Package Contents

Device Parts

Assembling

1. Clamp Head

2. Extension Pole Hole Knob

3. Clamp Head Knob

4. Mounting Hole (1/4”) (x3)

5. Handle

1. Mounting Platform (1/4”)

2. Flex Arm Knob

Mount the magic arm onto clamp.

Use needle-nose pliers to secure the magic arm.

Swivel the handle to release the clamp.

Camera Clamp

Magic Arm

Mount the clamp.

Tighten it.

-1 For tube or at surface (< 3.5 in (90 mm)) ﬂ

Mount the camera onto the mounting platform.

Use needle-nose pliers to secure the camera.

Swivel the ex arm knob to adjust the shooting angle. ﬂ

Tighten it.

Pull clamp head knob and slide clamp head down.

Mount the clamp.

Tighten it.

-2 Better grasp for at surface under 2.4 in (60 mm) ﬂ

Tube

Irregular cushion Grooved cushion

Flat surface

EN_A2 301-0133-00

amera Clamp Kit

User Manual

Speci cationsﬁ

ACC1000

Camera clamp, magic arm

¼”

Tube: 0.4- 3.5 in (10 - 90 mm)

Flat surface: 0.04- 3.5 in (1 -90 mm)

6.6 lb (3 KG)

Clamp: Stainless, aluminum

Magic Arm: Stainless, metal, aluminum

Model

Contents

26.5 oz (750 g) (included Magic Arm) Weight

Camera Mount Screw

Clamping Range

Magic Arm Load Capacity

Folded: 8.2x 3.7x 1.5 in

(209x 94x 39 mm)

Extended: 6.9x 7.1x 2.4 in

(176x 180x 60 mm)

110 lb (50 KG) (without extension pole)

Clamp Load Capacity

Size (LxWxH)

Materials

For manuals in other languages, visit

www.brinno.com/support

The product features, specications sheets and instructions may

dier from actual products. Please refer to Brinno ocial site for

the latest version of user manual.

xtend Clamp

ng Rang

** Extension

le is not included in BCC2000

pac

kag

e *

Install extension

pol

emove the extension pole hole knob

Pull out the clamp head knob.

e the cl

amp

head down to the desire

d p

osition

Slid

ten the extension pole hole knob

Produkt Specifikationer

Mærke:	Brinno
Kategori:	Ikke kategoriseret
Model:	ACC1000P
Bredde:	285 mm
Dybde:	70 mm
Højde:	120 mm
Vægt:	1280 g
Produktfarve:	Aluminium, Black
Produkttype:	Monteringsklemme
Materiale:	Aluminium, Stainless steel
Oprindelsesland:	Taiwan
Maksimal vægtkapacitet:	3 kg
Tilslutningsgevind:	1/4 "
