Side 1/6
Cable Replacement Kit
CFC Series
Owner’s Manual
for CFP Series Carbon Fiber Boom Poles
Introduction
Thank you for choosing Auray.
The Auray CFC replacement kit provides a
replacement cable for the Auray CFP carbon fiber
boom pole. Auray’s solderless design provides a
fast and easy solution for cable replacement.
The high-quality coiled cable features a right-angle
XLR connector manufactured by Neutrik®, and a
TA3 (mini XLR) connector manufactured by Rean®
(a registered trademark of Neutrik®) for secure
locking connections and flawless signal transfer.
This cable also features Auray’s unique strain relief
system that absorbs tension and protects the cable
from damage at the edge of the tip exit and at the
T3 connector. The included hex key and a small
slotted screwdriver (not included) are the only tools
needed for this cable replacement procedure that
will assure long-lasting and trouble-free operation
of your CFP boom pole.
Right-angle
XLR connector
TA3 (mini XLR)
connector
Coiled XLR
cable
Tip strain relief
Nylon line
1.5 mm hex
key
Replacing the Cable – Boom Pole with
Bottom Exit XLR
Remove the old cable
1. Use the hex key to
loosen the set screw
on the tip. 1
2. Remove the tip by
unscrewing it. 2
3. Lift the cable and
strain relief out of the
tip exit slot. 3
Tip: Before
proceeding, push a
small length of cable
into the tube from the
tip of the pole. This
will give you enough
slack to complete the
following steps.
4. Unscrew the bottom
housing from the base
of the boom pole. 4
5. Unscrew the plastic
TA3 strain relief. 5
6. Disconnect the TA3
connector by pressing
on the locking tab and
gently removing the
connector from the
mount.
Note: The TA3
connector should
easily disconnect. Do
not force or pull on the
cable to disconnect
it. Doing so could
damage the housing
or the connector.
7. Use a small slotted
screwdriver to reach
inside the strain
relief and depress the
locking tab of the TA3
connector. 6 With the
locking tab depressed,
you can slide the
strain relief over the
TA3 connector and
o of the cable. Set
the strain relief piece
aside.
Alternative: Use a wire cutter to snip the cable
at the base of the TA3 connector. Remove the
strain relief, and set it aside.
Important: Once you have performed this step,
the cable will be unusable. If you plan on using
the cable again at a later point, don’t proceed
with this alternative step.
8. Remove the cable by pulling it out from the
top of the pole.
5
6
Instructions
1
2
3
4
