negative ions exiting from the air outlet.This dust
does not come from the air output, but is drawn out
of the uncleaned air going past the air outlet.
This is additional evidence of the air cleaning
effectiveness of negative ions. The dust can be easily
removed with a clean, dampened cloth or soft brush.
NOTE: it is important to clean the permanent
HEPA filters at recommended intervals. Using the
ioniser in conjunction with dirty filters may result in
dirty particles exiting the air purifier and being
attracted to walls, carpets, furniture and other
household objects. These dirty particles may prove
very difficult to remove.
PRE-OPERATING INSTRUCTIONS
1. After removing the unit from the box, remove
the plastic covering from the unit.
2. Select a firm level place where there are no
obstructions to the air inlet (rear grill) or
3. Remove the inlet grill by pulling the grill
4. Remove both permanent HEPA filters by
gripping on both sides and pulling forward.
5. The filter clip can only be attached to the
hang tabs on the filter one way (see Fig. 2).
The filter clip should easily slide onto the filter
hang tabs. Do not use force whilst attaching
the filter clip to the filter. Align the clip on the
permanent HEPA filter with the rails on the
inside of the unit.(see Fig. 3)
NOTE:The pleated material and rubber gasket
should be facing towards the unit when applied.
6. Replace the inlet grill by sliding back on to the
unit. Make sure that it snaps securely into
position (the grill only goes on one way).
NOTE:Do not point outlet towards wall.
Your remote control requires (2) AAA batteries
(not included) for operation. To install the
batteries, simply depress and slide the back of
the remote control with your thumb on the arrow
indentation. Insert batteries according to the
diagram shown inside and replace cover. Remove
batteries before discarding the remote control.
• DO NOT mix old and new batteries.
• DO NOT mix alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium) batteries.
1. Plug into a suitable electrical outlet.
2. Press the power button ( ) on the control
panel or the remote control. The unit will turn
on high only the first time the unit is turned
on. All other times it is turned on, the unit
remembers the last speed selected and will
turn on at that speed, and the power light will
illuminate letting you know the power is on.
3. You can then select the desired speed
setting. This air cleaner has three speed
settings. You can select from HIGH ( ),
MEDIUM( ), or LOW ( ) by pushing the
desired operating speed button on the control
panel or the remote control.
4. To release negative ions into the filtered air,
press the ioniser button ( ) to either on the
control panel or the remote control and the
5. The ioniser will not work unless the unit is running.
6. For optimum air filtration, it is recommended to
operate the air purifier continuously. Its rugged
motor is designed to give many years of service.
7. For continuous use it is recommended to operate
the air purifier at the Medium ( ) setting. For
quieter operation or use in a bedroom, select the
Low ( ) setting. When high levels of air pollution
are present, select the HI ( ) setting to quickly
circulate clean filtered air.
1. Turn the air purifier off and unplug it before
2. The outside of the air purifier can be cleaned
with a soft, clean dampened cloth.
3. The rear air inlet grill can be removed and
washed in warm soapy water (not dishwasher
safe). Dry before replacing in the unit.
4. The filtered air outlet can be cleaned of dust
with a small, soft brush.
5. If you wish to clean the inside of the air purifier,
please only use a dry, soft cloth to wipe it down.
PERMANENT HEPA FILTER CLEANING
Filter Indicator Light ( ) - Your air purifier has
an indicator light that illuminates when it is time
to clean the permanent HEPA filters.
1. Every few weeks check the condition of the
2. Remove the inlet grill. If the foam pre-filter has
collected a noticeable amount of dust, remove it
from the inlet of the grill and wash it in warm soapy
water. Rinse and dry the pre-filter thoroughly
before replacing it in the inlet of the grill.
3. With the inlet grill removed, check the
condition of your permanent HEPA filters. If
the filters are dirty, remove them by gripping
on both sides and pulling forward.
4. To clean the permanent HEPA filters use a
crevice tool or brush attachment with your
vacuum cleaner. Run the attachment along the
inlet and outlet side of the filter trying to clean
between the pleated filter layers. (see Fig. 4).
NOTE: Vacuuming will restore performance
of the permanent HEPA filter however, the
filter may appear stained. This is normal and
does not affect performance in any way.
DO NOT USE WATER OR ANY OTHER
5. This model utilises a hang tab and filter clips to
insure that the filter is properly in place. Before
replacing the permanent HEPA filter make sure
that the hang tab is securely in place.
6. Align the clips on the side of your permanent
HEPA filter with the rails on the inside of the
unit. Gently slide the filter onto the rails.
7. The filter clip should easily slide onto the filter
hang tabs. Do not use force while attaching the
filter clip to the filter. Align the clip on the side
of your permanent HEPA filter with the rails on
the inside of the unit. (see Fig. 2 and 3)
NOTE: The pleated material and rubber gasket
should be facing towards the unit when applied.
8. Replace the inlet grill by sliding back on to the
unit. Make sure that it snaps securely into
position (the grill only goes on one way).
NOTE: Do not point outlet towards wall.
9. The filter life indicator ( ) must be reset
once the permanent filters have been cleaned.
Reset indicator by pressing the power button
( ) on the control panel for 2 seconds.
Filter Life – The filter has been designed to never
need replacement, however, it does need servicing.
We recommend that under normal conditions of
continuous use, the filters should be cleaned at least
every 3 months to help maintain optimal performance.
Should the filter become damaged during
cleaning replacements are available by calling
PERMANENT HEPA filter Filters
Holmes Products (Europe) Ltd reserves the right
to change or modify any specifications without
For U.K. and Ireland only:
If the plug is not suitable for the socket outlets in
your home, it can be removed and replaced by
a plug of the correct type. Please refer to
"Installation of a plug" below.
Installation of a plug Applicable to
WARNING - THIS APPLIANCE MUST BE
The wires in the mains lead are coloured as such:
Please note that the colour of these mains wires
may not correspond with the colour markings
that identify the terminals in your plug.
Please proceed as follows:
The wire which is coloured GREEN AND YELLOW
must be connected to the terminal which is marked
with the letter 'E' or by the earth symbol or
coloured GREEN AND YELLOW.
The BROWN coloured wire must be connected
to the terminal, which is marked with the letter
The BLUE coloured wire must be connected to
the terminal, which is marked with the letter "N"
NOTE: If the terminals in the plug are not marked
or if you are unsure or in doubt about the installation
of the plug please contact a qualified electrician.
If a 13A 3-pin plug is fitted, it must be an ASTA
approved plug, conforming to BS1363 standard.
Replacement 3A fuses must be BSI or ASTA
PLEASE KEEP YOUR RECEIPT AS THIS WILL
BE REQUIRED FOR ANY CLAIMS UNDER
• This appliance is guaranteed for 2 years.
• In the unlikely event of breakdown from a
manufacturing related fault, please return it to
the place of purchase, with your till receipt
and a copy of this guarantee.
• The rights and benefits under this guarantee
are additional to your statutory rights which
are not affected by this guarantee.
• Holmes Products (Europe) Ltd undertakes
within the specifiied period, to repair or replace free
of charge, any part of the appliance found to be
defective from a manufacturing fault provided that:
Check to make sure the unit is
Check to make sure the unit is on
by pressing the power button.
Make sure the filters are properly
installed and firmly close the door.
If the Filter Life Indicator ( ) is
red, the permanent HEPA filter
Check the filter to make sure
they are in good condition.
Check to ensure nothing is blocking
the air inlet and filtered air outlet.
Make sure filter bags are
PLEASE READ AND SAVE THESE
With proper care and use, this Bionaire
air purifier will give you fresh, clean air
NOTE: Before reading these instructions, please
view the corresponding illustrations.
DESCRIPTIONS (SEE FIG. 1 & FIG. 1-A)
F. Washable Foam Pre-filter
H.Permanent HEPA filters (2 pcs)
L. Operation Indicator Light
Carefully read and retain all instructions before
• To avoid fire or shock hazard, check that the
voltage on the product corresponds to your
electricity supply and plug directly into an
• Keep cord out of heavy traffic areas and to
avoid fire hazard, never put the cord under
rugs, or near any heat source.
• Carefully discard any plastic wrapping that
was used for the packaging. If the filter is
covered by a bag when shipped, remove
• Do not use the air purifier outside.
• Do not place the unit near any heat source or
• Always unplug the air purifier before moving it,
opening the grill, changing the filters, cleaning the
air purifier or whenever it is not in use.
• Do not use in or around water or any other
liquids. Do not attempt to wash the unit under
• Use appliance only for intended household
use as described in this manual.
• Ensure that all air openings are not restricted
• Do not place anything on top of the unit.
• Never insert any object into any openings.
• Do not use the air purifier if any part is
missing or damaged in any way.
• Do not attempt to repair or adjust any
mechanical functions of this unit. If the unit
becomes damaged return to the place of
purchase or phone the helpline number on
the back of this leaflet.
• If the supply cord or plug is damaged, it must
be replaced by the manufacturer or its service
agent or a similarly qualified person in order
• The air purifier contains no user serviceable
parts and should the product suffer damage
or breakdown it must be returned to the
manufacturer or its service agent.
• Should the air purifier stop working, first check the
fuse in the plug (UK only) or fuse/circuit breaker at
the distribution board is operating, before
contacting the manufacturer or service agent.
• The ioniser may cause a static charge to build
up on the air output grill. A static charge may
be felt if the unit is not properly grounded. To
avoid a static charge, plug the unit into a
grounded outlet, or properly install a ground
adaptor. The static shock will not occur if the
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
HOW THE AIR PURIFIER WORKS
Dirty, dust laden air is drawn through the back of
the air purifier and through the multi-stage
The permanent HEPA filter entraps 99% of all
smaller visible and non-visible particles down to
Air Purifier has an independently
controlled ioniser, which when turned on,
releases negative ions into the outgoing filtered
air. Ions are tiny particles that carry either a
positive or negative charge. These ions exist
naturally all around us in the air, water and
ground. Both positive and negative ions are
colourless, odourless and completely harmless.
Negative ions help the air purification process
by attaching themselves to very small airborne
particles in the room. These particles take on a
negative charge and may join with positively
charged particles, such as dust, pollen, smoke
and pet dander to form larger particles that are
then more readily captured by the filter system,
or they may be attracted to positively charged
surfaces like walls or floors.
You may also note, after extended use, that dust
may have collected around the grills or front panel.
This is from the ionisation effect caused by the
BAP1550-IUK_07EM1.qxd 4/25/07 20:46 Page 5
