Switching off
The switching off must be possible by taking
the plug out of the socket or by means of a
mains two-poles switch placed before the
socket.
Operation
Before putting into operation, clean the inside
of the appliance (see chapter „Cleaning").
After finishing this operation please plug
in the appliance, adjust the thermostat
knob to an average position. The green and
red LEDs in the signalling block must light.
Leave the appliance work for about 2
hours without putting food inside it.
The freezing of the fresh food is possible
after min. 20 hours of operation.
Appliance description
(Item. 1)
1. Door handle
2. Door
3. Lamp housing
4. Thermostat box
5. Basket
6. Spacer for transport
Freezer operation
Temperature adjustment
The temperature of the freezer is adjusted by
means of the knob assembled on the
thermostat (item. 4), position „MAX” being the
lowest temperature.
The achieved temperatures can vary
according to the conditions of use of the
appliance, such as: place of the appliance,
ambient temperature, frequency of door
opening, extent of filling with food of the
freezer. The position of the thermostat knob
will change according to these factors.
Normally, for an ambient temperature of
approx. 32
0
C, the thermostat will be adjusted
on an average position.
The signalling system is placed on the back
side of the freezer (Item 5).
It includes:
1. Thermostat adjustment knob – the inside
temperature is adjusted.
2. green LED – shows that the appliance is
supplied with electric energy.
3. red LED – damage – lights if the
temperature in the freezer is too high. The
LED will operate 15-45 minutes after the
putting into operation of the freezer, then it
must go off. If the LED goes on during the
operation, this means that defects have
occurred.
4. LED Orange– fast freeze function activated
– by setting the knob to Superfreeze
position the orange led goes on, showing
that the appliance entered into the "fast
freeze" mode. The exit of this mode is
done automatically after 50 hours then the
appliance runs in economic mode, and the
orange led goes off.
The three LEDs give information about the
mode of operation of the freezer.
