Side 1/17
Bauknecht AG, Industriestrasse 36, 5600 Lenzburg, www.bauknecht.ch
Verkauf Telefon 0848 801 002 Fax 0848 801 017 verkauf@bauknecht.ch
Kundendienst Telefon 0848 801 001 Fax 0848 801 003 service@bauknecht.ch
Ersatzteile Telefon 0848 801 005 Fax 0848 801 004 ersatzteilverkauf@bauknecht.ch
Instructions for use
WAE 8759
GB PROGRAMME CHART
The wool and handwash cycles of this machine have been tested and approved by The Woolmark Company for the washing of
Woolmark garments labelled as “machine wash” or “hand wash” provided that the garments are washed according to the
instructions on the garment label and those issued in this programme chart. M0702
❉:optional / Yes : dosing required
1) For improved garment care, spin speed is restricted in these programmes. 5019 401 05518
Programme
Tempe-
rature Care
Labels
Max
Load
kg
Type of wash/Notes
- Respect the manufacturer’s recommendations on the care label
Detergents and additives Selectable options Start delay
Start-
vorwahl
Départ différé
Spin
Pre-
wash
Main
wash
Softener Clean +
Clean +
Clean +
Pre-
wash
Vorwäsche
Prélavage
Rinse
hold
Spülstopp
Arrêt
Cuve Pleine
Intensive
rinse
Intensiv
spülen
Rinçage
Variable
spin
Schleudern
Essorage
Max
Spin
Speed
rpm
White Cotton /
Hygienic + 70 - 95 °C 8.0 Normally to heavily soiled bed linen, table linen and underwear, towels, shirts etc.
made of cotton and linen.
At a temperature of 80°C or more, this programme eliminates bacteria, ensuring
sanitization of your laundry. The bacteria removal efficiency has been tested following
a similar methodology to the NF EN 13697 standard of Nov. 2001.
❉Ye s ❉ ❉ ❉ ❉ ❉ ❉ ❉
max.
Coloured
Cotton Buntwäsche
Couleurs 20 - 60 °C
8.0
Synthetics Pflegeleicht
Synthétiques 20 - 60 °C
3.5 Normally soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira),
polyamide (Perlon, Nylon) or blends with cotton. ❉Ye s ❉ ❉ ❉ ❉ ❉ ❉ ❉
max.
Delicates Feinwäsche
Délicat 20 - 40 °C 2.5 Curtains and delicate clothing, dresses, skirts, shirts and blouses. ❉Ye s ❉—❉ ❉ —❉ ❉ 1000
1)
Wool 20 - 40 °C 2.0 Only woollens, labelled with the Woolmark and identified as machine washable.
This programme (40°C) is tested and approved by The Woolmark Company for
machine washable wool. —Ye s ❉— — ❉—❉ ❉ 1000
1)
Handwash 20 - 40 °C 2.0 Textiles made of silk, linen, wool and viscose marked as “handwashable”.
This programme (40°C) is tested and approved by The Woolmark Company for
handwashable wool. —Ye s ❉— — ❉—❉ ❉
400 1)
Lingerie Dessous
Lingerie 20 - 30 °C 2.0 This programme is particularly suitable to treat delicate lingerie (use of a laundry net
strongly recommended). —Ye s ❉— — ❉—❉ ❉
400 1)
Eco Cotton Baumwolle Eco
Coton Eco 60 °C 8.0 Heavily soiled and robust laundry washable at 60°C such as bed linen, table linen, towels etc.
The extended programme duration enables economic energy and water consumption
while maintaining good washing results. —Ye s ❉— — ❉ ❉ ❉ ❉
max.
Sport Sport 20 - 30 °C 3.5 Normally soiled and sweaty sportswear made of cotton jersey or microfibers.
This programme includes a prewash cycle – you can add detergent also to the prewash
chamber. Do not add any softener.
❉Ye s — — — ❉ ❉ ❉ ❉
max.
Super Eco Super Eco 20 - 60 °C 8.0
Normally to heavily soiled and robust bed linen, table linen and underwear, towels,
shirts etc. made of cotton and linen.
Offers highest economy in energy consumption by prolonged washing duration. Ideal to be
run overnight to additionally profit from the more favourable energy rates. To avoid noise
of spinning at night, set spin speed to “0” and start spin programme in the morning, or
define programme start with “Start delay” accordingly.
—Ye s ❉— — ❉ ❉ ❉ ❉
max.
Daily load Mischwäsche
Mixte 20 - 60 °C
6.0 Slightly to normally soiled textiles made of cotton and/or synthetics. —Ye s ❉— — ❉ ❉ ❉ ❉
max.
Speed 15 Kurz 15
Chrono 15 20 - 30 °C 3.0 Refreshes briefly worn outer clothing made of cotton, artificial fibers and blends with
cotton. Use lowest recommended detergent amount. —Ye s ❉— — ❉—❉ ❉
max.
Rinse & Spin Spülen & Schleudern
Rinçage & Essorage — — 8.0 Same as the last rinse and the final spin in the “Cotton” programme. — — ❉— — ❉ ❉ ❉ ❉
max.
Spin Schleudern
Essorage — — 8.0 In this programme spinning is intensive. Same as the spin cycle in the “Cotton” programme. — — — — — — — ❉ ❉
max.
A. Programme selector
B. Display
C. “Temperature” button
D. “Variable spin” button
E. “Start delay” button
F. “Start (Pause)” button
G. “Reset/Drain” button
H. “Favourites” button
I. Programme sequence indication
J. “Door open” indication
K. “Child lock” indication
L. “Detergent overdosage” indication
M. Red failure indications
C
K
A F
G
E
DH
}
IJ M
L
B
5019 401 05518
Add detergent as indicated on the front page and as described in
the chapter “Detergent and Additives” in your Instructions for Use
(remove separator in detergent dispenser for use of powder
detergent if necessary).
Turn the programme selector to the desired programme; the light
of the “Start (Pause)” button blinks. The temperature and spin
speed indicated on the display can be altered by pressing the
“Temperature” button or the “Variable spin” button.
When the combination of programme and additional option(s) is
not possible, the indication lights switch off automatically.
Unsuitable combinations of options are deselected automatically.
“Clean+” button
• Choose this option if you use an in-wash additive for stain removal
(powder, for example “Vanish”) - it will optimize the additive’s
efficiency to get better wash performance and stain removal.
• Choose temperature of 30 or 40°C and use with maximum load.
• Add an appropriate amount of in-wash additive for stain
removal (powder) to the main wash chamber, together with
your detergent (only use powder detergent with this option).
Respect the manufacturer’s dosing instructions.
• Prolongs the programme by approx. 10 to 15 minutes.
• Appropriate for use of stain removers and bleaches on oxygen
basis. Chlorine or perborate bleaches must not be used!
“Prewash” button
• Only for heavily soiled loads (for example sand, granular dirt)
sensible. Increases the cycle time by approximately 15 min.
• Do not use liquid detergent for the main wash when activating
the “Prewash” option.
“Rinse hold” button
• The laundry remains in the last rinse water, without
progressing to the fnal spin cycle, to avoid creasing and
prevent colours from changing.
• The programme stops to “Rinse hold” when the “Rinse hold”
symbol on the display blinks; the light of the “Start
(Pause)” button blinks as well.
• To terminate the “Rinse hold” by draining the water, without
any spinning, press the “Start (Pause)” button.
• To terminate the “Rinse hold” by spinning the laundry, press
the "Variable spin" button to select the desired spin speed and
then “Start (Pause)” to start the spin cycle.
• Do not leave the laundry to soak for too long in the “Rinse hold”.
“Intensive rinse” button
• More water is added and rinse cycle is prolonged.
• This option is particularly suitable for areas with very soft water or
for washing baby linen, and helps people with allergies.
“Variable spin” button
• Every programme has a predefined spin speed.
• Press the button to set another spin speed.
• If spin speed “0” is selected, the final spinning is cancelled but
intermediate spin peaks remain during rinse. The water is
drained out only.
If there is a programme setting which you use frequently, the
appliance offers the possibility to save one setting for each
programme so that it can be used again by just pushing one button.
• Select the desired programme, temperature, spin speed and
option(s), push and hold the “Favourites” button for at least 3
seconds. The lamp of the “Favourites” button shortly blinks and
then lights up - the programme setting is saved.
CONSUMPTION DATA
Programme Temperature
(°C)
Load
(kg)
Water
(l)
Energy
(kWh)
Approx. Programme Duration
(hours : minutes)*
White Cotton / Hygiene + 95 8.0 82 ** 2.40 2:20
Coloured Cotton 60 8.0 59 1.36 2:20
Coloured Cotton 40 8.0 77 0.75 2:05
Synthetics 60 3.5 46** 0.85 1:35
Synthetics 40 3.5 42 0.50 1:20
Delicates 30 2.5 60 0.40 0:45
Wool 40 2.0 60 0.60 0:45
Handwash 40 2.0 45 0.60 0:40
Lingerie 30 2.0 45 0.35 0:36
Eco Cotton*** 60 598.0 1.04 4:00
Sport 30 3.5 54 0.55 1:34
Super Eco 60 8.0 75 0.95 4:00
Daily load 40 6.0 73 0.60 1:00
Speed 15 30 3.0 30 0.20 0:15
Consumption values were measured in normalized conditions in compliance with Standard IEC/EN 60 456. Consumption data in the home
may vary with respect to the values in the table in relation to the water supply pressure and temperature, the load and the type of wash.
*The time indicated on the display can deviate from the values in the table, because it takes into account the operation conditions
applicable at that time.
** To reduce the water temperature, some cold water is added at the end of the main wash cycle, before the pump drains the water out.
*** Reference Programme for Energy Label (with separator in detergent dispenser removed for use of powder detergent).
ADD DETERGENTS, CLOSE THE DOOR
AND SELECT THE PROGRAMME
SELECT ANY DESIRED OPTION
SAVE YOUR FAVOURITE PROGRAMMES
Next time you want to use your individual programme setting,
select the programme, shortly push the “Favourites” button and
start by pushing “Start (Pause)”.
If you want to replace the saved programme setting by another
one, proceed as already described above.
The “Start delay” allows to run the machine at the consumer’s
convenience, for example at night when electricity is cheaper. Do
not use liquid detergent when activating the “Start delay”.
• Select programme, temperature, spin speed and options.
• Press the Start delay button to select one of the delay time
steps between 0:30 and 23:00 hours.
• Press the “Start (Pause)” button; the light stops blinking and
becomes solid.
The countdown of the delay time begins; the clock symbol next to
the delay time and the colon between hours and minutes blink.
• The time delay indication disappears when the programme
starts and it is replaced by the remaining programme time.
To cancel the “Start delay”
..before you press the “Start (Pause)” button:
• Press the “Reset/Drain” button, or set the start delay time to
“0:00” - the delay time disappears after a few seconds.
..after having pressed the “Start (Pause)” button:
Press the “Start (Pause)” button - the delay time disappears
from the display; press “Start (Pause)” again to start the selected
programme immediately.
Before starting and after end of a programme, the symbol lights to
show that the door can be opened. As long as a wash programme is
running, the door remains locked and must on no account be forced
open. In case you have to open it urgently during a running
programme, refer to “Reset a running programme before the end”.
Open the tap and press the “Start (Pause)” button; the blinking
“Start (Pause)” button light becomes constant. The programme
sequence indicator shows the current programme phase, running
from left to right through wash, rinse, spin, drain. In some phases, the
remaining programme time is newly calculated - if this is the case, the
“green intelligence sensor” on the display will fade,
and the remaining time is replaced by an animation.
Activating the child lock prevents children from starting a wash
cycle or changing the settings of a running programme. The child
lock cannot be activated or deactivated when the programme
selector is in the “Off/O” position. To activate the child lock:
• Turn the programme selector to a programme position, or run
a programme as usual.
• Press the “Temperature” and the “Variable spin” button
simultaneously for at least 3 seconds. The “Child lock” symbol
will shortly blink and then light up to indicate that the
child lock is active.
The programme setting cannot be changed anymore; the only change
possible is to switch the washer off by turning the programme selector
to the “Off/O” position. To deactivate the child lock, proceed in the
same way as for activating it.
If one of the red failure indications on the display lights up, refer to
the “Troubleshooting Guide” in your “Instructions for Use”.
• The display shows “End”, and the “Door open” indication
lights up.
1. Turn the programme selector to the “Off/O” position.
2. Close the water tap.
3. Open the door and unload the machine.
• Leave the door ajar to allow the drum to dry.
• If you do not turn the programme selector to the “Off / O”
position, all lights of the control panel go out after a few minutes
to save energy - only “End” will remain on the display.
The symbol will light up at the end of the programme if you used
too much detergent. Use less detergent next time. If the symbol
lights up and the display shows “Fod”, too much foam interrupted
the wash process; refer to the “Troubleshooting Guide” in your
Instructions for Use.
1. Press the “Start (Pause)” button to pause the programme.
The light blinks.
2. Select the new programme, temperature, any options and
another spin speed if you want.
3. Press the “Start (Pause)” button again. The new programme
continues at the same position where the previous programme was
interrupted. Do not add detergent for this programme.
The “Reset/Drain” button cancels a programme before the end.
• Press the “Reset/Drain” button for at least 3 seconds; an
animation appears on the display. Any existing water is drained
out before the door can be opened.
START DELAY
“DOOR OPEN” INDICATION
PROGRAMME START
CHILD LOCK
RED FAILURE INDICATIONS
PROGRAMME END
DETERGENT OVERDOSAGE INDICATION
CHANGE PROGRAMME AND/OR OPTIONS
AFTER PROGRAMME START
RESET A RUNNING PROGRAMME BEFORE
THE END
The Sensor Technology automatically adapts ption to the size of your wash load. Programme Time, Water and Energy consum
Produkt Specifikationer
| Mærke: | Bauknecht |
| Kategori: | Vaskemaskine |
| Model: | WAE 8759 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Bauknecht WAE 8759 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Vaskemaskine Bauknecht Manualer
30 April 2024
27 April 2024
25 April 2024
21 April 2024
19 April 2024
18 April 2024
17 April 2024
9 April 2024
8 April 2024
29 Marts 2024
Vaskemaskine Manualer
- Vaskemaskine DeLonghi
- Vaskemaskine Ikea
- Vaskemaskine Bosch
- Vaskemaskine PKM
- Vaskemaskine Gram
- Vaskemaskine TCL
- Vaskemaskine EasyMaxx
- Vaskemaskine Siemens
- Vaskemaskine Samsung
- Vaskemaskine Scandomestic
- Vaskemaskine GE
- Vaskemaskine Zanussi
- Vaskemaskine Cylinda
- Vaskemaskine Panasonic
- Vaskemaskine Candy
- Vaskemaskine Fisher & Paykel
- Vaskemaskine Gorenje
- Vaskemaskine Husqvarna
- Vaskemaskine VOX
- Vaskemaskine Miele
- Vaskemaskine Blomberg
- Vaskemaskine Concept
- Vaskemaskine Teka
- Vaskemaskine OK
- Vaskemaskine LG
- Vaskemaskine AEG
- Vaskemaskine Electrolux
- Vaskemaskine Whirlpool
- Vaskemaskine Vestfrost
- Vaskemaskine Sharp
- Vaskemaskine Hotpoint
- Vaskemaskine Kenwood
- Vaskemaskine Omega
- Vaskemaskine Hoover
- Vaskemaskine Daewoo
- Vaskemaskine Arçelik
- Vaskemaskine Sanyo
- Vaskemaskine Grundig
- Vaskemaskine De Dietrich
- Vaskemaskine Indesit
- Vaskemaskine Hotpoint Ariston
- Vaskemaskine Toshiba
- Vaskemaskine Klarstein
- Vaskemaskine Ardo
- Vaskemaskine Etna
- Vaskemaskine Infiniton
- Vaskemaskine Matsui
- Vaskemaskine Scholtès
- Vaskemaskine Hansa
- Vaskemaskine Logik
- Vaskemaskine Polar
- Vaskemaskine Westinghouse
- Vaskemaskine Thomson
- Vaskemaskine Constructa
- Vaskemaskine Hyundai
- Vaskemaskine Dyson
- Vaskemaskine AKAI
- Vaskemaskine Hisense
- Vaskemaskine Brandt
- Vaskemaskine Adler
- Vaskemaskine Black And Decker
- Vaskemaskine Camry
- Vaskemaskine Mestic
- Vaskemaskine Eurom
- Vaskemaskine TecLime
- Vaskemaskine AEG-Electrolux
- Vaskemaskine Asko
- Vaskemaskine Atlas
- Vaskemaskine BEKO
- Vaskemaskine Elvita
- Vaskemaskine Gaggenau
- Vaskemaskine Küppersbusch
- Vaskemaskine Neff
- Vaskemaskine Sandstrøm
- Vaskemaskine Smeg
- Vaskemaskine Wasco
- Vaskemaskine Clatronic
- Vaskemaskine Hitachi
- Vaskemaskine Intex
- Vaskemaskine Ariston Thermo
- Vaskemaskine Fagor
- Vaskemaskine Haier
- Vaskemaskine Bomann
- Vaskemaskine KitchenAid
- Vaskemaskine Rosieres
- Vaskemaskine Vivax
- Vaskemaskine Crosley
- Vaskemaskine Galanz
- Vaskemaskine Amica
- Vaskemaskine Finlux
- Vaskemaskine Kernau
- Vaskemaskine Caple
- Vaskemaskine Zenith
- Vaskemaskine Balay
- Vaskemaskine Cata
- Vaskemaskine Exquisit
- Vaskemaskine MPM
- Vaskemaskine Tesla
- Vaskemaskine Hanseatic
- Vaskemaskine V-Zug
- Vaskemaskine Maytag
- Vaskemaskine Domo
- Vaskemaskine Schulthess
- Vaskemaskine Bush
- Vaskemaskine Aspes
- Vaskemaskine Salora
- Vaskemaskine Nevir
- Vaskemaskine Techwood
- Vaskemaskine Inventum
- Vaskemaskine Carson
- Vaskemaskine Oceanic
- Vaskemaskine Swan
- Vaskemaskine White Knight
- Vaskemaskine Khind
- Vaskemaskine Midea
- Vaskemaskine CDA
- Vaskemaskine Frigidaire
- Vaskemaskine Frilec
- Vaskemaskine Esatto
- Vaskemaskine Calex
- Vaskemaskine SVAN
- Vaskemaskine Danby
- Vaskemaskine RCA
- Vaskemaskine Koenic
- Vaskemaskine Currys Essentials
- Vaskemaskine ECG
- Vaskemaskine Saturn
- Vaskemaskine Stirling
- Vaskemaskine Saivod
- Vaskemaskine Codini
- Vaskemaskine Cecotec
- Vaskemaskine Silver
- Vaskemaskine Morris
- Vaskemaskine Avanti
- Vaskemaskine Otsein-Hoover
Nyeste Vaskemaskine Manualer
9 Maj 2024
9 Maj 2024
8 Maj 2024
8 Maj 2024
8 Maj 2024
8 Maj 2024
7 Maj 2024
7 Maj 2024
7 Maj 2024
7 Maj 2024
