Side 1/8
Installation & Maintenance Instructions
TABLE OF CONTENTS
I. UNCRATING......................................................................................................................................................................................................... 2
II. MOUNTING INSTRUCTIONS ............................................................................................................................................................................ 2
III. WALL MOUNTING ............................................................................................................................................................................................ 3
IV. SUSPENDED MOUNTING ............................................................................................................................................................................... 4
V. VERTICAL MOUNTING ..................................................................................................................................................................................... 4
VI. TANDEM MOUNTING BRACKETS (for Vertical Mounting)....................................................................................................................... . 4
VII. ELECTRICAL CONNECTIONS ....................................................................................................................................................................... . 4
VIII. MECHANICAL CONNECTIONS ................................................................................................................................................................... . 5
IX. OPERATION INSTRUCTIONS ........................................................................................................................................................................ . 6
X. MAINTENANCE AND CLEANING .................................................................................................................................................................... 6
XI. SERVICE ............................................................................................................................................................................................................ 6
XII. WARRANTY .................................................................................................................................................................................................... . 8
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A. Read all instructions before installing or using this air curtain.
B. Use this unit only in the manner intended by the manufacturer and described in this manual. Any other use not recommended by the
C. Before servicing or cleaning unit, switch power o at service panel and lock the service disconnecting means to prevent power from
being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device,
such as a tag, to the service panel.
D. Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable national and local codes
having jurisdiction, including re-rated construction. See page 4, ELECTRICAL CONNECTIONS (NEC Code ANSI/NFPA No. 70).
E. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
F. To reduce the risk of re, do not store or use gasoline or other ammable vapors and liquids in the vicinity of the air curtain.
G. This air curtain is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, etc. and curtains at least 1 inch from the top, back, front, sides and at least 6 feet from the discharge of
the air curtain.
H. Extreme caution is necessary when any air curtain is used by or near children or invalids, and whenever the heater is left operating
unattended.
I. Do not operate any air curtain after it malfunctions. Disconnect power at the service panel and have the air curtain inspected by a
reputable electrician before reusing.
J. To disconnect the air curtain, turn controls to “o”, and turn o power to the air curtain circuit at main disconnect panel.
K. Do not insert or allow foreign objects to enter any ventilation or discharge opening as this may cause an electric shock or re, or damage
the air curtain.
L. To prevent a possible re, do not block the air intake or discharge of the air curtain in any manner.
M. The air curtain has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or ammable vapors or liquids are
used or stored.
N. This heater may include an audible or visual alarm to warn that parts of the heater are getting excessively hot. If the alarm sounds (or
illuminates), immediately turn the heater o and inspect for any objects on or adjacent to the heater that may have blocked the airow or
otherwise caused high temperatures to have occurred. DO NOT OPERATE THE HEATER WITH THE ALARM SOUNDING (OR ILLUMINATING).
READ AND SAVE
THESE INSTRUCTIONS
No. II-230
Date December, 2022
IMPORTANT INSTRUCTIONS
Saving energy and creating healthy, comfortable environments
INDUSTRIAL
Direct Drive 12 & 14
AIR CURTAIN SERIES IDC12 / IDC14
for outdoor use
unheated only
FDA
RECOMMENDED
USDA
COMPLIANCE
®
-2-
I. UNCRATING
Carefully examine the carton(s) for damage before opening. If
the carton is damaged, immediately notify shipping company.
If the unit(s) were shipped on wooden skids, remove protective
wood and banding straps securing the carton(s) to the skid.
Open the carton(s) and remove all protective packaging. Im-
mediately verify that the electrical rating nameplate located on
the cover matches the electrical power supply available. Retain
the shipping carton(s) until the unit(s) is installed and properly
operating.
ACCESSORIES: If the unit(s) were ordered with optional electri-
cal accessories (door switch, control panel, etc.), the accessories
may be found in the carton containing the unit or in a separate
carton(s) accompanying the unit(s). Check all of the cartons/
skids for accessories before discarding.
II. MOUNTING INSTRUCTIONS
(General Notes for All Mounting Congurations)
INDOOR MOUNTING - Environmental/Insect/Dust Control
OUTDOOR MOUNTING (Unheated Only) - Insect/Dust Control
A. Berner IDC12/IDC14 air doors are designed to be mounted
by their end anges without the need for intermediate
support. Each end ange contains (8) total ½” holes located
on all (4) sides to facilitate mounting exibility and the easy
addition of mounting accessories. Units may be attached to
the wall directly, suspended from overhead, or supported
by brackets. The style of door will determine the best
mounting method and; as a general rule, use the mounting
conguration that positions the air door as close to the top
of the doorway as possible without interfering with door
operation.
B. The IDC12/IDC14 Series air door is designed to be an
eective barrier against cold drafts in the winter and hot
air in the summer. To achieve optimum protection, the
unit should be mounted on the inside of the building, ush
to the wall and as close to the top of the door opening as
possible. To ensure peak performance keep the air stream
free of obstructions. If the air door cannot be installed ush
with the wall, be sure to seal the gap between the wall and
the back of the air door along the entire length of the unit to
prevent airow through this void.
C. The air door will not perform properly if negative air
pressure exists in the building. Under these conditions,
a means for makeup air to the building must be provided
so that the air pressure on both sides of the opening is in
balance.
D. Before mounting the air door, check the supporting
structure to verify that it has sucient load-carrying capacity
to support the weight of the unit(s). The mounting hardware
(supplied by others) should be capable of supporting a
minimum of three (3) times the weight of the unit. See
Tables 1 & 2.
TABLE 1
TABLE 2
Model
Weight by Unit Type
Ambient
Electric
Heat
Steam
Heat
Hot
Water
Heat
Indirect
Gas
Heat*
IDC12-1036 90 96 130 130 125
IDC12-1042 101 107 145 145 125
IDC12-1048 109 115 158 158 125
IDC12-1060 119 125 178 178 125
IDC12-2060 160 172 219 219 130
IDC12-2072 167 179 229 229 130
IDC12-2078 178 190 244 244 130
IDC12-2084 188 200 258 258 130
IDC12-2096 203 215 282 282 130
IDC12-3096 233 251 312 312 145
IDC12-2108 212 224 296 296 130
IDC12-3108 251 269 335 335 145
IDC12-2120 221 233 311 311 130
IDC12-3120 272 290 362 362 145
IDC12-3132 289 307 390 390 145
IDC12-3144 304 322 412 412 145
IDC12-4144 335 359 443 443 225
IDC12-4156 355 379 471 471 2 @ 130
IDC12-4168 376 400 499 499 2 @ 130
IDC12-4180 391 415 523 523 2 @ 130
IDC12-5180 419 449 551 551 2 @ 145
IDC12-4192 405 429 544 544 2 @ 130
IDC12-5192 435 465 574 574 2 @ 145
* Weight includes heater and duct transition
Model
Weight by Unit Type
Ambient
Electric
Heat
Steam
Heat
Hot Water
Heat
Indirect
Gas
Heat*
IDC14-1036 93 99 133 133 125
IDC14-1042 104 110 148 148 125
IDC14-1048 112 118 161 161 125
IDC14-1060 122 128 181 181 125
IDC14-2060 163 175 222 222 145
IDC14-2072 170 182 232 232 145
IDC14-2078 181 193 247 247 145
IDC14-2084 191 203 261 261 145
IDC14-2096 206 218 285 285 145
IDC14-3096 236 254 315 315 270
IDC14-2108 215 227 299 299 145
IDC14-3108 254 272 338 338 270
IDC14-2120 224 236 314 314 145
IDC14-3120 275 293 365 365 270
IDC14-3132 292 310 393 393 285
IDC14-3144 307 325 415 415 285
IDC14-4144 338 362 446 446 285
IDC14-4156 358 382 504 504 2 @ 145
IDC14-4168 379 403 534 534 2 @ 145
IDC14-4180 394 418 561 561 2 @ 145
IDC14-5180 422 452 589 589 2 @ 225
IDC14-4192 408 432 584 584 2 @ 145
IDC14-5192 438 468 614 614 2 @ 225
* Weight includes heater and duct transition
