Thank you for choosing Berner.

Berner International has been saving energy and creating healthy, comfortable environments for our customers

for over 60 years. Berner oers unmatched quality, performance, and dependability—not to mention our service.

At Berner, we stand behind our products.

1. To operate using the built-in Intelliswitch digital controller, proceed to the Quick Start Operation Guide.

NOTE: For a detailed Intelliswitch Programming Guide, go to www.Berner.com/Intelliswitch

2. Unheated units will have the fans activated by a door switch or sensor. The unit speed can be selected via the

Intelliswitch™ display or the Berner AIR App*

3. Heated units will have fans activated by a door switch or sensor, but may also be activated by the thermostat in

Comfort Plus Mode. The unit's speed can be selected via the Intelliswitch display or the Berner AIR App.*

4. To operate using the Berner AIR™ App*, download the app and follow the prompts. Requires on-site, secure

wi- connection. Berner recommends having the on-site user(s) set-up the Berner AIR™ App on his/her smart phone.

5. To operate using BACnet-IP client, download the Berner AIR™ App*. In the settings menu of the app, select the

BACnet option. Follow the prompts to congure the BACnet controller.

To connect via wire, see Appendix BACnet-IP Integration.

*NOTE: The air curtain must have been ordered from the factory with the Berner AIR (smart controller & App) option.

A. GENERAL OPERATIONS

December, 2022

©Copyright, 2022 Berner International

READ ALL INSTRUCTIONS BEFORE INSTALLING OR USING AIR CURTAIN

Industrial Air Curtain

with Intelliswitch™

www.Berner.com

WHEN THE DOORS ARE OPEN

™

save energy & create healthy, comfortable environments

This air curtain comes with the Berner Intelliswitch™ Digital Controller

built-in to control and schedule fan activation, fan speed selection, and heat activation.

If the optional Berner AIR™ system (smart controller and app) was ordered, it includes additional features

such as BACnet capability. The air curtain must be properly installed before either of these can be used.

A. Read all instructions before installing or using this air curtain.

B. Use this unit only in the manner intended by the manufacturer and described in this manual. Any other use not recommended by the

manufacturer may cause re, electric shock, or injury to persons. If you have any questions, contact the manufacturer.

C. Before servicing or cleaning unit, switch power o at service panel and lock the service disconnecting means to prevent power from

being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device,

such as a tag, to the service panel.

D. Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable national and local codes

having jurisdiction, including re-rated construction. See page 5, ELECTRICAL CONNECTIONS (NEC Code ANSI/NFPA No. 70).

E. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.

F. To reduce the risk of re, do not store or use gasoline or other ammable vapors and liquids in the vicinity of the air curtain.

G. This air curtain is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture,

pillows, bedding, papers, clothes, etc. and curtains at least 1 inch from the top, back, front, sides and at least 6 feet from the discharge

of the air curtain.

H. Extreme caution is necessary when any air curtain is used by or near children or invalids, and whenever the heater is left operating

unattended.

I. Do not operate any air curtain after it malfunctions. Disconnect power at the service panel and have the air curtain inspected by a

reputable electrician before reusing.

J. To disconnect the air curtain, turn controls to "o", and turn o power to the air curtain circuit at main disconnect panel.

K. Do not insert or allow foreign objects to enter any ventilation or discharge opening as this may cause an electric shock or re, or

damage the air curtain.

L. To prevent a possible re, do not block the air intake or discharge of the air curtain in any manner.

M. The air curtain has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or ammable vapors or liquids

are used or stored.

N. This heater may include an audible or visual alarm to warn that parts of the heater are getting excessively hot. If the alarm sounds

(or illuminates), immediately turn the heater o and inspect for any objects on or adjacent to the heater that may have blocked the airow

or otherwise caused high temperatures to have occurred. DO NOT OPERATE THE HEATER WITH THE ALARM SOUNDING (OR ILLUMINATING).

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

-2-

www.Berner.com/intelliswitch

NOTE – to navigate, use to select setting

use to change setting,

then press to enter the setting.

Stop: OFFImmediately stops the air curtain and changes mode to

"i": info button provides controller status and diagnostic data

Mode/Fan Speed:

Mode: Select your mode of operation (see next page)

Fan Speed: Sets the fan speed

Delay Time: Sets the amount of time the air curtain runs after the door closes

Temp Set: )Sets the temperature the air curtain will maintain (heated units only

Start Time: Programs the time of day the air curtain becomes active

Stop Time: Programs the time of day the air curtain stops running

Set Time/Day: Sets the clock time and day (used by programming)

Locked: Unit will run as programmed but settings cannot be changed

NOTE: Start/Stop time must be the same for the air curtain to operate continuously.

QUICK START INSTRUCTIONS

For your Berner Air Curtain with Intelliswitch™ Gen4

IMPORTANT NOTE!

If your air curtain unit is in “Locked” mode when you receive it:

Press and hold the for 5 seconds to unlock.

www.berner.com 800.245.4455 Berner International

111 Progress Ave. / New Castle / PA / 16101 / USA
