PRODUCT DESCRIPTION SHEET

400010907949

DIMENSIONS OF THE HOB (mm)

Ø 145 mm

Ø 210 mm

Ø 210/120 mm

Ø 180 mm

Ø 145 mm

Ø 210/120 mm

Ø 145 mm

Ø 145x250 mm

Min. 40 cm

Min. 10 cm

Min. 7 cm

R = Min. 6,5 mm

Max. 8 mm

490 mm

750 mm

Min. 70 mm

513 mm

Min. 70 mm

773 mm

750 mm

490 mm

482 mm

742 mm

510

42 mm

R = 11,5 mm

R = Min. 6,5 mm

6 mm

min 20 mm

770 mm

770 X 510 mm

min. 20 mm

IMPORTANT: The hob’s safety features include an automatic switching off function. Prolonged use of the same heat

setting triggers automatic switch-off of the cooking zone (for example, after around 1 hour at maximum heat setting, the

cooking zone switches off).

BE CAREFUL: To avoid permanently damaging the glass-ceramic top, do not use:

- Pots with bottoms that are not perfectly flat.

- Metal pots with enamelled bottom.

Any aesthetic defects (scratches, surface marks, etc.) must be reported immediately upon installation.

A On/Off D Key lock

B Cooking zone and timer selection

F Multiple zone Activation/Deactivation

(if present)

C-E Heat setting increase and decrease

Upon first installation, the control panel performs a functional test for about 1 second, after which it

automatically switches to the “Key lock” function.

To deactivate the function, press and hold button “D”; an acoustic signal will sound and the corresponding led

will turn off.

NOTE: If a reset occurs, repeat the procedure described above.

To switch the hob on, keep button “A” pressed for approx. 2 seconds. The 4 cooking zone displays show “0”.

If within 20 seconds none of the cooking zones is activated, the hob switches off automatically as a safety

precaution.

Press one of the buttons “B” corresponding to the cooking zone you intend to use.

Select the heat setting required with buttons “E” or “C”. The other selectable cooking settings go from 1 to 9.

Press buttons +/- at the same time to cancel all settings.

Pressing button “+” when level 9 is reached, the “Booster” function is activated and the letter “A” appears on

the display.

IMPORTANT: the control is deactivated 10 seconds after the heat setting has been selected. To change the heat

setting, first press the selection button “B” again, then proceed to change the setting, using buttons “E” or “C”.

MULTIPLE ZONE (if present): After selecting the desired zone and setting the level (as described in the

previous section) press “F”: an indicator above the button turns on, activating the additional zone. The multiple

zone can only be used if:

1) The cooking zone is provided with multiple zone;

2) The power level selected is greater than 0.

To deactivate the multiple zone, press button “B” of the desired zone, then press “F” again.

To set the Timer function, select the desired cooking zone and power setting then press the cooking zone key

again and a luminous dot will appear on the display of the timer-controlled cooking zone.

The indication “00” blinks on the 2 displays. Press buttons “C” or “E” to set the time from 1 to 99.

IMPORTANT: after 10 seconds the timer displays will show the power setting of the other cooking zones.

To view the remaining cooking time, press the timer-controlled cooking zone key twice.

The KEY LOCK function is switched on by holding down button “D” until a dot lights up above the function

button. The Key lock function locks all the hob’s other functions, with the exception of the On/Off button “A”.

The function remains on even after the hob is switched off and on again and can be deactivated by pressing button

“D” again until the dot above the function button goes off.

RESIDUAL HEAT INDICATOR

When the cooking zone is switched off, the residual heat indicator “H” remains on or flashes alternating with

“0” until the temperature of the hob returns within safety levels.

Produkt Specifikationer

Mærke:	Bauknecht
Kategori:	Ovn
Model:	CTAR 9642 IN
Tænd-/slukkontakt:	Ja
Bredde:	577 mm
Dybde:	507 mm
Højde:	46 mm
Vægt:	8000 g
Produktfarve:	Sort
Kontroltype:	Berøring
Indbygget skærm:	Ja
Strøm:	27.8 A
Pakkevægt:	9000 g
Pakkedybde:	600 mm
Pakkebredde:	670 mm
Pakkehøjde:	140 mm
Timer:	Ja
Placering af apparat:	Indbygget
Integreret ur:	Ja
Urtype:	Elektronisk
Installationsrum bredde:	560 mm
Installationsrum dybde:	490 mm
Installationsrum højde:	46 mm
Børnesikring:	Ja
Komfurtype:	Keramisk
Overfladetype:	Keramisk
Antal kogeplader / madlavningsområde:	4
Antal elektriske kogeplader:	4
Blus/kogeplade zone 1 strøm:	750 \ 2100 W
Blus/kogeplade zone 2 strøm:	1200 W
Blus/kogeplade zone 1 type:	Stor
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre bagende
Blus/kogeplade zone 1 strømkilde:	Elektrisk
Blus/kogeplade zone 2 type:	Simre
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre front
Blus/kogeplade zone 2 strømkilde:	Elektrisk
Kontrolposition:	Top forside
Nem at rengøre:	Ja
Tilsluttet belastning (elektrisk):	6300 W
Ovnbredde størrelse:	60 cm
Blus/kogeplade zone 3 type:	Simre
Blus/kogeplade zone 4 type:	Stor
Blus/kogeplade zone 2 diameter:	145 mm
Blus/kogeplade zone 1 diameter:	120 \ 210 mm
Blus/kogeplade zone 3 diameter:	145 mm
Blus/kogeplade zone 4 strømkilde:	Elektrisk
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Elektrisk
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Højre bagende
Blus/kogeplade zone 4 position:	Højre forside
Timer type:	Digital
Restvarmeindikator:	Ja
Indbygget hætte:	Ingen
Tilsluttet belastning (gas):	0 W
Autosluk timer tilbereder mad sikkert:	Ja
Timer varighed:	99 min.
Blus/kogeplade zone 4 strøm:	1000 \ 1800 W
Blus/kogeplade zone 3 strøm:	1200 W
Boost funktion:	Ja
Ramme, farve:	Rustfrit stål
Rammetype:	Fuld beskæring
Kogezone 4 størrelse (B x D):	145 x 250 mm
