5019 496 90132
GB
GSF 1988 Quick Reference Guide
Before using the dishwasher, read the user instructions!
(We reserve the right to make technical modifications)
Add regeneration salt
Only add regeneration salt
immediately before starting a
wash programme.
Add rinse aid
No water
Check that the appliance fills with
water.
Time and failure display 3)
Indicates in hours the time remaining
until the start of the wash cycle.
Switches off at programme start and
indicates the remaining time in hours
and minutes.
F... Information for the After-
Sales Service
Delayed start button
The wash cycle can be programmed to
start after 1 - 24 hours. With each
successive touch of the button, the
delayed start indicator increases by 1
hour, and after 24 returns to 00. Then
press the Start button. The dishwasher
will start at the set time.
Half load button
This function can be used with any
programme. The indicator lamp
switches on. The wash cycle is activated
for the upper or lower rack only.
1) Reference programme for energy label in
compliance with EN 50242 regulations;
2) Refer to User instructions;
3) Values may vary in relation to usage, e.g.:
different loads, water temperatures - above or
below 15°C - as well as water hardness and power
supply voltage, etc.
Programme selector knob
On / Off button
Start button
Switches on when the dishwasher
is operating. Flashes when a fault
occurs. Switches off at the end of
the programme.
Indicators
Wash cycle
Pre-Rinse Washing Drying Programme
end
Options
Programme chart Detergent2) Consumption
3)
Programmes Loading instructions A B Litres kWh Minutes
AutoNormal 40-55°C Automatic programme recommended for
routine washes, with no dried-on or burnt
food (not for EN 50242). X X 10-13 50-1100.8-1.05
AutoIntensive 60-70°C Automatic programme recommended for
heavily soiled crockery with dried-on or burnt
food, for example pans and saucepans. X X 13-20 90-1401.1-2.0
Pre-Rinse cold Crockery to be washed later. - - 4.0 0.03 14
Glass 40°C Light soiling, for example glasses
and cups. X - 10.0 0.80 55
Rapid 30 min 40°C Lightly soiled crockery with no
dried-on food. X - 10.0 0.65 30
Standard1) 50°C Normally or heavily soiled crockery. X X 13.0 1.05 120
BK/II/B/GB
How to use the appliance
Further indications are given in the single chapters and in the user instructions.
Press the ON / OFF button.
Large compartment A:
With each wash cycle.
Small compartment B:
For programmes with pre-wash only.
Mechanical indicator lamp C.
Electric indicator on control panel (if provided).
On models with water softener system only.
Mechanical indicator lamp D.
Electric indicator on control panel (if provided).
Refer to the dishwasher loading instructions.
The last programme selected will light up.
Select the desired programme (using the specific button or
knob). The corresponding indicator lamp lights up.
If necessary (and if provided) the corresponding indicator
lamp lights up.
The selected programme
is then memorised (even
in the event of power
failure).
- Only open the dishwasher if necessary
(Warning: beware of hot steam).
- If the appliance is switched off during
a wash cycle, when switched on
again it will resume the cycle from
where it was interrupted.
Only after the START button has switched off: Press the
ON / OFF button. All the indicator lamps switch off.
Warning: when the door is opened steam comes out!
Unload the appliance, starting from the lower rack.
Switch on the appliance
How to fill the
detergent dispenser
C
BA
Check the
rinse aid level
Check the regeneration
salt level
Load the racks
Close the door,
turn on the water tap
Select a programme
Select additional
options
Press the START button
“Change programme”
Press the START button for 2 sec. until
the Start indicator lamp switches off;
Select another programme and
press the START button again.
Wash cycle
Switch off the appliance
Shut off the water tap,
unload the racks
