Side 1/2

Product: FDSD012R9

Indoor/Outdoor Riser OS2 Distribution 12 Fibers

Product Description

FX Indoor/Outdoor OS2 Distribution Tight Buffer 12 Fibers OFNR Non-Unitized Black Jacket

Technical Specifications

Product Overview

Suitable Applications: Premise Backbone

Fiber Specifications

Fiber Type: OS2

Fiber Core Diameter: 8.2/125 µm

Buffer Material: PVC - Polyvinyl Chloride

Buffer Diameter: 900 µm

Fiber Count: 12

Fiber Color Coding: TIA-598-D

Outer Jacket Specifications

Strength Member: Waterblocking aramid yarns

Material: PVC - Polyvinyl Chloride

Nominal Diameter: 0.260 in (6.6 mm)

Color: Black

Number of Ripcords: 1

Optical Characteristics

Wavelength 1310 nm 1550 nm

Max. Attenuation 0.5 dB/km 0.5 dB/km

Mode Field Diameter 9.2 µm 10.4 µm

1 Gigabit Ethernet Performance 5,000 m --

10 Gigabit Ethernet Performance 10,000 m 50,000 m

Mechanical Characteristics

Min Bend Radius During Installation: 15x Cable OD

Min Bend Radius During Operation: 10x Cable OD

Max Tensile Strength During Installation: 660 N (150 lbf)

Max Tensile Strength During Operation: 200 N (45 lbf)

Crush Resistance: 220 N/cm

Bulk Cable Weight: 27 lbs/kft (40 kg/km)

Temperature Range

Installation Temp Range: -10°C to +60°C

Operating Temp Range: -40°C to +70°C

Storage Temp Range: -40°C to +70°C

Standards and Compliance

Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, Burial

Sustainability: CA Prop 65, Product Lens™, Environmental Product Declaration (EPD) Available

Flammability / Fire Resistance: OFNR, FT4

ICEA Compliance: S-104-696

European Directive Compliance: EU Directive 2015/863/EU, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16

History

Update and Revision: Revision Number: 0.213 Revision Date: 03-16-2021

Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described here in are subject to error or omission and to change without

notice, and the listing of such information and specifications does not ensure product availability.

Belden provides the information and specifications herein on an "ASIS" basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages

(including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,

negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein.

All sales of Belden products are subject to Belden's standard terms and conditions of sale.

Belden believes this product to be in compliance with all applicable environmental programs as listed in the data sheet. The information provided is correct to the best of Belden's knowledge, information and belief

at the date of its publication. This information is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. The Product

Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and

regulations based on their individual usage of the product.

Produkt Specifikationer

Mærke:	Belden
Kategori:	Kabler til computere og periferiudstyr
Model:	FDSD012R9
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 70 °C
Driftstemperatur (T-T):	-40 - 70 °C
Stik 1 køn:	Ingen
Stik 2 køn:	Ingen
Stik køn:	Ingen
Kabeldiameter:	6.6 mm
Fiberoptisk type:	OS2
Materiale for kapper:	Nylon/polyvinylchlorid (PVC)
