IP Multicast HDMI2.0 Video Transmitter with Dante
®
IP350UHD-TX
25mm
190mm
Description
The Blustream IP300 series Multicast distribution platform allows virtually
latency free (1 frame) distribution of 4K HDMI video over a 1Gb managed
network.
Featuring full interoperability with the IP300UHD product line, the
IP350UHD-TX is an industry leading Dante enabled 4K HDCP 2.2 HDMI
transmitter that, using visually lossless compression technology, delivers
18Gbps HDMI, Dante & AES67 audio, bi-directional IR, RS-232 & USB/KVM
up to lengths of 100m over standard copper network architecture, or
greater distances using the in-built bre SFP network interface.
The IP350UHD-TX can support both video and Dante audio distribution
from a single network. A second RJ45 connection allows for the Dante
audio network interface to be segregated from the video over IP network
if required.
The unit can be powered via PoE from the network switch, or locally
should the switch not support PoE.
With multiple conguration options available, the exibility of the
Blustream Multicast video over IP solution makes this platform ideal for
multiple installation types.
SFP24V 1A OPT OUT HDMI OUT HDMI IN
AUDIO IN
IP350UHD-TX
AUDIO OUT
IP350UHD-TX
RESET
RS-232 IR IN
RX TX
IR OUT USB
DEBUG
ON OFF
LAN 1 / PoE LAN 2
Multicast 18Gbps UHD Transmitter with Dante
®
Key Features
•
Advanced 4K HDMI 2.0 video over 1Gb managed network
supporting 18Gbps HDMI signals
• Virtually unlimited system size
• Extends HDMI up to a distance of 100m over a single CAT cable
• SFP port for signal distribution over bre
• Features 1 x HDMI loop-out for integrating local displays or
cascading to multiple devices
• Supports up to 4K UHD 60Hz 4:4:4
• Supports HDR including Dolby Vision LLM
• Dual RJ45 network ports congurable for independent or
combined HDMI and Dante signal distribution
• SFP port for independent or combined HDMI and Dante signal
distribution over a single bre cable
• In-built 2ch Dante transmitter for breakout of audio from HDMI
source or local analogue audio input
• In-built 2ch Dante receiver for embedding of audio onto the HDMI
signal or breakout to local analogue audio output
• HDMI ARC, eARC or optical audio return from a display connected
to an IP300UHD or IP350UHD receiver
• Supports all known HDMI audio formats including Dolby Atmos,
Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
transmission
• Advanced signal management for independent routing of IR,
RS-232, USB/KVM, audio and video
• PoE (Power over Ethernet) to power Blustream unit from PoE
switch
• HDCP 2.2 compliant with advanced EDID management
• Balanced/unbalanced analogue L/R audio embedding
• Audio breakout to analogue L/R audio, supporting both balanced
and unbalanced audio signals
• OLED front panel display for advanced system information and
manual conguration
• Optional 24V power supply (should Ethernet switch not support
PoE)
• Compatible with Blustream IP300UHD-RX and IP350UHD-TX/RX
products
• IP300/350 Multicast platform features 4 operational modes:
- Matrix distribution (requires 1Gb network switch)
- Video wall (requires 1Gb network switch)
- One-to-one HDMI extender (no network switch required)
- One-to-many HDMI extender (no network switch required)
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.




