Side 1/4

pFurther indications are given in the pages to follow and in the user instructions.

“Water stop” device indicator

“Water stop” device not working.

Switch off the dishwasher and shut off the

water tap.

Rinse aid level indicator

Add rinse aid.

Salt level indicator

Add regeneration salt; only add regeneration

salt immediately before starting a wash

programme.

Programme progress indicator Start button

Indicator lamp lit while the

dishwasher is operating.

Flashes when a fault occurs.

Switches off at the end of the

programme.

On / Off Button

Pre-rinse /

Pre-wash

Washing

Drying

Programme end

Option

Delayed start button

The wash cycle can be programmed to start after 3-6-9 hours.

Then press the Start button. The dishwasher will start at the

set time.

Programme Symbol

and Temperature

Programme selection and

recommended load type

Place the detergent in the:

small large

compartment compartment

Consumption 1)

Normal load

Water

(Litres)

Energy

(kWh)

Time

(Min.)

Pre-wash Crockery to be washed later. - - 95.0 0.02

Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 300.85

Bio-Eco 50° C Normally soiled crockery. - X 12.0 731.25

Bio-Normal 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 861.40

Normal 65° C 3) Normally or heavily soiled crockery with dried-on food. X X 16.0 861.60

Intensive 70° C Heavily soiled pans and saucepans. X X 21.0 931.68

Quick Reference GuideGB

5019 100 90316

(We reserve the right to make technical modifications)

1) Values may vary in relation to usage, e.g.: different loads,

water temperatures - above or below 15° C - as well as water hardness and power supply voltage.

2) Programme recommended when using detergents of type B (enzyme-based detergents).

Reference programme for energy label.

3) Programme recommended when using detergents of type A (non enzyme-based detergents).

GSF 5369

1. After loading the dishwasher, close the

door properly and open the water

supply tap.

2. Press the On/Off button to switch the

dishwasher on. One of the

programme indicator lamps will

switch on.

3. Select the desired programme by

pressing the corresponding button.

The corresponding indicator lamp

lights up. If required, select options

(if supplied).

4. Press the Start button to start the

selected programme. The Start

indicator lamp will light up. Once set,

the programmed data cannot be

altered by pressing the programme

selector buttons.

Note: once the Start button has been

pressed, the dishwasher memorises the

last programme selected. This

information remains in the memory even

during interruption of the power supply.

To change the selected

programme, press the Start button

for about 5 seconds, until the Start

indicator lamp switches off.

Select a new programme using the

programme selector knob and

press the Start button.

Note: if the dishwasher is switched off

during a wash programme, when

switched on again it will resume the wash

cycle from where it was interrupted.

Only open the dishwasher door if

strictly necessary during a wash cycle

and exercise maximum caution.

Danger of scalding from steam.

5. To indicate the end of the programme,

the Start indicator lamp switches off

and the End indicator lamp (if fitted)

lights up (for about 30 min.).

6. Once the Start indicator lamp has

switched off press the On/Off button to

switch the dishwasher off. All the

indicator lamps switch off.

7. Open the door (warning: beware of hot

steam). Unload the lower rack before

the upper one. Close the water tap.

Upper rack

Rack height adjustment:

(The dishwasher is delivered with the upper

rack in the top position).

The rack height can also be changed

when loaded.

•To lower: pull out the two side

handles and gently lower the rack.

•To raise: pull up the two side handles

until the rack clicks into place.

•The rack must be level on both

sides.

Crockery holders:

•Down: cups and long-stemmed glasses.

•Up: plates.

“ ”Vario Organizer multi-purpose

support:

•To be used, for example, for long-

handled utensils (arrange knives

with the blade facing downwards),

cups and glasses.

•May be used in three different

positions (see also “Dishwasher

loading instructions” on Page 4).

1. Upon the left-hand side of the rack.

2. Upside-down, towards the centre of

the rack.

3. Upside-down, towards the left side.

Glass holder:

Lower rack

Plate holders:

•May be lowered to increase

available space (A).

•May be removed to increase available

space (B). To remove: pull the handle

up.

Cutlery basket:

The cutlery basket can be removed to

increase (C) available space.

How to use the dishwasher

Please read the user instructions carefully.

Upper and lower rack
