Bertazzoni Z122 6G MFE RO Manual

Bertazzoni Komfur Z122 6G MFE RO

Læs gratis den danske manual til Bertazzoni Z122 6G MFE RO (20 sider) i kategorien Komfur. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 3.6 stjerner ud af 29 anmeldelser. Har du et spørgsmål om Bertazzoni Z122 6G MFE RO, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/20

INSTALLATION, MAINTENANCE AND USE

INSTRUCTIONS FOR

FREE-STANDING COOKERS

121,9x64 cm (type MT/MTV)

X1226GMFE

READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING

THE APPLIANCE.

The manufacturer will not be responsible for any damage to property or to persons

caused by incorrect installation or improper use of the appliance.

The manufacturer is not responsible for any inaccuracies, due to printing or transcription

errors, contained in this booklet. In addition, the appearance of the figures reported is also

purely indicative.

The manufacturer reserves the right to make changes to its products when considered

necessary and useful, without affecting the essential safety and operating characteristics.

CONTENTS:

INSTALLER TECHNICAL MANUAL ............................................................................................................... pg. 2

Installing the cooker - Installation information ................................................................................................. pg. 2

Ventilation and aeration of rooms .................................................................................................................... pg. 3

Height adjustable legs .................................................................................................................................... pg. 3

Backguard installation instruction ................................................................................................................... pg. 3

Gas connection ............................................................................................................................................... pg. 3

Adaptation to different types of Gas and burner adjustments.......................................................................... pg. 4

Electric connection .......................................................................................................................................... pg. 5

APPLIANCE MAINTENANCE - Replacing parts

.......................................................................................

...... pg. 6

USE AND MAINTENANCE MANUAL ............................................................................................................. pg. 6

Description of control panel and control types ................................................................................................. pg. 7

Using burners .................................................................................................................................................. pg. 7

Using the electric griddle ................................................................................................................................. pg. 8

Using the electric thermostat ........................................................................................................................... pg. 8

Using the 9+0 switch.......................................................................................... .............................................. pg. 8

Using the thermostat with switch in series....................................................................................................... pg. 9

Using the natural conventional electric oven .................................................................................................. pg. 9

Using the ventilated electric oven .................................................................................................................... pg. 10

Positioning the oven trays & shelves ............................................................................................................... pg. 11

Using the electric grill ..................................................................................................................................... pg. 11

Using the ventilated electric grill ...................................................................................................................... pg. 11

Using the self cleaning oven .......................................................................................................................... pg. 11

Abnormal Operation ........................................................................................................................................ pg. 12

Cleaning the appliance .................................................................................................................................... pg. 12

After-sales technical service and spare parts .................................................................................................. pg. 12

THIS APPLIANCE HAS BEEN DESIGNED FOR NON-PROFESSIONAL DOMESTIC USE.

INSTALLER TECHNICAL MANUAL

By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could

otherwise be caused by inappropriate waste handling of this product.

The symbol on the product indicates that this product may not be treated as

household waste. Instead it shall be handed over to the applicable collection point

for the recycling of electrical and electronic equipment.

Disposal must be carried out in accordance with local environmental regulations for waste disposal.

For more detailed information about treatment, recovery and recycling of this product, please

contact your local city council office.

INSTALLER INFORMATION

The installation, all adjustments, transformations and maintenance listed in this part of the manual must be

carried out only by skilled personnel.

Improper installation may cause damage to persons, animals or property, for which the manufacture will not be

held responsible.

The appliance safety or automatic adjustment devices may be changed during the service life of the system only

by the manufacturer or by the duly authorised supplier.

INSTALLING THE COOKER

After having removed the various loose parts from the internal and external packing, make sure that the cooker is not

damaged. In case of doubt, do not use the appliance and contact skilled personnel.

Keep all the dangerous packing parts (polystyrene foam, bags, cardboard, staples, etc.) away from children.

The appliance can be installed as a freestanding unit, next to a wall or inserted between two walls (Fig.1). A single

sidewall that exceeds the height of the work surface is possible. This must be at a minimum distance of 70 mm from the

edge of the cooker (Fig.1)

Any walls of the adjacent furniture pieces and the wall behind the cooker must be made with heat-resistant material that

can withstand a minimum overtemperature of 65 K.

WARNING: the connection to the gas network must only use metal flexible pipes that conform with the national

standards in force.

Produkt Specifikationer

Mærke:	Bertazzoni
Kategori:	Komfur
Model:	Z122 6G MFE RO
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	1222 mm
Dybde:	640 mm
Højde:	902 mm
Produktfarve:	Rød
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Produkttype:	Fritstående komfur
Strøm:	26.65 A
Grill:	Ja
Konvektion madlavning:	Ja
Justerbare fødder:	Ja
Komfurtype:	Gaskomfur
Overfladetype:	Rustfrit stål
Antal kogeplader / madlavningsområde:	6
Blus/kogeplade zone 1 strøm:	1000 W
Blus/kogeplade zone 2 strøm:	1750 W
Kontrolposition:	Front
Tilsluttet belastning (elektrisk):	5900 W
Antal glasdørpaneler:	3
Varmebeskyttende dør:	Ja
Samlet indvendig ovn kapacitet:	142 L
Strøm for samtlige ovne:	- W
Antal ovne:	2
Ovn nettokapacitet:	86 L
Automatiske programmer, antal:	9
Ovn effekt:	- W
Blus/kogeplade zone 4 strøm:	5000 W
Blus/kogeplade zone 3 strøm:	3000 W
Elektronisk tænding:	Ja
Ovn strømkilde:	Elektrisk
Ovn samlet kapacitet:	86 L
Ovn 2 samlet kapacitet:	56 L
Opbevaringsrum:	Ja
