BINOCULAR INSTRUCTIONS

CAUTION: DIRECTLY VIEWING THE SUN OR ANY LIGHT SOURCE

WITH THIS OPTICAL DEVICE CAN CAUSE PERMANENT EYE DAMAGE.

Fig.4 BINOCULAR EYECUPS

Roll Down Eye Cups

BC152

®| La Verne, CA 91750

w w w . b a r s k a . c o m

®| La Verne, CA 91750

w w w . b a r s k a . c o m

model may varys

III. WATERPROOF/FOG-PROOF (select models)

Your binocular may be designed and built utilizing the

latest waterproof and fog-proof technology.

Waterproof models are O-ring sealed for complete

protection. Fog proof protection is achieved from dry

nitrogen purging to remove all internal moisture.

IV. EYECUPS

Your binocular is fitted with either rubber roll-down

or rubber pop-up eyecups designed for your comfort

and to exclude extraneous external light. If you wear

sun/eye glasses, roll down the eyecups. This will

bring your eyes closer to the binocular lens thus

providing improved field of view.

V. INSTRUCTIONS FOR CARE

If handled with care, this binocular will provide years

of trouble-free service. Like any fine optical

instrument your binocular should be given sensible

care. Non waterproof models should not be exposed

to excessive moisture.

1. Keep the lens covers (that come with your

binocular, except compact models) on the

lenses when binoculars are not in use.

2. Store binoculars with the eyecups up. Thus

avoiding excessive stress and wear on the

eyecups in the down position.

3. Avoid banging and dropping.

4. Store in a cool, dry place.

5. Looking directly at the sun with your binocular

may be very harmful to you eyes.

VI. CLEANING

1. Blow away any dust or debris on the lens (or

use a soft lens brush)

2. To remove dirt or fingerprints, clean with a

soft cotton cloth rubbing in a circular motion.

Use of a coarse cloth or unnecessary rubbing

may scratch the lens surface and eventually

cause permanent damage.

3. For a more thorough cleaning, photographic

lens tissue and photographic-type lens cleaning

fluid or isopropyl alcohol may be used. Always

apply the fluid to the cleaning cloth-never

directly on the lens.

VERY IMPORTANT

Never attempt to clean your binocular internally or try

to take it apart.

2. Cover right objective (front) lens with your

hand. Rotate left eyepiece until image is

focused.

3. Follow the same procedure for the right eye.

The eyepiece should be turned in a counter-

clockwise direction for more distant objects.

With the image now in focus, make a note of

the diopter setting for future use.

FOCUS-FREE (select models)

Focus-free binoculars offer “never needs focusing”

optical systems.

“ZOOM” FEATURE (select models)

1. Follow the steps for focusing as outlined under

“Center Focus”

2. When focusing a “zoom” binocular, it is best to

begin at the highest power. This will provide a

more comfortable focus at the lower powers.

Set the “zoom” lever at high power.

3. Adjust your binocular for individual eye

strength using the “diopter setting”

Your binocular is now adjusted properly for your

eyes. You may now “zoom” “out” or “in” on any

distant object.

Note: to focus on an object at a closer distance,

focus on the object at high power first and then adjust

the “zoom” lever to the desired lower power. With any

“zoom” instrument, better quality images are possible

at lower powers.

CENTER FOCUS-has a central focusing wheel

between the barrels.

INDIVIDUAL FOCUS-each eyepiece is focused

separately. Most typically with waterproof/fog-proof

models.

FOCUS FREE-binocular require no focusing

adjustment.

CENTER FOCUS

1. Adjust interpupillary distance (Figure 1)

2. Keep both eyes “open” at all times.

3. Using a lens cover or your hand, cover the

objective (front) lens of the side with the

“diopter setting”

4. Using the center focus wheel, focus the

distant object being viewed.

5. Cover the other objective lens, then view

the same object as explained above.

6. Using the “diopter setting” adjustment ring,

focus the same object being viewed. Caution

should be used as over turning or forcing the

diopter eyepiece can damage or cause the

eyepiece to break away from the chassis.

7. Your binocular should be adjusted for your

eyes. Focus at both far and near distance can

now be attained simply by turning the center

focus wheel.

INDIVIDUAL FOCUS (select models)

1. Adjust interpupillary distance. Make a note of

the number which appears on the central

hinge scale. Always re-set your binocular to

this position before using. (To see a single

INSTRUCTIONS FOR USE

This binocular is a precision instrument designed to

provide many years of pleasurable viewing. This

booklet will help you achieve optimum performance

by explaining how you can adjust the binocular to

your eyes, and how to care for this instrument. Read

the instructions carefully before using your

binoculars.

I. EYE ADJUSTMENTS (FIGURE 1)

HOW TO ADJUST FOR DISTANCE BETWEEN

YOUR EYES

The distance between the eyes, called “interpupillary

distance” (IPD), varies from person to person. To

achieve perfect alignment of lens to eye, follow these

simples steps.

1. Hold your binocular in the normal viewing

position.

2. Grasp each barrel firmly. Move the barrels

closer together or further apart until you see a

single circular field. Always re-set your

binocular to this position before using.

HOW TO ADJUST FOR INDIVIDUAL EYE

STRENGTH

Human eyes are as individual as fingerprints. This

binocular has a feature which allows you to adjust the

binocular to your vision. Follow the focusing

instructions for your binocular style.

II. FOCUSING

Binoculars have three primary focusing systems,

center, individual and focus-free. “Zoom” binoculars

utilize the center focus system.

Fig.1 INTERPUPILLARY DISTANCE ADJUSTMENT

Center

Focus

Wheel

Diopter Setting

Fig.2 DIOPTER SETTINGS

Center Focus

Wheel

CAUTION: DIRECTLY VIEWING THE SUN OR ANY LIGHT SOURCE

WITH THIS OPTICAL DEVICE CAN CAUSE PERMANENT EYE DAMAGE.

Zoom Lever

Fig.2 “ZOOM” SETTINGS

Produkt Specifikationer

Mærke:	Barska
Kategori:	Kikkert
Model:	Gladiator
Bredde:	- mm
Dybde:	- mm
Højde:	- mm
Vægt:	900 g
Produktfarve:	Sort
Sammenfoldelig:	Ingen
Vandfast:	Ingen
Forstørrelse:	30 x
Nærmeste fokuseringsafstand:	8 m
Øjenlindring:	15 mm
Objektiv diameter:	50 mm
Prisme-type:	Porro
Udgangspupil:	5 mm
Lysstyrke:	- cd/m²
Synsfelt (ved 1000 m):	65 m
Linse overflade:	Multi coated (MC)
