CFP-ET Series

Carbon Fiber

Extension Tubes

for CFP-Series Boom Poles

Owner’s Manual

Extension tube

accessory for use

with Auray CFP-

series boom poles.

Manufactured with

sturdy, lightweight

carbon ﬁber for

portability and

reliability.

Integrated cable

with high-quality

TA3 (mini XLR)

connectors

manufactured by

Rean® (a registered

trademark of

Neutrik®).

www.AurayAudio.com

Adding an Extension – Boom Pole with

Side-Exit XLR

1. Unscrew the side exit housing, 1 and

move the plastic strain relief cap so that

the TA3 connector inside the housing is

exposed.

2. Disconnect the TA3 connector by pressing

on the locking tab and gently removing the

connector from the mount. 2

Note: The TA3 connector should easily

disconnect. Do not force or pull on the

cable to disconnect it. Doing so could

damage the housing or the connector.

3. Use a small slotted screwdriver to reach

inside the strain relief and depress the

locking tab of the TA3 connector. With the

locking tab depressed, you can slide the

strain relief over the TA3 connector and o

of the cable. 3 Set the strain relief piece

aside.

4. Connect the male TA3 connector of the

included cable to the female TA3 connector

of the coiled cable of the boom pole.

5. Snake the included cable through the

extension tube.

6. Screw the extension tube onto the end of

the boom pole.

7. Fit the narrow side of the strain relief over

the TA3 connector, and push it past the

TA3 connector’s locking tab. 4

8. Plug the TA3 connector into the bottom

housing by inserting it into the TA3 mount

and pushing in until it clicks.

Note: When properly aligned, the TA3

connector will easily slide into place.

Do not try to force the connector into

the mount. Doing so could damage the

connector or the mount.

9. Push the strain relief all the way into the

side exit housing so it sits over the TA3

connector. 5

10. Screw the side exit housing onto the end of

the boom pole.

Auray is a registered trademark of the

• Please read and follow

these instructions, and

keep this manual in a safe

place.

• Handle the product with

care.

• Use only parts provided by

the manufacturer.

• Make sure the item is

intact and that there are no

missing parts.

• All photos are for

illustrative purposes.

Adding an Extension – Boom Pole with

Bottom-Exit XLR

1. Unscrew the bottom housing from the base

of the boom pole. 1

2. Unscrew the plastic TA3 strain relief. 2

3. Disconnect the TA3 connector by pressing

on the locking tab and gently removing the

connector from the mount.

Note: The TA3 connector should easily

disconnect. Do not force or pull on the cable

to disconnect it. Doing so could damage the

housing or the connector.

4. Use a small slotted screwdriver to reach

inside the strain relief and depress the

locking tab of the TA3 connector. 3 With

the locking tab depressed, you can slide the

strain relief over the TA3 connector and o of

the cable. Set the strain relief piece aside.

5. Connect the male TA3 connector of the

included cable to the female TA3 connector

of the coiled cable of the boom pole.

6. Snake the included cable through the

extension tube.

7. Screw the extension tube onto the end of the

boom pole.

8. Fit the narrow side of the strain relief over

the TA3 connector, and push it past the TA3

connector’s locking tab. 4

9. Plug the TA3 connector into the bottom

housing by inserting it into the TA3 mount

and pushing in until it clicks.

Note: When properly aligned, the TA3

connector will easily slide into place. Do not

try to force the connector into the mount.

Doing so could damage the connector or the

mount.

10. Screw the threaded end of the strain relief

onto the threaded ﬁtting on the bottom

housing. 5

11. Screw the bottom exit housing onto the end

of the boom pole.

Instructions

XLR cable with

Rean® TA3

connectors

The TA3 (mini XLR)

connectors manufactured

by Rean® (a registered

trademark of Neutrik)

provide a secure locking

connection and maximum

signal transfer.

Sturdy lightweight

carbon ﬁber

The CFP series features

matrix reinforced carbon

ﬁber composite tubes

that oer exceptional

strength-to-weight ratio.

The lightweight design

reduces handling fatigue

during lengthy sessions.

They are designed to

withstand the rigors of ﬁeld

use, and are comfortable

to handle even in extreme

temperatures.

Tube Diameter:

1.25″ (31.3 mm)

Tube Length:

CFP-ET2: 2′ (0.6 m)

CFP-ET3: 3′ (0.9 m)

CFP-ET4: 4′ (1.2 m)

CFP-ET5: 5′ (1.5 m)

CFP-ET6: 6′ (1.8 m)

Cable Connectors:

TA3 Male to TA3 Female

Speciﬁcations

Precautions

Introduction

Thank you for choosing Auray.

The Auray CFP-ET-series

extension tubes are extensions for

Auray’s CFP-series boom poles.

Made of the same lightweight and

durable carbon ﬁber construction

as the CFP boom poles, these

extensions will add length to the

boom pole without sacriﬁcing

strength. The TA3 (mini XLR)

cable is engineered to be

compatible and work ﬂawlessly

with every component of the CFP

boompole series.
