Side 1/44
OWNER’S MANUAL
VS Series Loudspeakers
VS 336, VS 344, VS 325C, VS 224, VS 260, and VS 240
Español
Altavoces VS de Boston
Manual del Propietario /
Instrucciones de Seguridad /
Información de Cumplimiento
Français
Haut-parleurs Boston VS
Guide de l’utilisateur /
Instructions de sécurité /
Informations relatives à la
conformité
Italiano
Altoparlanti Boston VS
Manuale dell’utente/Istruzioni
di sicurezza/Informazioni sulla
conformità
Svenska
Boston VS högtalare
Bruksanvisning /
säkerhetsanvisningar
/ information om
överensstämmelse
Deutsch
Boston VS Lautsprecher
Bedienungsanleitung
/ Sicherheitshinweise /
Konformitätserklärung
2
Introduction
Thank you for choosing Boston Acoustics. The Boston VS Series Loudspeakers – our best-performing, best-looking products – deliver
a superb audio/video or audio-only experience. Innovative driver and cabinet designs yield exceptional sonic characteristics. Each
VS Series model is voiced to blend with the others so they can be combined to deliver the best performance in any configuration.
Adding to the sonic appeal of the VS Series is their visual appeal. The striking piano lacquer finish and high-gloss furniture-grade
end panels cover cabinets that are so much more than rectangular boxes. The structural elements of the cabinets are made of
high-frequency-molded MDF which feature curved surfaces that reduce internal standing waves and panel resonances. Substantial
internal braces enhance the strength of the cabinets to provide an ideal environment for the high performance drivers.
Features
• Elegantpianolacquernishcabinet
• High-glossmulti-layerfurniture-gradeendpanels
• High-frequency-moldedMDFcabinetfeaturescurvedsurfaces,whichreduceinternalstandingwavesandpanelresonances
• Long-throwwoofersandmidrangesfeaturecastaluminumframes,OrganicCompositeConeMaterial(OCCM),andrubbersurrounds
• SuperWideBandwidth(SWB)tweeterswithaCoupledDualConcentricDiaphragm(CDCD)minimizesphaseshiftanddistortion
while improving pistonic motion.
• MagnaGuard®videoshielding
• 5-waygold-platedprecisionbindingposts
• Acousticallytunedports
Specifications VS 336 VS 344 VS 325C VS 224 VS 260 VS 240
Frequency Range (±3dB):
35Hz–30kHz 42Hz–30kHz 65Hz–30kHz 78Hz–30kHz 45Hz–30kHz 70Hz–30kHz
Recommended Amplier
10–400watts 10–250watts 10–250watts 10–200watts 10–250watts 10–100watts
Sensitivity:
87dBSPL/2.8V/m 87dBSPL/2.8V/m 90dBSPL/2.8V/m 87dBSPL/2.8V/m 87dBSPL/2.8V/m 86dBSPL/2.8V/m
Nominal Impedance:
 8ohms 8ohms 8ohms 8ohms 8ohms 8ohms
Crossover Frequency:
250/2,500Hz 300/2,500Hz 350/2,400Hz 1,900Hz 1,900Hz 2,000Hz
Bass Driver:
Triple6
1
/2” Quadruple4
1
/2” Dual5
1
/4” Dual4
1
/2” 6
1
/2” 4
1
/2”
(165mm) (114mm) (133mm) (114mm) (165mm) (114mm)
Midrange Driver:
4
1
/2”(114mm) 4
1
/2”(114mm) 3”(76mm) — — —
High-Frequency Driver:
1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm) 1”(25mm)
SuperWide SuperWide SuperWide SuperWide SuperWide SuperWide
Bandwidth Bandwidth Bandwidth Bandwidth Bandwidth Bandwidth
Dimensions (H x W x D):
46
1
/16x9
7
/8 x 12
13
/16” 44x5
3
/8x8
3
/8” 7
1
/8x28
3
/16x6
5
/16” 25x5
3
/4 x 3
3
/4” 15
1
/4x8
7
/8x10
1
/4” 9
7
/16x5
7
/8x6
3
/8”
(1170x250x325mm) (1117x148x161mm) (181x716x161mm) (632x148x96mm) (387x225x260mm) (240x150x162mm)
Base Dimensions (W x D):
8
3
/8x8
3
/8”(
213x213mm)
Weight:
66.3lbs(30.12kg) 34.8lbs(15.8kg) 25.9lbs(11.78kg) 10lbs(4.5kg) 19lbs(8.6kg) 6.3lbs(2.9kg)
E
N
G
L
I
S
H
Boston Acoustics continually strives to update and improve its products.
The specifications and construction details are subject to change without notice.
