Thank you for choosing one of our products. We hope you will get the very best performance
from this appliance.
Before using this appliance, carefully read the warnings contained in this instruction
manual, since these are important instructions for its safe installation, use and
maintenance. Carefully conserve this manual for future consultation.
The manufacturer reserves the right to make modifications considered to be necessary and
useful, without any advance notice.
This appliance satisfies the following EC directives:
93/68/CEE : General Regulations and subsequent amendments
2006/95/CE : Low Voltage and subsequent amendments
2004/108/CEE : Electromagnetic Compatibility and subsequent amendments
This appliance is marked in compliance with European Directive 2002/96/EC, Waste Electrical
and Electronic Equipment (WEEE).
By making sure that this product is properly disposed of, the user is contributing to preventing
potential environmental and health damage.
The symbol on the product, or on the documentation that goes with it, indicates that this
product must not be considered as domestic waste. It must instead be turned over to suitable
collection centres for the recycling of electrical and electronic equipment.
Dispose of it in accordance with local standards for waste disposal.
For further information on the treatment, salvage and recycling of this product, contact the
proper local authority, the home waste collection service or the retailer where the product was
purchased.
GENERAL WARNINGS
o THIS PRODUCT WAS DESIGNED FOR HOUSEHOLD USE.
o After having removed the packaging, make sure that the appliance is in good condition.
If any doubts exist, consult professionally qualified personnel.
o The packaging materials (for example: polystyrene, bags, etc.) can be hazardous for
children (suffocation hazard). Keep packaging materials away from children.
o The packaging is comprised of recyclable material and is marked by the symbol .
Please dispose of properly.
o This manual constitutes an integral part of the appliance. We recommend keeping it in
a safe place for the entire lifespan of the appliance and reading it carefully in order to
install, use, maintain, clean and treat the appliance.
o Lifting and moving of appliances weighing more than 25kg must be carried out using
proper equipment, or by two persons, in order to avoid risks or injuries.
o Do not leave the appliance exposed to atmospheric agents (rain, sun, etc.).
o If it is ever decided to no longer use the appliance, it is recommended to render it
inoperative by cutting the power supply cable after disconnecting it from the electrical
socket. In addition, it is also recommended to render the parts of the appliance that
could cause danger innocuous.
o Oven accessories that could come into contact with foods are constructed with
materials that conform with the regulations outlined in CEE Directive 89/109 of
21/12/88.
2
GENERAL WARNINGS - INSTALLATION / REPAIRS -
o THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR ANY DAMAGE TO PEOPLE OR
ITEMS CAUSED BY INCORRECT INSTALLATION OR IMPROPER, WRONG OR ABSURD USE
OF THE APPLIANCE.
o Attention: earth connection is required by law.
o CONNECTION: check that the specific details on the data plate regarding the workings of
the oven correspond to your electricity supply, for the mains electricity connection it is
necessary to provide for a device which ensures disconnection from the mains electricity
supply, with a contacts opening distance which enables complete disconnection in category
III over voltage conditions, in compliance with the installation regulations.
o The oven must be connected with a cable with minimum 1.0 section in the rear, using an
omnipolar switch that complies with currently enforced laws, with an opening distance
between contacts that is equal to or more than at least 3mm.
o The manufacturer will in no way be held liable if accident prevention standards area not
observed.
o Any work on the appliance must be done with the appliance disconnected from the
electrical power supply.
o If the oven is visibly damaged or malfunctioning, do not use it. Unplug it and contact
customer services.
o It is not recommended to use adapters, multiple plugs and/or extension cords. If it is not
possible to avoid using these, always remember to use exclusively extension cords and
single or multiple adapters that comply with currently enforced laws governing safety and
that do not exceed the maximum capacity indicated on the extension cord or single
adapter, or the maximum power indicated on the multiple adapter.
o In the event of a breakdown or if indispensable repairs are required, contact customer
service.
o It is not permitted to modify, tamper with or attempt repairs on the appliance, especially
with tools (screwdrivers and the like), either inside or outside the appliance.
o Inappropriate repair work may cause serious accidents, damage the appliance and
equipment and lead to improper operation.
o Appliances repaired in technical service centres must undergo routine testing, especially
the continuity of the earth circuit.
o Make sure that the power cable of the electrical appliances is not trapped by the door. The
electrical insulation could be damaged.
o If the power cable has been damaged, it must be replaced by customer service to prevent
dangerous accidents.
GENERAL WARNINGS – FIRST USE -
o Warning: the oven must be disconnected from the electrical mains, or the electrical power
supply must be unplugged, or the system main switch must be off.
o Before using the oven, carefully clean the inside of the oven, the grills and the drip pan
using non-abrasive soap and tepid water. Insert the grill and drip pan in their respective
tracks.
o Once this has been complete, connect the oven to the mains electricity supply and switch
it onto the steam cycle (or the grill if available) for around 30 minutes, in order to
eliminate any residues of fat, oil or resin from during its manufacture which could provoke
bad odours during cooking; then, air the room.
o Once this simple operation is complete, the oven is ready for use
3
GENERAL WARNINGS – OPERATIONS/CLEANING -
o This appliance is to be used by adults who are familiar with these user instructions.
o Children are often unable to recognize the ri g the appliance. During sks entailed in usin
oven operations, make sure to keep an adequate distance.
o Make sure that children do not play with the appliance.
o The disabled must be assisted by capable adults.
o Before closing the oven door, make sure there are no foreign objects or pets inside the
oven.
o Do not place heat-sensitive or flammable materials in the ovens such as detergents, oven
sprays, etc.
o Do not use the appliance to heat the room.
o While it is working, the appliance will get hot. Make sure not to touch the heated parts
inside of the oven.
o Wait for a sufficient length of time before doing anything like cleaning the oven.
o When opening the oven door, steam and hot water spray may come out of the oven. Use
caution.
o If the oven contains steam, it is not advisable to put your hands inside of it.
o Leave the oven door open in the supported position only.
o Do not leave the door open to avoid tripping or crushing fingers.
o Do not sit or lean on the oven door, and do not use it as a work surface.
o Do not touch the appliance with damp hands or feet.
o Do not pull on the power supply cable, or the appliance itself, to remove the plug from the
power socket.
o Hot grease and fat catch fire easily. Be careful. Never try to put out a grease fire using
water (there may be an explosion). Suffocate the flames with wet cloths.
o The grill, hotplates and cooking containers will become extremely hot. Use protective
gloves or hot pads.
o WARNING: WE RECOMMEND USING ADEQUATE PREVENTION AND PROTECTION
DEVICES WHEN DISMANTLING, MAINTAINING AND CLEANING THE APPLIANCE
(GLOVES, ETC.)
o Do not use steam cleaners to clean the oven
o When using or cleaning the oven, be careful not to place your fingers in the door hinges or
in the door itself in order to avoid crushing or injuries.
o Avoid cleaning parts of the appliance that are still warm.
o Painted, chrome plated and glass parts should be washed with warm water.
o The inside of the oven should be cleaned after each use using warm water and detergent,
then rinsed and dried thoroughly.
o The parts in stainless steel, and in particular the areas with engraving, must not be
cleaned using abrasive detergents or diluents. It is preferable to use only a soft cloth
dampened with warn water or liquid dish detergent.
o To clean stubborn stains, denatured alcohol may be used.
o Stainless steel may remain stained if it is in contact for an extended time with water which
has excessive mineral deposits or with aggressive detergents (containing phosphorus).
After cleaning is finished, thoroughly rinse and dry using a soft cloth
o Avoid leaving acidic liquids on painted or enamelled parts (vinegar, lemon juice,
aggressive detergents, etc.)
o Do not use steel wool or abrasive sponges, muriatic acid or other substances that can
scratch or streak, or that can cause the glass door to break.
o Only use the heat sensor recommended for this oven.
4
It is advisable to only use water which has a low calcium content or bottled
mineral water, in order to limit the formation of lime scale.
o Empty the water pitcher after each use for hygiene reasons.
o After cooking, and when the oven has cooled sufficiently, use a soft cloth to dry any
liquid remaining on the bottom of the cooking chamber.
o Use the appliance in settings where the temperature is not lower than 5°C. If the
appliance is subject to frost, the residual water contained in the hydraulic circuit can
damage the pipes and the pump.
5
TECHNICAL DATA
Usable oven dimensions:
Width 597mm
Depth 568mm
Height 460mm
Power Draw:
Steam Cooking 800-950 W
Grill Cooking 1400-1650 W (for steam ovens with GRILL function)
Useable Volume of Oven:
27 L
Water tray capacity: 1.2 L
Voltage and power supply frequency:
220-240V~ 50/60Hz
CONNECTION TO MONO-PHASE ELECTRICITY
For direct connection to the mains power, it is necessary to use a device that ensures that the
mains power is disconnected, with a distance between contacts that allows complete
disconnection in compliance with surge category III and installation regulations.
Assembly of the power cable:
1. Open the terminal board by placing a
screwdriver under the side flaps on the cover, pull
and then open the cover (see the figure).
2. Install the power supply cable, unscrew the screws on the
cable grip and the three screws on contacts L-N- and then attach the
wires under the screw heads following the colours Blue(N), Brown(L),
Green-Yellow(see the figure).
3. Attach the wire to the appropriate wire holder.
4. Close the terminal board lid.
6
Attaching the power supply cable to the mains.
In case of direct connection to the mains, it is necessary to install an omnipolar switch
between the appliance and mains power with a minimum opening between the contacts of
3mm dimensioned for the indicated capacity and in compliance with currently enforced
regulations (the ground cable must not be interrupted by the switch).
The power supply cable must be positioned in a way that it does not exceed 50°C in any area
of the surrounding temperature.
The installer is responsible for correct electrical hook-up and adherence to safety regulations.
Before hook-up to the mains, make sure that:
- the socket has a ground connection and that it complies with legal regulations;
- the socket is able to withstand the oven's maximum power capacity indicated on the
features plate.
- the power supply voltage is within the value80s listed in the electrical characteristics
label.
- the socket is compatible with the appliance plug.
- If this is not the case, replace the socket or the plug. Do not use extension cords or
multiple sockets.
- Once the appliance is installed, the electrical cable and the electrical power socket must
be easy to reach.
- The cable must not be bent or compressed.
- The cable must be periodically checked and only replaced by authorized technicians.
- The Company declines any responsibility if these instructions are not adhered to.
Replacement of the power cable:
If the power cable needs to be replaced, use cables of the following type only:
- H05 RR-F,
- H05 V2V2-F (T90),
suitable for the operating capacity and temperature.
The green-yellow ground cable must be longer than the other two conductors
by approximately 2cm.
7
INSTALLATION
Important:
any adjustments, maintenance, etc. must be executed with the oven
disconnected from electricity.
To guarantee the proper functioning of the built-in appliance, the furniture unit must have
suitable characteristics:
- the panels adjacent to the oven must be constructed with heat resistant materials;
- in the case of veneered wood furniture units, the glue must be heat resistant to
temperatures up to 100°C;
The oven must be located in a standard opening of 560mm, as illustrated in Fig. 1, whether
under a counter or in a column position.
When inserting the oven into fficient ventilation it is the column, in order to ensure su
indispensable to make an opening of at least 85÷90 mm as shown in the picture below.
The oven is secured to the furniture unit by four “A” screws located in the holes of the
frame.
Make sure not to lift the oven by its door when inserting it. Furthermore, do not place
excessive pressure on the door when it is open.
8
Produkt Specifikationer
| Mærke: | Boretti |
| Kategori: | Ovn |
| Model: | BS45 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Boretti BS45 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Ovn Boretti Manualer
15 Oktober 2024
14 Oktober 2024
1 Oktober 2024
27 September 2024
23 September 2024
17 September 2024
14 September 2024
14 September 2024
12 September 2024
11 September 2024
Ovn Manualer
- Ferrari
- WestBend
- Proline
- König
- UPO
- Magic Chef
- Heller
- Bella
- Cooking Performance Group
- Haier
- Sam Cook
- Rinnai
- Buffalo
- Izzy
- New.Up!
Nyeste Ovn Manualer
2 August 2025
2 August 2025
2 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
