HMXL44CS-KIT QUICK REFERENCE GUIDE
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
• Advanced HDBaseT™ technology oering uncompressed video and audio with zero latency
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Video down-conversion on HDBaseT™ output 1 allowing a display only capable of supporting lower video resolutions (4K
60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on the
remaining video outputs
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p video up to 70m
• HDMI re-clocking on the HEX70CS-RX HDBaseT™ receiver to help solve HDMI HDCP, compatibility and handshaking issues
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio
transmission
• HDMI audio breakout to associated analogue L/R audio outputs with pre-amp line level control
• Analogue audio input can be embedded onto any HDMI input
• Web interface module for control and configuration of matrix
• Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
• Supplied with Blustream 5V IR receivers and emitters
• Control via front panel, IR, RS-232, TCP/IP, or iOS / Android App
• Supports PoC (Power over Cable) to power supplied Blustream HDBaseT™ receivers
• 1U design for 19” rack mount integration - mounting kit included
• Advanced EDID management
• HDCP 2.2 compliant
Our Essential 4x4 HDBaseT™ Matrix oers unprecedented performance and value for the
custom installation market. The HMXL44CS-KIT is a HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 Matrix
package utilising HDBaseT™ CSC technology to deliver HDMI, bi-directional IR, RS-232
and PoC (Power over Cable) up to lengths of 70m over a single CAT cable. The matrix also
provides advanced features including simultaneous HDBaseT™ / HDMI on output 1, video
down conversion on HDBaseT™ output 1, audio breakout with pre-amp variable line-level
control, and a web browser interface module for control and configuration of the matrix. The
HMXL44CS-KIT is supplied with 4 x HEX70CS-RX HDBaseT™ receivers.
Introduction
HMXL44CS-KIT
Quick Reference Guide
FEATURES:
01
