Intrusion Alarm Systems | B901 Door Controller

B901 Door Controller

www.boschsecurity.com

uDirect interface to compatible Wiegand card readers

uOn-board buzzer output and supervised on-board

points

uRequest to Exit and Request to Enter inputs that

can have a shunt only option

uFour door states: Locked, Unlocked, Secured, Fire

Unlock

uSDI2 support as well as SDI compatible

The B901 Access Control Interface Module is a fully

supervised, addressable SDI/SDI2 bus device that

allows access control integration for Bosch compatible

control panels. This module offers 14 programmable

levels of access authority. Authority for access is

controlled by the user level, the group of the user, the

time of day, the door state, and the area armed state.

Control each authority restriction through automatic

and manual functions.

A door that has been automatically released by the

control panel will require manually re-engaging to

return to normal.

In a combination Fire/Intrusion system, the B901

should not be used to lock doors used for emergency

egress unless these doors have a mechanical release

mechanism.

Functions

Reader input

• Standard 5-wire Weigand interface.

• +5 VDC or +12 VDC supplied to power readers.

• Open collector output for reader LED.

Unsupervised inputs

• Tamper. Supports normally open devices.

• REX. Supports normally open devices. Request to Exit

(REX) on short.

• RTE. Supports normally open devices. Request to

Enter (RTE) on short.

Supervised input

• 1 kΩ End-of-line resistor.

• Use for door contact.

Door states

Four door states are controlled through the keypad,

RPS (Remote Programming Software), scheduled

events (SKEDs), and automatic programmable

functions in the door controller parameters:

• Locked. The lock relay can be deactivated (door

allowed to open) with a valid credential or REX/RTE

input.

• Unlocked. The Lock relay is held in the deactivated

state to allow access without the need of a

credential.

• Secured. The lock relay is activated and no access is

allowed even with valid credential (overridden by Fire

Unlock).

• Fire Unlock. The lock relay is held in the deactivated

state during a Fire Alarm. This allows free access to

and from the building during an emergency.

Two automatic functions link the door state to the

arming state of the area:

• Auto Door. When the area is Off (disarmed), the door

state is switched to “Unlocked”.

• Disarm on Open. With this function as "Yes," a user

with valid access rights activates the strike and turns

off (disarms) the system after the door is opened.

With this function as "No," the area turns off

(disarms) upon the strike activation.

Indicators

• Heartbeat LED. Blue LED blinks on and off when

system is operational. A rapid three-blink sequence

indicates a system error.

• Reader LED. Rapidly blinking LED indicates the Card

data is being received. When the LED is off, no card

data is being received.

Certifications and approvals

Region Regulatory compliance/quality marks

Australia RCM ACMA

Europe CE EMC, RoHS [B915, B920, B930, B430,

B208, B308, B901]

USA UL Underwriters Laboratories

UL UL 294 - Standard for Access Control

Units and Systems

UL UL 365 - Police Station Connected Bur-

glar Alarm Units

UL UL 609 - Standard for Local Burglar

Alarm Units and Systems

UL UL 864 - Standard for Control Units and

Accessories for Fire Alarm Systems

(10th edition)

UL UL 985 - Household Fire Warning Sys-

tem Units (6th edition)

UL UL 1023 - Household Burglar Alarm Sys-

tem Units

UL UL 1076 - Proprietary Burglar Alarm

Units and Systems

UL UL 1610 - Central Station Burglar Alarm

Units

CSFM California State Fire Marshal (see our

website)

FCC Part 15 Class B

Canada ULC Underwriters Laboratories of Canada

ULC CAN/ULC S303 - Local Burglar Alarm

Units and Systems

ULC CAN/ULC S304 - Standard for Signal Re-

ceiving Center and Premise Burglar

Alarm

ULC ULC-ORD C1023 - Household Burglar

Alarm System Units

ULC ULC-ORD C1076 - Proprietary Burglar

Alarm Units and Systems

IC ICES-003 - Information Technology

Equipment (ITE)

Installation/configuration notes

The B901 Access Control Interface Module is

individually programmed through the control panel.

The module is compatible with several credential

models and readers.

Notice

Not all products and features are available in all

regions. Consult your local Bosch representative

for availability details.

Compatibility

Bosch readers and

accessories

ARD-AYJ12 EM Prox Mullion

ARD-MINIPROX

ARD-PROX-PPL

ARD-SER90-WI

ARD-SER40-WI

ARD-SER10-WI

D8223 HID Prox Wall Mount

D8224 HID Prox Mullion

D8224‑SP Low‑profile card reader,

HIDprox

D8225 HID Prox Mini Mullion

D8229 PIN Reader

Bosch tokens and cards ACA-ATR13 EM Tokens

ACD-ATR11ISO EM Cards

ACD-ATR14CS EM Clamshell Cards

ACD-IC2K26-50 iClass Cards

ACT-IC2K26-10 iClass Tokens

D8236‑10 HID Prox Cards

D8236KF‑10 HID Prox Tokens

Parts included

Quan

tity

Component

1 B901

1 1 kΩ ½ watt end of line resistor

1 Innerconnect cable (included)

3 # 6x3/8 self-tapping screws

1 Literature pack

Technical specifications

Environmental considerations

Relative humidity 5% to 93% at +32°C (+90°F)

Temperature (operating) 0°C to +49°C (+32°F to +120°F)

Properties

Dimensions 2.9 in x 5.0 in x 0.6 in

(73.5 mm x 127 mm x 15.25 mm)

Power requirements

Current Standby:110 mA + reader current

Alarm: 110 mA + reader current

Output (alarm) Form C relay (COM, NC, NO) at 12/24

V @ 2.0 A

Voltage (input) 12 VDC nominal

2 | B901 Door Controller
