Side 1/7

English

1. Please read and follow the instructions in this installation guide carefully

before installation and retain them for future reference.

2. The BenQ Corporation is not liable for any damage or injury resulting from

incorrect installation.

3. The wall mounting bracket is designed for easy installation and removal. The

BenQ Corporation accepts no liability for any damage or injuries due to

human action or from natural causes, such as an earthquake or typhoon.

4. This projector wall mounting bracket must only be installed by service

professionals.

5. At least two persons are required for the installation or removal of this bracket

to prevent personal injury, or material damage from heavy falling objects.

6. To ensure proper ventilation, install the projector with sucient clearance

between it and the wall and ceiling.

7. To ensure safe installation and avoid accidents, check the wall structure and

select a solid durable location.

8. The wall should be strong enough to support four times the total weight of

the projector and the wall mounting bracket, or more. It should also be of

sucient strength to bear the force of vibrations from earthquakes or other

events.

9. Check the surroundings of the mounting location before installation.

• Do not install in places where the temperature or humidity is high and

avoid moisture.

• Do not install near an air conditioner or vents, or in excessively dusty or oily

places.

• This product must only be installed on a vertical wall, not a slanting one.

• Do not install in places subject to vibration or shock.

• Keep the projector out of direct sunlight

10. Do not replace any parts or use damaged parts. Please contact your retailer if

you have any questions.

11. Fix the screws tightly but not excessively to avoid breakage or damage to the

threads.

12. The wall mounting bracket can support a maximum projector weight of

5J.J3A10.021: 15Kg or 33.07 lbs 5J.J4V10.011/5J.J4R10.011: 12Kg or 26.46 lbs.

13. Nothing extra must be added to the load on the wall mounting bracket.

Nothing should be attached or hung from it.

14. Holes for the screws will remain in the walls after the projector mounting

bracket has been removed and marks may also result from long term use.

Warning

English

1 Warning　　

2 Introduction　　

English

Introduction

P.4

P.3

P.7

Required Tools / Torque Adjustment

Installation Steps

Packaged Parts

P.6

P.5

Specications / Size / Guide sheet for hole drilling

P.4

Angle Adjustment

1. Adjust the mounting bracket arm of the projector to 5°.

2. Adjust the rotation angle of the sides of the projected image.

3. Adjust the angular displacement of the top and the bottom of the projected image.

4. Adjust the horizontal angular displacement of the projected image.

5.Move the base plate(A)inside the rails the rails (B) to enable projector horizontally lateral moves.

6. Adjust the distance between the projector and the projected image: (A) Move the projector bracket.

(B) or adjust the distance of the projection.

1. Installing the wall bracket

A. Make sure the wall bracket (P) is in the correct position on the wall. Hold the bracket (P) rmly against the wall and mark the places for the

holes with a pencil.

Drill the holes at the marked points. The holes for a masonry wall should be 10mm (0.39”) in diameter and 55mm deep (2.17”). Use a

hammer to drive the plastic plugs (C) into the holes.

For a wooden wall, drill 4.5mm (0.17”) diameter holes 55m (2.17”) deep.

B. Screw the self-tapping screws (C) into the wall.

C. Push the power cord into the front end of the projector main support member and pull it out at the back.

D. Insert and secure the socket head screw M6 x L8 (F) in the holes of the projector main support member (Q) and the wall bracket (P) by using

a 5mm hex wrench (K). It is necessary to leave a gap of 0.5mm for adjustment of the angle after assembly.

E. Before positioning the hinge module (A), secure the socket head screw (H) in the projector main support member (Q) to enable the

cantilever support to be in the horizontal direction.

2. Installing the xing bracket on the bottom of the projector

A. Install the projector bracket (A) on the projector, using shim screws (I) and sleeves (J) to fasten these 3 parts onto the projector.

B. Align the holes in the hinge connector (D) with those in the hinge module (A). Insert M6 x L10 (F) hex head screws into the holes and

tighten them with Wrenches (K). Allow 2-3mm clearance for installing the bracket on the arm.

3. Installing the bracket on the bottom of the projector arm

A. Assemble the hinge module (A) and the projector main support member (Q).

B. After attaching the projector bracket (A) to chassis (Q), tighten both with a wrench (L).

4. Cable Management

A. Plug the power cord into the projector.

B. Fit the plastic cap (M) to the end of the projector main support member (Q).

C. Pass the power cord through the lower plastic cover (O) and then t the upper (N) and lower (O) plastic covers as shown.

5. Adjusting the projection angle

A. Using a hex wrench (K) to adjust the tightness of the internal hex screws (H), the projector may be adjusted to the required angle.

After adjustment to the required angle, tighten internal hex screws (F) using the 5mm hex wrench (K), then replace

the upper and lower plastic cover (N)(O).

B. The gray knob (A) is used to adjust the sideways rotation angle of the projected image.

C. The yellow knob (B) is used to adjust the angular displacement of the top and bottom of the projected image.

D. The black knob (C) is used to adjust the horizontal angular movement of the projected image.

E. Move the base plate(A)inside the rails the rails (B) to enable projector horizontally lateral moves.

Produkt Specifikationer

Mærke:	BenQ
Kategori:	Tilbehør til projektor
Model:	WM04G3
Bredde:	110 mm
Dybde:	803 mm
Højde:	215 mm
Vægt:	4020 g
Produktfarve:	Metallic, White
Monteringstype:	Væg
Harmoniseret systemkode (HS):	83024190
Hældningsvinkelområde:	-10 - 10 °
Maksimal vægtkapacitet:	12 kg
Justerbar:	Ja
Afstand til væggen (maks.):	705 mm
