Side 1/2

Description

The DA1414 is a sophisticated PoE powered audio matrix designed

as independent routing of mono audio signals, volume control,

balance adjustments, up to 8-band parametric equalizer including

stages

Equipped with 8x Dante, 4x balanced/unbalanced analogue, and

2x USB audio inputs, it supports output to 8x Dante, 4x balanced/

unbalanced analogue, and 2x USB channels. The system includes

API switching functionality, allowing users to route Dante channels

via third-party control platforms, bypassing Dante Controller or

Domain Manager. The analogue inputs also feature selectable

48V phantom power for microphone or line-level connections.

Additionally, USB-C / USB-B connectivity options ensure maximum

seamlessly routing and controlling audio signals within both

commercial and residential environments, regardless of the

source type.

DA1414

437mm

P HAN TOM

14x14 Audio Matrix with Dante

and USB

44mm

Key Features

•

14 x 14 audio Matrix with Dante

, balanced / unbalanced

analogue and USB audio

• Supports separation (mono) of all audio channels and

independent control resulting in switching of up to 14x14 audio

feeds

• Analogue audio inputs support both balanced and unbalanced

audio + MIC line level signals

• MIC line level supports 48V/0.5mA Phantom power

• Selectable USB audio between USB-C and USB Type-B inputs with

USB audio class 2.0 support

• Supports: volume, balance and up to 8 band parametric equaliser

output

• Supports 48kHz 24-bit sampling rate for A/D and D/A conversion

• Supports 44.1, 48 & 96 KHz sample rates @ 24 Bit

•

device latency (supports 2, 3, 4, 5 or 10ms

Controller)

• Features 2x Dante

LAN ports supporting network redundancy

• Supports AES67 RTP audio transport

• Supports power via PoE+ (Class 4 IEEE 802.3at) on Dante

Primary

LAN connection or local power supply

• Control via front panel, RS-232, TCP/IP and web-GUI

• 1U design for 19” rack mount integration- Rack mounting kit

included
