4K 60Hz 4:4:4 Video over 1Gb Network - Transmitter
IP300UHD-TX
Description
The Blustream IP300 series Video over IP distribution platform allows
virtually latency free (1 frame) distribution of 4K 18Gbps HDMI video
over a 1Gb managed network.
Featuring full interoperability with the IP350UHD product line where
Dante is required, the IP300UHD-TX is an industry leading 4K HDMI
transmitter that, using visually lossless compression technology,
delivers 18Gbps HDMI, HDCP2.2, audio, bi-directional IR, RS-232 & USB/
KVM up to lengths of 100m over standard copper network architecture,
or greater distances using the in-built bre SFP network interface.
The unit can be powered via PoE from the network switch, or locally
should the switch not support PoE.
With multiple conguration options available, the exibility of the
Blustream Video over IP solution makes this platform ideal for multiple
installation types.
Key Features
•
Advanced 4K HDMI 2.0 video over 1Gb managed network
supporting 18Gbps HDMI signals
• Virtually unlimited system size
• Extends HDMI up to a distance of 100m over a single CAT cable
• SFP port for signal distribution over bre
• Features 1 x HDMI loop-out for integrating local displays or
cascading to multiple devices
• Supports up to 4K UHD 60Hz 4:4:4
• AES-256 encryption of video signals across network
• Supports HDR including Dolby Vision LLM
• Supports all known HDMI audio formats including Dolby Atmos,
Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
transmission
• Advanced signal management for independent routing of IR,
RS-232, USB/KVM, audio and video
• PoE (Power over Ethernet) to power Blustream unit from PoE
switch
• HDCP 2.2 compliant with advanced EDID management
• Audio breakout to analogue L/R audio, supporting both balanced
and unbalanced audio signals
• Balanced/unbalanced analogue audio input for replacing the
HDMI embedded audio with a dierent audio signal
• HDMI ARC, eARC or optical audio return from a display connected
to an IP300UHD or IP350UHD receiver
• OLED front panel display for advanced system information and
manual conguration
• Optional 24V power supply (should Ethernet switch not support
PoE)
• Compatible with Blustream IP300UHD-RX, IP300UHD-WP-TX, and
IP350UHD-TX/RX products
• IP300UHD/IP350UHD Multicast platform features 4 operational
modes:
- Matrix distribution (requires 1Gb network switch)
- Video wall (requires 1Gb network switch)
- One-to-one HDMI extender (no network switch required)
- One-to-many HDMI extender (no network switch required)
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.
25mm
190mm
SFP24V 1A LAN / PoE OPT OUT HDMI OUT HDMI IN
AUDIO IN
IP300UHD-TX
AUDIO OUT
IP300UHD-TX
Multicast 18Gbps UHD Transmitter
RESET
RS-232 IR IN
RX TX
IR OUT USB
DEBUG
ON OFF
