAL FOR NON-AMPLIFIED DODGE®, CHRYSLER®, JEEP®, MASERATI®

MAXIMUM INPUT 15 VRMS (50 WATTS)

LOAD GENERATING DEVICE & SIGNAL STABILIZER

FOR OEM SOUND SYSTEMS REQUIRING A SPEAKER LOAD

©2019 AudioControl. All rights reserved. P/N 9120630

22410 70th Ave West | Mountlake Terrace, WA 98043 USA

Phone 425-775-8461 | Fax 425-778-3166

www.audiocontrol.com

Important

ÄDo not exceed 15 Vrms (50 watts) of input

ÄOperating Impedance: 20 Ohms

ÄDo not install under carpet or near heat sources

Also

makes a

charming

bracelet!

What’s Included?

One pair of AC-LGD 20s prewired with EIA color

coded wires

Quick Start:

1. Remove one speaker level input plug from your AudioControl active line

output converter (LOC), processor, or amplier

2. Unplug one end of AC-LGD 20 then plug the AC-LGD 20 into the LOC

3. Install the plug you removed from the LOC to the open end of the AC-LGD 20

4. Connect your factory speaker signals to the AC-LGD 20

5. If you are using a LOC with dierent style connectors, unscrew the connectors

from the AC-LGD 20 wires and connect the wires accordingly

What is a Load Generating Device?

Today’s factory ampliers feature built in protection circuits which can mute some

or all audio outputs when the factory speakers are removed. The AC-LGD 20 has

been designed to generate load and stabilize signal from amplied factory systems

to ensure the best possible audio.

R

L

R

L

R

L

R

L

R

R

L

L

R

R

L

L

LOAD GENERATING DEVICE & SIGNAL STABILIZER

FOR OEM SOUND SYSTEMS REQUIRING A SPEAKER LOAD

To Speaker

Level Inputs

From Factory

Amplier

Rear Outputs Rear Inputs

Front Outputs Front Inputs

8 351523 00771

Produkt Specifikationer

Mærke:	AudioControl
Kategori:	Generator
Model:	AC-LGD 20
