Side 1/66
Digital Projector
Us
er
Ma
n
u
a
l
MX805ST
Table of contents2
Important safety
instructions ................... 3
Introduction.................. 7
Projector features.....................................7
Shipping contents ......................................8
Projector exterior view...........................9
Positioning your
projector ..................... 15
Choosing a location................................15
Obtaining a preferred projected image
size..............................................................16
Connection ................. 17
Connecting a computer or monitor...18
Connecting a Component Video source
device.........................................................19
Operation ................... 20
Starting up the projector ......................20
Adjusting the projected image .............21
Using the menus......................................24
Securing the projector...........................25
Switching input signal .............................28
Magnifying and searching for details ...29
Selecting the aspect ratio ......................29
Optimizing the image .............................31
Setting the presentation timer .............35
Remote paging operations ....................36
Hiding the image......................................37
Freezing the image ..................................37
Operating in a high altitude
environment.............................................38
Use teaching template............................39
Personalizing the projector menu
display ........................................................40
Select the lamp saver mode................. 40
Shutting down the projector ............... 41
Menu operation ...................................... 42
Maintenance ............... 52
Care of the projector............................ 52
Lamp information ................................... 53
Troubleshooting......... 60
Specifications.............. 61
Dimensions .............................................. 62
Ceiling mount installation ..................... 62
Timing chart............................................. 63
Warranty and Copyright
information................. 66
Table of contents
Important safety instructions 3
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that
you follow the instructions mentioned in this manual and marked on the product.
Safety Instructions
1. Please read this manual before
you operate your projector. Save
it for future reference.
2. Do not look straight at the
projector lens during operation.
The intense light beam may damage
your eyes.
3. Refer servicing to qualified
service personnel.
4. Always open the lens shutter or
remove the lens cap when the
projector lamp is on.
5. In some countries, the line voltage is
NOT stable. This projector is
designed to operate safely within a
mains voltage between 100 to 240
volts AC, but could fail if power cuts
or surges of ±10 volts occur. In
areas where the mains voltage
may fluctuate or cut out, it is
recommended that you connect
your projector through a power
stabilizer, surge protector or
uninterruptible power supply
(UPS).
6. Do not block the projection lens with
any objects when the projector is
under operation as this could cause
the objects to become heated and
deformed or even cause a fire.
Important safety instructions4
Safety Instructions (Continued)
7. The lamp becomes extremely hot
during operation. Allow the
projector to cool for approximately
45 minutes prior to removing the
lamp assembly for replacement.
8. Do not operate lamps beyond the
rated lamp life. Excessive operation
of lamps beyond the rated life could
cause them to break on rare
occasions.
9. Never replace the lamp assembly or
any electronic components unless
the projector is unplugged.
10. Do not place this product on an
unstable cart, stand, or table. The
product may fall, sustaining serious
damage.
11. Do not attempt to disassemble this
projector. There are dangerous high
voltages inside which may cause
death if you should come into
contact with live parts. The only
user serviceable part is the lamp
which has its own removable cover.
Under no circumstances should you
ever undo or remove any other
covers. Refer servicing only to
suitably qualified professional
service personnel.
12. When the projector is under
operation, you may sense some
heated air and odor from its
ventilation grill. It is a normal
phenomenon and not a product
defect.
Important safety instructions 5
Safety Instructions (Continued)
13. Do not place this projector in any of
the following environments.
- Space that is poorly ventilated or
confined. Allow at least 50 cm clearance
from walls and free flow of air around
the projector.
- Locations where temperatures may
become excessively high, such as the
inside of a car with all windows rolled up.
- Locations where excessive humidity,
dust, or cigarette smoke may
contaminate optical components,
shortening the projector's life span and
darkening the image.
- Locations near fire alarms
- Locations with an ambient temperature
above 40°C / 104°F
- Locations where the altitudes are higher
than 3000 m (10000 feet).
14. Do not block the ventilation holes.
- Do not place this projector on a blanket,
bedding or any other soft surface.
- Do not cover this projector with a cloth
or any other item.
- Do not place inflammables near the
projector.
If the ventilation holes are seriously
obstructed, overheating inside the
projector may result in a fire.
15. Always place the projector on a level,
horizontal surface during operation.
- Do not use if tilted at an angle of more
than 10 degrees left to right, nor at angle
of more than 15 degrees front to back.
Using the projector when it is not fully
horizontal may cause a malfunction of, or
damage to, the lamp.
3000 m
(10000 feet)
0 m
(0 feet)
Important safety instructions6
Safety Instructions (Continued)
16. Do not stand the projector on end
vertically. Doing so may cause the
projector to fall over, causing injury or
resulting in damage to the projector.
17. Do not step on the projector or place
any objects upon it. Besides probable
physical damage to the projector,
doing so may result in accidents and
possible injury.
18. Do not place liquids near or on the
projector. Liquids spilled into the
projector may cause it to fail. If the
projector does become wet,
disconnect it from the power supply's
wall socket and call BenQ to have the
projector serviced.
19. This product is capable of displaying
inverted images for ceiling mount
installation.
Use only BenQ's Ceiling Mount Kit for
mounting the projector and ensure it is
securely installed.
Introduction 7
Introduction
Projector features
This model is one of the best projectors available in the world. You can enjoy the best
performance video quality with up to 300-inch projection across various devices such as
PC, laptop, DVD and VCR even document camera to bring all possibility to life.
The projector offers the following features
• SmartEco™ starts your dynamic power saving
SmartEco™ technology saves lamp power consumption up to 70% depending on the
content brightness level when SmartEco mode is selected
• Longer hours lamp life with SmartEco™ technology
SmartEco™ technology increases the lamp life hours when selecting SmartEco mode
to lower the power consumption
• ECO BLANK saves 70% of lamp power
Pressing the ECO BLANK bottom to immediately hide the image, lowering 70% of the
lamp power at the same time your image is hiding
• Less than 0.5W in standby condition
Less than 0.5W power consumption under standby mode
• One-key auto-adjustment
Pressing AUTO on the keypad or remote control to show the best picture quality
immediately
• Quick Cooling, Auto Power Off, Direct Power On
Quick Cooling function speeds up the cooling process when turning off the projector.
Auto Power Off function allows the projector to turn off automatically if no input signal
is detected after a set period of time. Direct Power On turns your projector when the
power is fed.
• Instant Restart
Selectable Instant Restart function enables you to restart the projector immediately
within 90 seconds after turning it off.
• 3D Function supported
Various 3D formats make the 3D function more flexible. By presenting the depth of the
images, you can wear BenQ 3D glassed to enjoy the 3D movies, videos and sporting
events in a more realistic way.
• The apparent brightness of the projected image will vary depending on the ambient lighting
conditions, selected input signal contrast/brightness settings, and is proportional to
projection distance.
• The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.
Introduction8
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these items
are missing, please contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those illustrated.
*The warranty card is only supplied in some specific regions. Please consult your dealer for
detailed information.
Optional accessories
Projector Power cord VGA cable
Quick start guide User manual CD Warranty card*
Remote control with battery
Digi t
al Proj
ec tor
QQ
uick Sta rt Gu
id eu
ick Sta rt G u
id e
1. Spare lamp kit
2. Ceiling mount kit
3. Carry bag
4. 3D glasses
5. Presentation plus
Introduction 9
Projector exterior view
1. External control panel
(See "Projector" on page 10 for
details.)
2. Lamp cover
3. Focus ring
4. Vent (heated air exhaust)
5. Front IR remote sensor
6. Projection lens
7. Quick-release button
8. RGB (PC)/Component video
(YPbPr/ YCbCr) signal input jack
9. RGB signal output jack
10. RS-232 control port
11. USB input jack
12. Kensington anti-theft lock slot
13. AC power cord inlet
14. Ceiling mount holes
15. Rear adjuster foot
1
3
2
4
5
6
7
Front/upper side
7
89 10 11 12
13 14 15
Rear/lower side
